Data Structures

1
Data Structures

• 5. Trees
• Chih-Hung Wang
• Fall 2009
• Textbook Ellis Horowitz, Sartaj Sahni and Dinesh
  P. Mehta. Fundamentals of Data Structures in C
  (Second Edition). Silicon Press, 2007.

2
Definition

• A tree is a finite set of one or more nodes such
  that
• There is a specially designated node called root.
• The remaining of nodes are partitioned into n?0
  disjoint sets T1, T2, , Tn, where each of these
  sets is a tree. T1, T2, , Tn are called the
  subtrees of the root.

3
A Simple Tree
The height or depth of a tree is defined to
be maximum level of any node in tree.
The roots of the subtrees of a node X are the
children of X. X is the parent of its children.
The ancestors of a node are all the nodes along
the path from the root to that node.
LEVEL 1 2 3 4
Children of the same parent are said to be
siblings
Degree the number of subtrees of a node degree
of A 3. The degree of a tree is the maximum of
the degree of the nodes in the tree Nodes that
have degree zero are called leaf or terminal
node Others nonterminals
4
Representation of Trees

• List representation
• Figure 5.2 (A(B(E(K,L)F),C(G),D(H(M),I,J)))

5
Left Child-Right Sibling Representation
data
Left child
right sibling
6
Representation as a Degree-Two Tree

• Rotate the right-sibling pointers in a left
  child-right sibling tree clockwise by 45 degrees.

are also known as binary tree
7
Two Ways of Tree Representations
left child-right sibling tree
tree
binary tree
8
Binary Tree
templateltclass Tgt class BinaryTree // Object A
finite set of nodes either empty or consisting of
a // root node, left BinaryTree and right
BinaryTree. public BinaryTree() // creates an
empty binary tree bool IsEmpty() // return
true iff the binary tree is empty BinaryTree(Bina
ryTreeltTgt bt1, T item, BinaryTree ltTgt
bt2) // creates a binary tree whose left
subtree is bt1, whose right subtree
// is bt2, and whose root node contains
item BinaryTreeltTgt LeftSubtree() // return the
left subtree of this BinaryTreeltTgt
RightSubtree() // return the right subtree of
this T RootData() // return the data in the
root node of this

• ADT of binary tree

9
Skewed and Complete Binary Tree
10
Properties of Binary Trees

• Lemma 5.2 Maximum number of nodes
• The maximum number of nodes on level i of a
  binary tree is 2i-1, i?1.
• The maximum number of nodes in a binary tree of
  depth k is 2k-1, k?1.

11
Lemma 5.3

• Relation between number of leaf nodes and
  degree-2 nodes
• For any non-empty binary tree, T, if n0 is the
  number of leaf nodes and n2 the number of nodes
  of degree 2, then n0 n2 1.
• Definition A full binary tree of depth k is a
  binary tree of depth k having 2k 1 nodes, k
  0.

12
Full Binary Tree and Complete Binary Tree

• Definition A binary tree with n nodes and depth
  k is complete iff its nodes correspond to the
  nodes numbered from 1 to n in the full binary
  tree of depth k.

13
Array Representation (1)

• Lemma 5.4 If a complete binary tree with n nodes
  is represented sequentially, then for any node
  with index i, 1 i n, we have
• parent(i) is at if i ?1. If i 1, i is
  at the root and has no parent.
• leftChild(i) is at 2i if 2i n. If 2i gt n, then
  i has no left child.
• rightChild(i) is at 2i 1 if 2i 1 n. If 2i
  1 gt n, then i has no right child.

14
Array Representation (2)
Figure 5.10(b)
Figure 5.10(a)
15
Linked Representation (1)
template ltclass Tgt class Tree //forward
declaration template ltclass Tgt class TreeNode
friend class Tree ltTgt private T
data TreeNode ltTgt leftChild TreeNode ltTgt
rightChild template ltclass Tgt class
Tree public // Tree operations . private Tre
eNode ltTgt root
16
Linked Representation (2)
for Figure 5.10
17
Binary Tree Traversal

• If we adopt the convention that we traverse left
  before right--three traverals LVR (inorder), LRV
  (postorder), and VLR (preorder).
• Inorder
• Preorder
• Postorder

