NSIS NAT/FW NSLP Problem Statement and Framework

1
NSIS NAT/FW NSLPProblem Statement and Framework

• M. Brunner, Stiemerling, M. Martin (NEC), H.
  Tschofenig (Siemens), H. Schulzrinne (Columbia
  U.)

2
Objective

• Need for dynamically allocated pinholes or NAT
  bindings
• Application include VoIP, gaming, streaming
• application using other than well-known ports
• Applications doing application specific routing
  (e.g. SIP)
• Use path-coupled signaling for NAT and firewall
  traversal
• But not for IPsec related tunnel endpoint
  discovery.

3
Other solutions

• Application-specific Firewall and NAT
  implementation
• Midcom WG
• Use a protocol to dynamically configure a
  firewall/NAT
• Requires knowledge of the right NAT/Firewall(s)
• Shortcommings of pathdecoupled signaling

4
General View
NAT/FW NSLP
NTLP
IP
5
Various scenarios listed

• Define a set of use cases to understand the
  problem better
• FW/NAT related Scenarios
• Firewalls only
• NATs and firewalls
• Sending host behind a NAT,
• Receiving host behind a NAT,
• both behind a NAT
• Security related Scenarios
• Peer-to-peer trust relationship
• Intra-Domain trust relationship
• End-to-middle trust relationship

6
What a NAT/FW NSLP solves

• Topology problem -gt uses normal routing
• What firewalls/NATs need to get configured -gt
  only those on the data path
• Easily works for several FW/NAT in a row -gt find
  and configures them all
• Application independent -gt end-hosts and
  firewalls/NATs only must implement NSIS NTLP and
  NAT/FW NSLP

7
ProblemsTechnical

• Missing Network-to-Network Trust Relationship
• NATs from the outside -gt in general the
  destination IP address of the destination (NSIS
  responder) is unknown.
• Must deal with route changes quickly (data losses
  happen on the data path until the new FW is
  configured
• Determine the scenario a host is in

8
ProblemsDocument Handling

• Should the document cover
• the NAT handling of other NSLPs (e.g. QoS) be
  covered? (and interworking with them)
• interoperability with non-NSIS aware NATs
• solution specific aspects?

9
Conclusion

• An NSIS NAT/FW NSLP is an effective solution for
  NAT/FW traversal for dynamically setup data
  communication
• There are still a number of problems, which need
  to be resolved
• The work is part of the charter
• Adopt as WG draft?

10
A Solution for the Topology Problem
FW 1
FW 2
FW 4
FW 3
NSIS signaling
Host A
Host B
