Genes: Structure Replication and Expression

1
Chapter 12

• Genes Structure Replication and Expression

2

• Replication
• During mitotic division information is duplicated
  by DNA replication and is passed on to next
  generation
• daughter cells has exavcyt replica of the parent
  DNA

3
Role of DNA in Protein synthesis

• DNA and protein synthesis involves
• Transcription- yields a ribonucleic acid (RNA)
  copy of specific genes
• Translation- uses information in messenger RNA
  (mRNA) to synthesize a polypeptide.
• Protein synthesis is assisted by RNA (tRNA) and
  ribosomal RNA (rRNA)

4
Nucleic Acids
5
Nucleic Acid StructureDeoxyribonucleic Acid (DNA)

• polymer of nucleotides
• contains the bases adenine, guanine, cytosine and
  thymine
• sugar is deoxyribose
• molecule is usually double stranded

6

• DNA is a double-stranded molecule twisted into a
  helix (think of a spiral staircase).
• Each spiraling strand, comprised of a
  sugar-phosphate backbone and attached bases, is
  connected to a complementary strand by
  non-covalent hydrogen bonding between paired
  bases.
• The bases are adenine (A), thymine (T), cytosine
  (C) and guanine (G). A and T are connected by
  two hydrogen bonds. G and C are connected by
  three hydrogen bonds.

7
(No Transcript)
8
(No Transcript)
9
DNA Structure Two Complementary Strands

• base pairing
• Adenine (purine) and thymine (pyrimidine) pair by
  2 hydrogen bonds
• Guanine (purine) and cytosine (pyrimidine) pair
  by 3 hydrogen bonds
• major and minor grooves form when the 2 strands
  twist around each other

10
Nucleic Acid StructureRibonucleic Acid (RNA)

• polymer of nucleotides
• contains the bases adenine, guanine, cytosine and
  uracil
• sugar is ribose
• most RNA molecules are single stranded

11
RNA Structure

• three different types which differ from each
  other in function and in structure
• messenger RNA (mRNA)
• ribosomal RNA (rRNA)
• transfer RNA(tRNA)

12
The Organization of DNA in Cells

• In most bacteria DNA is a circular, double helix
• further twisting results in supercoiled DNA
• in bacteria the DNA is associated with basic
  proteins
• help organize the DNA into a coiled chromatin
  like structure

13

• DNA Replication

14
DNA Replication

• complex process involving numerous proteins which
  help ensure accuracy
• the 2 strands separate, each serving as a
  template for synthesis of a complementary strand
• synthesis is semi-conservative each daughter
  cell obtains one old and one new strand

15
DNA Replication

• bidirectional from a single origin of replication

16
DNA replication (arrows) occurs in both
directions from the origin of replication in the
circular DNA found in most bacteria.
17
Rolling Circle Replication

• some small circular genomes (e.g., viruses and
  plasmids)
• replicated by rolling-circle replication
• Animation illustrating DNA replication by
  complementary base pairing

18
Genes
19
Gene Structure

• Gene
• the basic unit of genetic information
• also defined as the nucleic acid sequence that
  codes for a polypeptide, tRNA or rRNA
• linear sequence of nucleotides
• codons are found in mRNA and code for single
  amino acids
• reading frame
• organization of codons such that they can be read
  to give rise to a gene product

20
Importance of Reading Frame
Figure 12.16
21
Genes that Code for Proteins

• template strand directs RNA synthesis
• promoter is located at the start of the gene
• is the recognition/binding site for RNA
  polymerase
• functions to orient polymerase
• leader sequence is transcribed into mRNA but is
  not translated into amino acids
• Shine-Delgarno sequence important for initiation
  of translation

22
Genes that Code for Proteins

• The Coding Region
• begins with the DNA sequence from 3-TAC-5
• produces codon AUG which codes for
  N-formylmethionine, a modified amino acid used to
  initiate protein synthesis in bacteria ( check
  fig.)
• coding region ends with a stop codon, immediately
  followed by the trailer sequence which contains a
  terminator sequence used to stop transcription

23
Bacterial Gene Structure
24
Genes That Code for tRNA and rRNA

• tRNA/rRNA genes have promoter (recognition/bindin
  g site for RNA polymerase), leader (is
  transcribed into mRNA), coding region, spacer and
  trailer regions (contains a terminator sequence
  used to stop transcription)
• during maturation process.

