Title: Visualization Software Packages


1
Visualization Software Packages
  • Scott A. Klasky
  • PPPL
  • September 25, 2000

2
Outline
  • VDE2000, VDE2001
  • What is visualization?
  • Who cares?
  • Criteria to judge a visualization package.
  • Visualization Packages
  • Amira
  • AVS
  • AVS/Express
  • IDL
  • IRIS Explorer
  • OpenDX
  • PV3
  • SciRun
  • VisAD
  • VTK
  • Conclusions
  • Demo

3
VDE2000, VDE2001
  • VDE2000 April 27-28 2000
  • Held at PPPL with 152 people in attendance
  • http//w3.pppl.gov/vde2000
  • Goal was to provide audience with knowledge of
    the popular Visualization Development
    Environments.
  • The winners Amira and OpenDX
  • VDE2001 April 26 27 2001 LBNL/NERSC
  • Session 1
    Session 2
  • 9-2 Software vendor overview 9-11 What's
    new/changes vendors
  • 11-2
    University Vis. Tools
  • 2-6 User talks 2-4 Panel 1
    Defining Scientific

  • Visualization Benchmarks
  • 4-6 Panel 2
    Extensions to Vis.

  • packages for distributed

  • memory environments
  • Session 1
    Session 2
  • 9-12 User talks 9-12 Hardware
    vendors
  • 9-10 Poster Session
  • 1-5 Showdown

4
What is visualization?
  • Data Visualization is the process of representing
    data as a graphics display on a screen.
  • Visualization gives you
  • Insight into your data by allowing you to
    interact with your data.
  • Enables you to analyze and obtain new
    information.
  • Enables you to present your data with others.
  • Visualization tells the story of your data.
  • Good stories capture peoples attention, and make
    them ask questions to gain new insights.
  • Interaction with the data.
  • Visualization systems should allow us to interact
    with the data easily.
  • Rotations/Translations/Zooms, Time animations,
    etc. must be FAST!
  • Visualization Techniques
  • Isosurfaces
  • Volume Rendering
  • Slicing/Clipping
  • Extraction (3D-gt2D-gt1D)
  • Stream Lines

5
Who cares!
  • Back in the stone-age, researchers had X-terms
    which were incapable of scientific visualization.
  • In the future (days to come) we will have PCs
    with fast graphics cards!
  • The world will seem like a different and better
    place
  • New CAD (Dell machines) has changed the way the
    engineers are working.
  • 3D vis. Packages will be available on your
    desktop!
  • Your needs can be incorporated in what we do here
    for visualization!

6
Criteria to judge a visualization package
  • Quality of the Output
  • Accuracy of the output
  • Ex There are many isosurface routines which miss
    triangles,
  • Aesthetic quality of the output
  • Speed of Common Visualization Routines.
  • Isosurfaces, Streamlines
  • Contour Plots, Volume Rendering
  • Speed for rotations/translations/zooms.
  • Ease of Use
  • Need statistical sample of users
  • How many lines of code does it take to create
    everyday visualizations.
  • Number of Visualization and numerical modules
    available.
  • Cost

7
AMIRA
  • PPPL is in the process of obtaining the license
    (3000/node locked license) (AmiraDev), 1K for
    Amira 2.1 (non extendible).
  • At VDE2000, they showed the most impress 3d
    graphics.
  • Data Flow environment, with less tools than DX,
    Express, but the tools it includes are more
    powerfull.
  • 120 modules to visualize, analyze and process
    data.
  • TCL command language for scripting or vis.
    Network editing.
  • Extendible with the AmiraDev edition (will be
    available in a another week).
  • Extendible means that we can create new modules
    in the system.
  • Will be primary used at PPPL for end
    visualizations (not as much for everyday
    visualization, unless it proves to be extremely
    powerful.
  • Stereo Support

8
AVS
  • Not recommend by Muse/AVS if you have
    AVS/Express.
  • Similar to IRIS Explorer and IBM DX.
  • All 3 products came on the market about the same
    time (AVS was the first).
  • Does not have custom UI modules.
  • More difficult to use c.f. Express.
  • Does not support vector postscript output.
  • Not supported at PPPL
  • Stereo support
  • Demo

9
AVS/Express
  • AVS/Express is a multi-platform, component-based
    software environment building applications with
    interactive visualization and graphics features
  • We have 6 licenses (5 vis. editions), 1
    developers edition).
  • Solaris 2.7 (for Express 5.x). Solaris 2.6 (for
    express 4.2), Dec Unix, Linux (wait for Express
    5.5-gtsoon).
  • 5 licenses for 5K (Vis. Edition), 5K for 1
    developers license.
  • Stereo graphics support
  • Seems to be the most powerful visualization
    package here at PPPL.
  • 2x faster than DX for Xianzhu Tangs datasets.
  • Demo

