Norman MacLeod

1
Introduction to Allometry
Norman MacLeod Department of Palaeontology, The
Natural History Museum
2
Scale of Life
108
105
102
10-1
10-4
10-7
10-10
10-13
Mycoplasm
Tetrahymena
Bee
Human
Malarial Parasite
Large Amoeba
Blue Whale
Hamster
In terms of physical scale, life covers 21 orders
of magnitude
3
Scale of Life
Organisms at one end of the scale have different
shapes from those at the other
A.
B.
C.
4
Size-Related Constraints
Comparative anatomy is largely the history of
lifes attempts to increase area in relation to
volume. J.B.S. Haldane
5
Size-Related Constraints
Consider the meaning of size-related
shape changes in the skull of this Triassic
dinosaur
6
Size-Related Constraints
Consider the meaning of size-related
shape changes in this modern mammal
7
Size-Related Constraints
Note how the complexity of these changes masks a
simple underlying geometric transformation
8
Types of Form Variation

• Position - object centroids located at different
  positions
• Rotation - corresponding point locations oriented
  in different directions
• Size - a co-ordinated, constant or proportional
  metric increase or decrease in the spatial
  dimension of all parts of the form
• Shape - a localized, metric increase or decrease
  in spatial dimension

9
Expected Pattern of Form Variation
10
Analysis of Form Variation
Consider the cuboids
Surface Area Length2
Volume Length3
Surface Area Volume2/3
11
Analysis of Form Variation
Area Length2
12
Relative Growth
In the early 1900s Julian Huxley noticed that,
when plotted on logarithmically ruled paper, the
pattern of size increase for structures in a
large number of animals and plants looked
remarkably simple.
13
Analysis of Allometry
Log Area 2(Log Length)
Area Length2
14
Examples of Allometry
from Roth (1990)
15
Examples of Allometry
Mammals
from Van Valkenburgh (1990)
16
Examples of Allometry
Mammals
from Van Valkenburgh (1990)
17
Examples of Allometry
from McMahon Bonner (1983)
18
Examples of Allometry
from McMahon Bonner (1983)
19
Examples of Allometry
from McMahon Bonner (1983)
20
Examples of Allometry
from McNab (1990)
from Martin (1990)
21
Allometry
The study of the influence of body size on form
and function
22
Types of Allometry
Static Allometry The analysis of allometry
between different individuals of the same species
at the comparable levels of development
23
Types of Allometry
Ontogenetic Allometry The analysis of allometry
in an individual over the course of different
developmental stages
24
Types of Allometry
Evolutionary Allometry The analysis of allometry
between individuals of different sister species
at comparable developmental stages
25
Allometry Nomenclature
Positive Allometry Slope gt 1.0
Isometry Slope 1.0
Negative Allometry Slope lt 1.0
26
Example Radiolaria
Descriptive Morphology Morphological Integration
MacLeod et al. 1986
27
Example Radiolaria
Descriptive Morphology Morphological Integration
28
Example Radiolaria
Descriptive Morphology Morphological Integration
29
Example Foraminifera
Descriptive Morphology
30
Example Irish Elk
Evolutionary Trends Targets of Selection
31
Example Brontotheres
Evolutionary Trends Targets of Selection
32
Heterochrony
The study of changes in the relative timing of
appearance and development rate for characters
present in ancestors and descendants (or sister
taxa)
33
Types of Heterochrony

• Paedomorphosis - changes in the differential
  growth rate or offset signal that cause adult
  descendant species to be morphologically similar
  to the juvenile forms of ancestors
• Peramorphosis - changes in the differential
  growth rate or offset signal that cause adult
  descendant species to extrapolate the
  developmental trends of ancestors

34
What Type of Heterochrony?
In Human Evolution
35
What Type of Heterochrony?
Paedomorphosis
36
What Type of Heterochrony?
In Echinoid Evolution
37
What Type of Heterochrony?
Peramorphosis
38
Allometry Heterochrony
39
Developmental Trajectories
40
Allometry Heterochrony
41