18
Inorder/Infix form

• A/BCDE

19
Inorder Traversal of a Binary Tree

• 1 template ltclass Tgt
• 2 void Tree ltTgtInorder()
• 3 // Driver calls workhorse for traversal of
  entire tree. The driver is
• 4 // declared as a public member function of
  Tree.
• 5 Inorder(root)
• 6
• 7 template ltclass Tgt
• 8 void Tree ltTgtInorder(TreeNode ltTgt
  currentNode)
• 9 // Workhorse traverses the subtree rooted at
  currentNode
• 10 // The workhorse is declared as a private
  member function of Tree
• 11 if (currrentNode)
• 12 Inorder(currentNode?leftChild)
• 13 Visit(currentNode)
• Inorder(currentNode?rightChild)
• 15
• 16

20
Trace of Program 5.1
21
Preorder Traversal

• /ABCDE

22
Postorder Traversal

• AB/CDE

23
Iterative Inorder Traversal
24
Analysis of NonrecInorder

• Every step will be executed no more than some
  constant times n, so the time complexity is O(n).

25
Inorder Iterator Class (1)
26
Inorder Iterator Class (2)
27
Level-Order Traversal

• Like the order of Figure 5.11
• Use a queue

28
Additional Binary Tree Operations (1)

• Copying Binary Trees

29
Additional Binary Tree Operations (2)

• Testing Equality
• Textbook page 270

30
Additional Binary Tree Operations (3)

• The Satisfiability Problem

not before and before or
Time cimplexity to determine the
satisfiability O(2n)
Evaluation using postorder
31
First Version of Satisfiability Algorithm
32
Visiting a Node in an Expression Tree
33
Threaded Binary Trees (1)

• 0 rightChild field
• Pointer to the node that would be visited after p
  when traversing the tree in inorder.
• 0 leftChild field
• Pointer to the node that immediately precedes
  node p in inorder.

34
Threaded Binary Trees (2)
Empty threaded binary tree
35
Threaded Binary Trees (3)

• Memory representation

root
36
Finding the Inorder Successor
T ThreadedInorderIteratorNext () // Return
the inorder successor of currentNode in a
threaded binary tree ThreadedNode ltTgt temp
currentNode ? rightChild if (!currentNode ?
rightThread) while (!temp ? leftThread) temp
temp ? leftChild currentNode temp if
(currentNode root) return 0 else return
currentNode ? data
Right ? Left Most
37
Inserting a Node
before
after
38
Insertion Rule

• If s has an empty right subtree, then the
  insertion is simple and diagram in Figure
  5.23(a).
• If the right subtree of s is not empty, then this
  right subtree is made the right subtree of r
  after insertion. When this is done, r becomes the
  inorder predecessor of a node that has a
  leftThreadtrue field, and consequently there is
  an thread which has to be updated to point to r.
  The node containing this thread was previously
  the inorder successor of s. Figure 5.23(b)
  illustrates the insertion for this case.

39
Inserting r as the Right Child of s
template ltclass Tgt void ThreadedTree
ltTgtInsertRight (ThreadedNode ltTgt s,
ThreadedNode ltTgt r)// Insert r as the right
child of s. r ? rightChild s ? rightChild r
? rightThread s ? rightThread r ? leftChild
s r ? leftThread True // leftChild is a
thread s ? rightChild r s ? rightThread
false if (! r ? rightThread) ThreadedNode
ltTgt temp InorderSucc (r)
// returns the inorder successor of r temp ?
leftChild r
40
Heaps

• Priority queue
• The element to be deleted is the one with highest
  (or lowest) priority.
• An element with arbitrary priority can be
  inserted into the queue.
• See Example 5.1

41
A Max Priority Queue ADT
template ltclass Tgt class MaxPQ public virtual
MaxPQ () // virtual destructor virtual
bool IsEmpty () const 0 // return true iff
the priority queue is empty virtual const T Top
() const 0 // return reference to max
element virtual void Push(const T) 0 //
add an element to the priority queue virtual
void Pop () 0 // delete element with max
priority
42
Max Heap (1)

• Definition A max (min) tree is a tree in which
  the key value in each node is no smaller (larger)
  than the key values in its children (if any). A
  max heap is a complete binary tree that is also a
  max tree. A min heap is a complete binary tree
  that is also a min tree.