leader, spacer, and trailer removed during
maturation process
Figure 12.19a
25
rRNA genes have promoter, leader, coding, spacer,
and trailer regions
spacer and trailer regions may encode tRNA
molecules
Figure 12.19b
26
m
Fig. 12.20
27
Transcription
28
(No Transcript)
29
Transcription

• RNA is synthesized under the direction of DNA
• RNA produced has complementary sequence to the
  template DNA
• three types of RNA are produced
• mRNA carries the message for protein synthesis
• tRNA carries amino acids during protein synthesis
• rRNA molecules are components of ribosomes

30
Transcription in Bacteria

• Definitions to understand protein synthesis
• in most bacterial RNA polymerases
• Holoenzyme can begin transcriptiongt What is
  Holoenzyme??
• the core enzyme is composed of 5 chains and
  catalyzes RNA synthesis
• the sigma factor has no catalytic activity but
  helps the core enzyme recognize the start of
  genes
• holoenzyme core enzyme sigma factor
• only the holoenzyme can begin transcription

31
Transcription in Bacteria.

• Transcription in Bacteria is catalyzed by a
  single RNA polymerase.
• a reaction similar to that catalyzed by DNA
  polymerase for DNA syntehsis.
• ATP,GTP,CTP and UTP are used to produce a
  complementary RNA copy of the template DNA
  sequence

32
http//www.vidoemo.com/yvideo.php?iM2FWVDJEcWuRpV
GJ0QTgreplication-transcription-and-translation
33
Transcription Process
34
Transcription Initiation

• Promoter
• site where RNA polymerase binds to initiate
  transcription is not transcribed

35
Transcription Elongation

• after binding, RNA polymerase unwinds the DNA
• transcription bubble produced
• moves with the polymerase as it transcribes mRNA
  from template strand
• within the bubble a temporary RNADNA hybrid is
  formed

36
Coupled Transcription and Translation in
Prokaryotes
37
Proteins
38
The Genetic Code

• mRNA sequence is translated into amino acid
  sequence of polypeptide chain (process
  translation).
• an understanding of the genetic code is necessary
  before translation is studied.

39
Organization of the Code

• code degeneracy
• up to six different codons can code for a single
  amino acid
• sense codons
• the 61 codons that specify amino acids
• stop (nonsense) codons
• the three codons used as translation termination
  signals
• do not encode amino acids

40
Translation
41
Translation

• Translation of mRNA into protein
• synthesis of polypeptide is directed by sequence
  of nucleotides in mRNA
• Ribosome
• 70S ribosomes 30S 50S subunit
• site of translation
• polyribosome (polysome) complex of mRNA with
  several ribosomes

42

• Translation of mRNA into protein
• Three phases
• Initiation
• Elongation
• Termination

43

• During translation, the mRNA is "read" according
  to the genetic code which relates the DNA
  sequence to the amino acid sequence in proteins
• Each group of three base pairs in mRNA
  constitutes a codon, and each codon specifies a
  particular amino acid (hence, it is a triplet
  code).
• The mRNA sequence is thus used as a template to
  assemblein orderthe chain of amino acids that
  form a protein.

44
Transfer RNA (tRNA) and Amino Acid Activation

• The tRNA molecules are adaptor moleculesthey
  have one end that can read the triplet code in
  the mRNA through complementary base-pairing, and
  another end that attaches to a specific amino
  acid
• attachment of amino acid to tRNA is catalyzed by
  aminoacyl-tRNA synthetases

45

• The translation of mRNA begins with the formation
  of a complex on the mRNA (Fig. below).
• First, three initiation factor proteins (known
  as IF1, IF2, and IF3) bind to the small subunit
  of the ribosome.
• This preinitiation complex and a
  methionine-carrying tRNA then bind to the mRNA,
  near the AUG start codon, forming the initiation
  complex.

46
The Ribosome
47

• Methionine (Met) is the first amino acid
  incorporated into any new protein, however, it is
  not always the first amino acid in translation of
  protein.
• In many proteins, methionine is removed after
  translation.

