SMBL and Blast

1
SMBL and Blast

• Joe Rinkovsky
• Unix Systems Support Group
• Indiana University

2
Introduction

• IU has around 2000 Windows PCs in public Student
  Technology Centers
• Condor is used to harvest unused cycles
• Simple Message Brokering Library(SMBL) used for
  parallelizing applications on Windows
• Web portal for user interaction

3
Project History

• SETI_at_home Was used as initial test of Condor
• SMBL was created to address the lack of a
  general purpose parallel library on Windows that
  could tolerate sporadically available systems
• FastDNAml was ported to SMBL
• Web portal created
• Other apps ported to SMBL(MEME,BLAST)

4
System Architecture

• Condor server running on Linux
• BLAST databases served via Samba on a second
  Linux machine
• Apache/MySQL/PHP web portal
• Windows clients

5
What is SMBL?

• Simple Message Brokering Library
• Open Source(http//smbl.sf.net)
• Uses master / worker model
• Process and Port Manager(PPM) manages SMBL
  servers and master processes
• Number of master /foreman processes is different
  for each application
• SMBL workers contact the SMBL master to get work
• SMBL server terminates workers when they are no
  longer needed

6
Condor and SMBL

• Condor is used as the scheduling and delivery
  system for SMBL workers
• SMBL workers contact the SMBL server when they
  start running to begin receiving work.
• SMBL server seperates the work to be into smaller
  pieces depending on the number of workers
• Work is redistributed if a worker is lost
• SMBL server terminates workers when there is no
  work left

7
Applications using SMBL

• FastDNAml Generates phylogenic trees from
  molecular data
• MEME Detects patterns in nucleotide and protein
  sequences
• NCBI BLAST(blastall) Query molecular sequences
  against sequence databases

8
The Challenges of porting BLAST to SMBL

• BLAST relies on the availability of large
  database files
• Files too large for efficient delivery via Condor
• Local copies of databases on pool machines would
  be difficult to manage
• Sharing DB files via Samba is the best solution
• Samba was moved to a seperate server to increase
  perfomance

9
The Challenges of porting BLAST to SMBL(cont.)

• BLAST jobs take more time to complete than
  FastDNAml and MEME
• Dissapearing worker problem
• Pool machines would end up in CLAIMED/IDLE state
• Size of our Condor pool made the problem hard to
  track
• Only jobs taking more than 30 minutes were
  affected
• Problem was determined to be state table
  sessions timing out on the machine room
  firewall.
• Machines were removed from firewall and switched
  to host-based iptables firewall.

10
Web portal

• Apache/MySQL/PHP based
• Jobs are submitted via portal ONLY
• Condor submit files are dynamically generated
  based on user input
• Status of jobs can be checked using the portal
• Results retrieved from the portal

11
(No Transcript)
12
(No Transcript)
13
Questions?