43
Max Heap (2)
Max heaps
Min heaps
44
Max Heap (3)

• Private
• T heap // element array
• int heapSize // number of elements
  in heap
• int capacity //size of the array
  heap

template ltclass Tgt MaxHeapltTgtMaxHeap (int
theCapacity 10) if ( theCapacity lt 1 ) throw
Capacity must be gt 1. capacity
theCapacity heapSize 0 heap new T
capacity 1 // heap 0 is not used
45
Insertion into a Max Heap (1)
Height log(n1)
O(logn)
46
Insertion into a Max Heap (2)
Template ltclass Tgt void MaxHeapltTgtPush(const T
e) // Insert e into the max heap if
(heapSize capacity) // double the capacity
ChangeSize 1D(heap, capacity, 2capacity)
capacity 2 int currentNode
heapSize while (currentNode ! 1
heapcurrentNode / 2 lt e) // bubble up
heapcurrentNode heapcurrentNode / 2 //
move parent down currentNode /
2 heapcurrentNode e
47
Deletion from a Heap (1)
O(logn)
48
Deletion from a Heap (2)
Template ltclass Tgt void MaxHeapltTgtPop() //
Delete max element if (IsEmpty ()) throw
Heap is empty. Cannot delete. heap1.
T() // delete max element // remove last
element from heap T lastE heapheapSize--
49
Deletion from a Heap (3)
// trickle down int currentNode 1 // root int
child 2 // a child of currentNode while
(child lt heapSize) // set child to larger
child of currentNode if (child lt heapSize
heapchild lt heapchild 1) child //
can we put lastE in currentNode? if (lastE gt
heapchild) break // yes // no
heapcurrentNode heapchild // move child
up currentNode child child 2 // move
down a level heapcurrentNode lastE
50
Binary Search Tree

• Binary search tree has a better performance than
  any of the data structures when the functions to
  be performed are search, insertion, and deletion.
• Definition A binary search tree is a binary
  tree. It may be empty. If it is not empty then it
  satisfies the following properties
• Every element has a key and no two elements have
  the same key (i.e., the keys are distinct)
• The keys (if any) in the left subtree are smaller
  than the key in the root.
• The keys (if any) in the right subtree are larger
  than the key in the root.
• The left and right subtrees are also binary
  search trees.

51
BST and Not BST
Not BST
52
Searching a BST
template ltclass K, class Egt // Driver pairltK, Egt
BSTltK, Egt Get(const K k) // Search the
binary search tree (this) for a pair with key
k. // If search a pair is found, return a
pointer to this pair otherwise, return 0.
return Get(root, k) template ltclass K, class
Egt // Workhorse pairltK, Egt BSTltK, Egt
Get(TreeNode ltpair ltK, Egt gt p, const K k)
if (!p) return 0 if (k lt p?data.first)
return Get(p?leftChild, k) if (k gt
p?data.first) return Get(p?rightChild, k)
return p?data
O(h) h BST with height h
Recursive search of a binary search tree
53
Iterative Search of a BST
template ltclass K, class Egt // Iterative
version pairltK, Egt BSTltK, Egt Get(const K
k) TreeNode lt pairltK, Egt gt currentNode
root while (currentNode) if (k lt
currentNode ?data.first) currentNode
currentNode ?leftChild else if (k gt
currentNode ?data.first) currentNode
currentNode ?rightChild else return
currentNode ?data // no matching
pair return 0
54
Searching a BST by Rank
template ltclass K, class Egt // search by
rank pairltK, Egt BSTltK, Egt RankGet(int r) //
Search the binary search tree for the rth
smallest pair. TreeNode lt pairltK, Egt gt
currentNode root while (currentNode)
if (r lt currentNode ?leftSize) currentNode
currentNode ?leftChild else if (r gt
currentNode ?leftSize) r -
currentNode ?leftSize currentNode
currentNode ?rightSize else
return currentNode ?data return 0
If we wish to search by rank, each node should
have additional field leftsize.
O(h) h BST with height h
55
Example of Searching a BST by Rank
26
Leftsize13
41
17
47
30
14
21
38
28
22
19
10
16
20
7
12
35
39
15
3
Find 17th smallest node
56
Insertion into a BST (1)
57
Insertion into a BST (2)
template ltclass K, class Egt void BSTltK, E gt
Insert(const pairltK, E gt thePair) // Insert
thePair into the binary search tree // search
for thePair.first, pp is parent of p TreeNode
lt pairltK, Egt gt p root, pp 0 while (p)
pp p if (thePair.first lt p
?data.first) p p ?leftChild else if
(thePair.first gt p ?data.first) p p
?rightChild else // duplicate, update
associated element p ?data.second
thepair.second return // perform insertion p
new TreeNodelt pairltK, Egt gt (thePair) if (root)
// tree not empty if (thePair.first lt pp
?data.first) pp?leftChild p else
pp?rightChild p else root p
58
Deletion from a BST (1)
The node has one child The node has two children
59
Deletion from a BST (2)
z has only one child
60
Deletion from a BST (3)