48

• The large ribosomal subunit binds to this
  complex, which causes the release of IFs
  (initiation factors) once the initiation complex
  is formed on the mRNA

• The large subunit of the ribosome has three sites
  at which tRNA molecules can bind
• The A (amino acid) site is the location at which
  the aminoacyl-tRNA anticodon base pairs up with
  the mRNA codon, ensuring that correct amino acid
  is added to the growing polypeptide chain.

49

• The P (polypeptide) site is the location at which
  the amino acid is transferred from its tRNA to
  the growing polypeptide chain.
• Finally, the E (exit) site is the location at
  which the "empty" tRNA sits before being released
  back into the cytoplasm to bind another amino
  acid and repeat the process.

50

• The initiator methionine tRNA is the only
  aminoacyl-tRNA that can bind in the P site of the
  ribosome, and the A site is aligned with the
  second mRNA codon.
• The ribosome is thus ready to bind the second
  aminoacyl-tRNA at the A site, which will be
  joined to the initiator methionine by the first
  peptide bond.

51
Elongation of the Polypeptide Chain

• The next phase in translation is known as the
  elongation phase .
• Elongation cycle is the sequential addition of
  amino acids to growing polypeptide consists of
  three phases
• aminoacyl-tRNA binding
• transpeptidation reaction
• Translocation
• The above process need several Elongation factors
  ( EF)

52
Elongation First, the ribosome moves along
the mRNA in the 5'-to-3'direction, which requires
the elongation factor G, in a process called
translocation
53
..Elongation Cycle

• The tRNA which corresponds to the second codon
  can then bind to the A site, a step that requires
  elongation factors (in E. coli, these are called
  EF-Tu and EF-Ts) and GTP (guanosine triphosphate
  ) as an energy source for this acitivity.
• Upon binding of the tRNA-amino acid complex in
  the A site, GTP is cleaved to form guanosine
  diphosphate (GDP), then released along with EF-Tu
  to be recycled by EF-Ts for the next round.

54

• .Elongation
• In the next step, peptide bonds between the
  now-adjacent first and second amino acids are
  formed through a peptidyl transferase activity.

• After the peptide bond is formed, the ribosome
  shifts, or translocates, again, thus causing the
  tRNA to occupy the E site.

• The tRNA is then released to the cytoplasm to
  pick up another amino acid.
• The A site is now empty and ready to receive the
  tRNA for the next codon.

55

• .Elongation
• This process is repeated until all the codons in
  the mRNA have been read by tRNA molecules
• the amino acids attached to the tRNAs have been
  linked together in the growing polypeptide chain
  in the appropriate order.
• At this point, translation must be terminated,
  and the nascent protein must be released from the
  mRNA and ribosome.

56
Final Phase in Elongation Cycle - Translocation

• Three simultaneous events
• peptidyl-tRNA moves from A site to P site
• ribosome moves down one codon
• empty tRNA leaves P site

57

• Termination of Translation/protein synthesis
• Three termination codons ( Non-sense or stop
  codon) that are employed at the end of a
  protein-coding sequence in mRNA UAA, UAG, and
  UGA
• No tRNAs recognize these codons.
• Instead, release factors (RFs) helps in
  recognition of stop codons.
• Release factors are protein which binds and
  facilitates release of the mRNA from the ribosome
  and subsequent dissociation of the ribosome.

58
Several ribosome can align on one mRNA strand
and forms several polypeptide chains each with 20
or more amino acids.

• http//www.vidoemo.com/yvideo.php?ibmNqSWlEcWuRpN
  TFoUWsdna-translation-animation

59
Prokaryotic and Eukaryotic Translation

• The translation process is very similar in
  prokaryotes and eukaryotes.
• Although different elongation, initiation, and
  termination factors are used, the genetic code is
  generally identical.
• In bacteria, transcription and translation take
  place simultaneously, and mRNAs are relatively
  short-lived.

60

• In eukaryotes, mRNAs have highly variable
  half-lives,
• are subject to modifications, and must exit the
  nucleus to be translated.

61
References

• http//student.ccbcmd.edu/biotutorials/dna/fg12.ht
  mlhttp//www.accessexcellence.org/RC/VL/GG/dna_mol
  ecule.php
• http//www.nature.com/scitable/topicpage/Reading-t
  he-Genetic-Code-1042
• http//www.nature.com/scitable/topicpage/Translati
  on-DNA-to-mRNA-to-Protein-393