10
IDL
  • Great imaging software.
  • Complex method of Visualization
    Non-pipeline-dataflow program.
  • Rendering Quality is not as good as other
    products.
  • Very difficult to program for visualizaton
    examples VDE2000data, VDE2000data2
  • Not considered a Vis. Product by Vis. Experts
  • Demo

11
IRIS Explorer
  • Best Quote from VDE2000, explorer used to be
    everybody's favorite when DX was not free and SGI
    IRIS Explorer was, now we are in trouble
  • Better than AVS, but still uses the same
    architecture. Memory is copied between modules.
  • Has a collaborative interface.
  • Stereo support
  • Link to NAG math routines.

12
OpenDX
  • Similar to AVS
  • Released to the open public May 18, 1999.
  • Is well tested, widely used.
  • SMP-thread based
  • Support is continuing for this product from the
    mailing lists.
  • Will be a PPPL supported Vis. Package.
  • Very good data model
  • Can run separate modules on separate computers.
  • Does not support vector postscript output.
  • DDX!!!!!!!!
  • Demo

13
PV3
  • More of a university product by Bob Haimes (MIT).
  • Built on top of PVM, and made to run on parallel
    computers.
  • It co-processes the visualization of data
    generated on a parallel computer.
  • Data generated from large scale scientific
    simulations can inflict huge burden on those
    tasked in assisting the scientist with
    understanding the results.
  • Data from one simulation can occupy terabytes of
    data. ? Compress the data so it can be
    visualized.
  • PV3 does not perform traditional scientific
    visualization on the data-set after it has been
    generated.
  • It deals with the volume of data concurrently
    with the solver.
  • PV3 works for parallel fluid simulations.
  • It contains all of the extraction tools used for
    these simulations including
  • geometric cuts
  • iso-surfaces
  • Streamlines
  • transient particle traces
  • These abstracts are stored on disk, and
    transferred to the vis. Machine.
  • Not easy to set up!

14
SciRun
  • Chris Johnson (Utah) is the creator of this code
  • Is trying to create this is a commercial product.
  • Is geared for medical researchers.
  • Scientific Programming environment
  • Provides for the construction, debugging and
    steering of large scale computer simulations
  • Extendible.
  • Visual Programming
  • Mainly used for Steering, where the simulation
    is built with tools in Scirun.
  • Runs on the Origin 2000, and other SGIs.

15
VisAD
  • Created by Bill Hibbard (Wisconsin).
  • Mainly used for weather applications.
  • Pure Java (Java2)
  • Uses Java3d and Java2d
  • Fully collaborative.
  • Fully platform independent (even runs on Macs.
    Sort of-gtOsX).
  • Supports computational steering.
  • Users must program in Java (or now Python) to get
    their vis.
  • Not for serious 3D visualization, but great for
    2d vis., and some 3d vis
  • Has a nice Visualization SpreadSheet program that
    lets you get nice visualizations without
    programming.

16
VTK (Kitware)
  • OpenSource
  • Used for 2d Imaging, 3d graphics and
    visualization.
  • Distinguishing feature is the integration of
    functionality, support of supercomputing and
    activie community support.
  • Designed as a toolkit (NOT A SYSTEM).
  • It is meant to be embedded into an application in
    combination with other tools.
  • VTKs core is in C
  • Wrapped with TCL/TK, Java, Python.
  • Contains the most advanced visualization
    routines, although the other products are already
    incorporating these in their products.
  • Contains streaming support, which allows VTK to
    handle large (Terabytes) data-sets.
  • PPPL (with Stanley Dunn) worked on Parallel VTK
    with Kitware and Los Alamos.
  • Results were poor, and we viewed this as
    difficult to use.
  • To use, we must have the VTK manual by our side
    to know the interface of modules.
  • Used mainly by vis. Experts.
  • Demo

17
Conclusions
  • PPPL supports the following vis. Packages.
  • IDL Bill Davis et. Al.
  • AVS/Express
  • Easy to add modules
  • Easy to program
  • fast!
  • AVS? but users should work with Express, since we
    will not continue our license for this product,
    since Express can use AVS networks.
  • OpenDX? DDX Its Free, and it uses SMP-gtthread
    based, and it will eventually run on parallel
    clusters.
  • VTK? If there parallel implementation gets better
    (a complete rewrite of their system), and if they
    start to build a visual front-end, then we will
    look into this product again.
  • Amira???? If it can produce sexy pictures easily,
    then we should pay attention to this product.
    Coming soon??? If congress allows us (no money in
    MS this year).
