Board Replacement for Engineered GlueDown HardWood Floors

1
Board Replacement for Engineered Glue-Down
HardWood Floors
2
Why Replace a Board?

• Damage to existing board
• Manufacturing defect
• Aesthetic changes

3
Tools to be Used
4
Layout the Areas to be Cut

• With a marking pen layout the areas to be cut
• approximately ½ from the side joints

5
Drill Holes at the Corners to Prevent Damage to
Adjoining Boards
6
Cutting the Areas Marked

• Care must be taken not to cut into adjoining
  boards

7
Setting the Saw to cut the thickness of the board
8
Make a Cut Down the Center for Easy Removal
9
Carefully Remove the End Pieces
10
Release the Remaining ½ of the Edge Loose from
the Adhesive
11
Clean any Remaining the Adhesive to a Thin Residue
12
Mark the Replacement Board to Length
13
Cut the Board to Length
14
Remove the Bottom of the Groove on the Side and
End
15
Apply the Adhesive to the Back of the Material
with a Notched Spreader
16
Optional Place a Bead of Glue on the Top of the
Tongue
17
Insert the Tongue and Drop into Place
18
Clean and Fill as Necessary
19
Weight Overnight if Necessary
