SABINE Navigator System Processors

1
SABINE Navigator System Processors
Tired of the same old drag and drop?
2
SABINE Navigator System Processors
Simplicity
Flexible Control
Unlimited DSP Power
3
SABINE Navigator System Processors
Loudspeaker Controller
Matrix Mixer
Signal Router
4
SABINE Navigator System Processors
All at a price you can sell!
5
SABINE Navigator System Processors
NAV3600
NAV4800
NAV8800
6
SABINE Navigator System Processors
Simplicity
Ready to use instantly plug and go No
complicated menus or protocols Fixed system
architecture Presets give you a fast start
7
SABINE Navigator System Processors
Flexible Control
Front panel access to all functions Instant
channel linking from front panel Intuitive
software Network control Serial and
Ethernet remotes
8
SABINE Navigator System Processors
Unlimited DSP Power
All functions run concurrently No DSP
meters No worrying about DSP budget
9
SABINE Navigator System Processors
Speaker Controller
Superior sound quality Crossovers with three
filter types, slopes to 48 dB Delay for
drivers and clusters Sets of 30 presets
Live sound production audio
10
SABINE Navigator System Processors
Matrix Mixer
Superior sound quality Churches, schools,
corporate Presets for multi-purpose rooms
Security and front panel access Controller for
room combining
11
SABINE Navigator System Processors
Signal Router
Superior sound quality Any input to any
output Three gain stages Presets for
routing changes Remote control switching
12
SABINE Navigator System Processors
Navigator Advantages

• Delay 450 ms on each input and output
• EQ 6 PEQ per I/O, plus 8 FBX per input
• Manage Gain Comp/Limiter on each I/O
• Nav3600 The only 3x6 at this price point
• Navigator Networks
• FBX Feedback Exterminator

13
SABINE Navigator System Processors
FBX Feedback Exterminator

• The original and the best
• Transparent does nothing to your sound
• Superior speed, resolution, and accuracy
• Maintains sonic integrity of your system
• Adjust the algorithm to suit your application

14
SABINE Navigator System Processors
Scenario Eight channels of feedback control is
specified using a complicated drag drop box
Resource hungry
Expensive
Less effective at feedback control
15
SABINE Navigator System Processors
FBX Feedback Exterminator
No problem with DSP resources
No extra charge!
8 SOLOs cost the same as one NAV8800!
The most effective feedback controller
16
SABINE
NAVIGATOR The new direction in sound system
control..
Loudspeaker Controller Matrix Mixer Signal
Router
Simple Flexible Control Unlimited DSP Power