• z has two children
• Delete the replacing element
• Largest element in the left subtree
• Smallest element in the right subtree

61
Selection Tree

• Winner Trees
• A winner tree is a complete binary tree in which
  each node represents the smaller of its two
  children.
• Analysis of merging runs using winner trees.
• The time to restructure the tree is
• The time to merge all n records is

62
Winner Tree for k8
run 1 run2 run3 run4 run5
run6 run7 run8
63
Restructure of Tree
run 1 run2 run3 run4 run5
run6 run7 run8
64
Loser Trees
65
Forests

• Definition
• A forest is a set of n 0 disjoint trees.
• If we remove a root from a tree, we obtain a
  forest. For example, removing the root of any
  binary tree produces a forest of two trees.

66
Three-tree Forest
67
Transforming a Forest into a Binary Tree

• Definition If T1, , Tn is a forest of trees,
  then the binary tree corresponding to this
  forest, denoted by B(T1, , Tn),
• is empty if n 0
• has root equal to root (T1) has left subtree
  equal to B(T11, T12,, T1m), where T11, T12,,
  T1m are the subtrees of root (T1) and has right
  subtree B(T2, , Tn).

68
Binary Tree Representation of Forest
69
Disjoint Sets

• Disjoint set union If Si and Sj are two disjoint
  sets, then their union Si ?Sj all elements x
  such that x is in Si or Sj.

70
Sets Union
71
Data Representation for the Sets
72
Class Definition
class Sets public // set operations
follow . . private int parent
int n // number of set elements SetsSets(int
numberOfElements) if (numberOfElements lt
2) throw Must have at least 2 elements. n
numberOfElements parent new intn
fill(parent, parent n, -1)
73
Simple Functions for Union and Find
void SetsSimpleUnion(int i, int j) // Replace
the disjoint sets with roots i and j, i ! j with
their union parenti j int
SetsSimpleFind(int i) // Find the root of the
tree containing element i. while (parenti
gt 0) i parenti return i
74
Analysis of SimpleUnion and SimpleFind

• Union can be proceed in time O(n)
• Find can be performed in time O(n2)

75
Weighted Union

• Definition
• Weighting rule for Union(i, j) If the number
  of nodes in the tree with root i is less than the
  number in the tree with root j, then make j the
  parent of i otherwise make i the parent of j.

76
Trees Obtained Using the Weighting Rule
77
Union Function
void SetsWeightedUnion(int i, int j) // Union
sets with roots i and j, i?j, using the weighting
rule. // parenti -counti and parentj
-countj int temp parenti
parentj if (parenti gt parentj) // i
has fewer nodes parenti j
parentj temp else // j has fewer
nodes (or i and j have the same number of nodes)
parentj i parenti temp

78
Lemma 5.5

• Assume that we start with a forest of trees, each
  having one node. Let T be a tree with m nodes
  created as a result of a sequence of unions each
  performed using function WeightedUnion. The
  height of T is no greater than .

79
Example 5.3 (I)
(a) Initial height-1 trees
(b) Height-2 trees following Union (0,1), (2,3),
(4,5) and (6,7)
80
Example 5.3 (II)
(c) Height-3 trees following Union (0,2) and (4,6)
(d) Height-4 tree following Union (0,4)
81
Collapsing Rule

• If j is a node on the path from i to its root and
  parenti? root(i), then set parentj to root(i).

82
Example 5.4 (I)

• See Example 5.3
• Perform Find(7), Find(7), , Find(7)
• Eight times
• 24 moves before collapsing
• 13 moves after collapsing

83
Example 5.4 (II)
-8
-8
0
0
2
4
2
6
1
7
1
4
5
3
3
5
6
After collapsing
7
Before collapsing
373 reset three parents
84
Collapsing Find
int SetsCollapsingFind(int i) // Find the root
of the tree containing element i // Use the
collapsing rule to collapse all nodes from i to
the root for (int r i parentr gt 0 r
parentr) // find root while (i ! r) //
collapse int s parenti
parenti r i s return r
