IMRT For Prostate Cancer

1
IMRT For Prostate Cancer
2
Prostate CancerSeveral Basic Postulates

• Dose escalation is important
• Prostate is a moving target
• It needs to be hit with high precision every day
• DVH assessment
• Seminal vesicles to treat or not to treat

3
Dose Escalation Is Important
M.D.Anderson figures 78 vs. 70Gy
4
Some Images from Internet Sites
University of Nebraska internet site
Variantm Website
5
The Prostate Is a Moving Target
6
Margins
Margins 0.7cm LR 0.7cm SI 1.1cm AP
Antolac at al, IJROBP,42661, 1998
7
What Could the IMRT Offer?

• Wraps the isodoses around critical structures

8
Rectal Sparing
95
9
What Is Rectum and How The Definition Is
Related to the DVH
Solid organ Hollow
organ
IMRT
95
95
95
3D
95
10
DVH Is a Form of Statistics
11
The Way Ahead

• More sophisticated planning
• 3D (4 field brick is not good enough)
• IMRT
• when seminal vesicles to be treated
• Daily verification is more important

12
Daily Verification Cone Beam Reconstruction

• Megavoltage CBR - Siemens
• MVision Megavoltage Cone Beam Imaging
• No extra attachments
• Dose per image 8MU
• Flat panel dependent

Orthovoltage CBR - Siemens Varian Additional
low energy system Better soft tissue
definition Lower dose per image Higher BED
13
Fan vs. Cone Beam Reconstruction
detectors
detectors
14
Cone Beam Uses Cone Beam of X-rays
This is volume acquisition All slices are
obtained in one go Actually slices do not
exist Single gentry rotation 210 degrees
(270-110)
15
45 Seconds

• Uses the standard imaging plate
• Higher dose - better image
• Beautiful images - 15MU
• Useful images - 8MU
• With experience - 4MU

16
Cone Beam Images are Good Enough for RT Planning

• Good CT density representation
• Metal hips are not a problem (pair production)
• Only problem - no patients contour (small field
  of view)

17
Megavoltage Cone Beam ImagesMVision
Megavoltage Cone Beam Imaging
18
Megavoltage Cone Beam ImagesMVision
Megavoltage Cone Beam Imaging
Seeds Insertion
19
Cone Beam Image Dose Distribution

cone beam
original plan
no optimization
simple optimization
20
Dose Escalation by Being More Accurate

• Prostate tumors stay posteriorly
• We are missing the tumor in at least 10 of the
  cases even with 1cm post margin
• Assuming daily verification eliminates the
  geographical miss
• By daily verification affectively we are
  increasing the tumor dose with 10
• Rectal dose would be the same or lower

21
Summary

• The jury is still out on the role of IMRT in
  prostate cancer
• IMRT plans should be compared with good 3D plans
• Protons treatment becomes strongly promoted
  alternative
• IMRT certainly is very helpful for RT to the
• Seminal vesicles
• Pelvic nodes
• Pelvic nodal treatment is used less and less
• There is huge monetary drive behind IMRT in
  prostate cancer
• Daily verification is the next big thing in
  prostate radiotherapy

22
(No Transcript)
23

• This presentation is done with close co-operation
  with
