1
Civil Engineering Construction
  • By Prof. Jin-an Wang
  • USTB 2009. 09

2
CHAPTER 7 Structural Steel Frame
  • Outline
  • Structural Steel Shapes
  • Principles of Structural Steel Frames
  • Structural Steel Connections
  • Erection of Steel Frame
  • Preengineered Structural Steel Frames
  • Construction Procedures and Practices
  • Review Questions

3
Introduction
  • The use of structural steel in the construction
    of building frames was the beginning of a new
    concept in building design, the high-rise or
    multistory building.
  • Because of its versatility and strength as a
    building material, steel has become one of the
    dominant materials in the construction industry.

Steel Frame High-Rise Office Building
4
  • The properties of steel for use in building
    frames.
  • High strength to weight ratio
  • Ductile
  • Equally strong in compression and in tension
  • Can be formed and fabricated into any shape
  • To enhance the performance of concrete and timber
    as structural materials.

5
7.1 Structural Steel Shapes
  • W (wide flange)
  • HSS (hollow structural sections)
  • WT (tees cut from wide flange sections)
  • S (standard I sections)
  • Angle (equal leg and unequal leg)
  • C (channels)
  • HP (I-shaped pile sections)
  • Plate.

6
7.1 Structural Steel Shapes
7
7.2 Principles of Structural Steel Frames
  • The structural steel frame must be considered
    from two points of view
  • (1) the strength of the individual sections that
    make up the frame
  • (2) the overall stability of the frame.
  • The stability of any structure is contingent on
    the arrangement of the framing members and the
    type of connections used to fasten them together.

8
7.2 Principles of Structural Steel Frames
  • Structural steel frames can be categorized into
    two basic types
  • Braced frames some type of lateral bracing is
    used to prevent horizontal movement of the frame.
  • Unbraced frames the stiffness of the
    load-carrying sections in the assembled frame
    must resist the horizontal movement that is
    anticipated.

9
7.2 Principles of Structural Steel Frames
  • The connections between the framing members can
    be considered as
  • Pin-type connections are flexible and allow
    rotation to occur between the connected members
    when deflections occur due to applied loads.
  • Rigid or moment-resisting connections add
    stability to the frame by their ability to resist
    the rotation that occurs between the frame
    sections when the frame is under the influence of
    lateral loads.

10
Unbraced Structural Steel Frame
11
Tension Cross-Bracing in a Braced Frame
  • This type of bracing allows for load reversals
    and ensures that stability is provided in both
    directions.
  • The removal of one of these braces will produce
    instability in the frame because tension braces
    are not designed to resist compression loads

12
Rigid Frame Structural Steel Building Frame
  • Where moment-resisting connections are used,
    bracing can be eliminated.
  • An unbraced frame develops its stability through
    its rigid connection at the haunch.
  • The connections used to join the bents to one
    another are considered to be pin type, and
    bracing is required along the length of the
    building to ensure stability in that direction.

13
  • In a three-dimensional structure, to ensure
    stability in all directions, the bracing must be
    provided in both planes of the structure.
  • In some cases, masonry walls or reinforced
    concrete stairwells are used to provide lateral
    stability.
  • Many structural steel frame buildings, especially
    multistory buildings, use a reinforced concrete
    core to provide the necessary resistance to
    lateral forces. Lateral forces are transferred
    through the floor slabs by diaphragm action to
    the core, which in turn transfers these loads
    into the foundations.

14
Particular attention must be given to the
stability of the frame during the construction
phase !
15
7.3 Structural Steel Connections
  • The two most common methods used for connecting
    steel members in structural steel frames are
    bolting and welding.
  • Welded connections are usually less expensive
    when done in the shop under controlled
    conditions
  • Bolted connections are usually better suited to
    field conditions.

16
Bolts (???)
  • Structural bolts may be classified according to
    type of thread, type of steel, steel strength,
    shape of head and nut, and type of shank.
  • Two types of bolted connections are used in
    structural steel connections bearing type and
    friction type.

17
(1) Bearing-type connection
  • The bolted parts bear on the shank of the bolt,
    thus using the bolt as a direct means of
    transferring load from one part to the other.
  • Bearing-type connections are used in locations
    where the applied load acts primarily in one
    direction without much variation in magnitude.

18
(2) Friction-type Connections
  • They transfer load from one member to the other
    by means of the friction developed between the
    connected surfaces.
  • The bolt acts as a clamp only and is not used in
    the transfer of load from one member to the other
    as in the bearing-type connection.
  • Because the friction between the connected parts
    determines the capacity of the connection, no
    movement in the connection is expected.
  • This type of connection can be used where the
    load direction varies without producing any
    undesirable effects on the connection.

19
The bolts in all bolted connections must be
properly tightened to produce good results.
Tightening High-Strength Bolts with Torque Wrench
Pneumatic Impact Wrench
20
Welds(??)
  • Two types of welds are most often used in welded
    connections the fillet weld and the groove or
    butt weld.

21
Typical Welded Joints
22
7.4 Erection of Steel Frame
  • (1)Anchor Bolts
  • The successful erection of a steel frame depends
    on the proper positioning of the anchor bolts
    that will tie the frame to the foundation.
  • They are cast into the concrete foundation to
    hold the first members of a steel frame to be
    placedthe column bearing plates.
  • The anchor bolts must be positioned carefully,
    according to the plans, so that the bearing
    plates can be lined up accurately.

23
Anchor Bolts and Hairpins Anchor
24
  • (2)Bearing Plates
  • The column bearing plates are steel plates of
    various thicknesses in which holes have been
    drilled to receive the anchor bolts.
  • The holes are slightly larger than the bolts so
    that some lateral adjustment of the bearing plate
    is possible.
  • The angle connections by which the columns will
    be attached to the bearing plates are bolted or
    welded on them.

25
Column Bearing Plates
Fig. 7-13 Column Bearing Plates
Fig. 7-14 Leveling Base Plates
26
(3)Columns
  • First-tier columns are the next group of members
    to be erected. They are often two stories long or
    in any case, the same size for at least two
    stories.
  • Column lengths are such that splices will come
    450 to 600 mm above the floor levels, which is
    done to prevent splice connections from
    interfering with girder or beam-to-column
    connections.
  • Column ends are milled to exactly the right
    length and to make sure that column loads will be
    evenly distributed over the entire bearing area.

27
Shape of Column
  • HP shapes, as nearly square in cross section as
    possible,are often chosen for columns.
  • Round or square HSS sections may also be used,
    though the round column may present some
    connecting problems.
  • Columns may also be built up by welding or
    bolting a number of other rolled shapes into a
    single unit.

28
(4)Column Splices
  • Column sections are joined together by splice
    plates that are bolted or welded to the column
    flanges and, in special cases, to the webs.
  • If the column flanges match reasonably well, it
    is common to butt the column ends directly and
    join the column sections with splice plates.
  • When the columns are of different sizes, a plate
    is used between the two column ends to provide
    bearing for the smaller column.

29
(5)Girders
  • Girders, the primary horizontal members of a
    flame, span from column to column and support the
    intermediate floor beams.
  • They carry wall and partition loads and the point
    loads transmitted to them by the beams.
  • Rolled W shapes or three-plate welded I shapes
    are normally used as girders.
  • Connections between girders and columns can be
    either pin-type connections or moment resisting
    connections.

30
Pin-Type Connections
  • Pin-type connections are designed to resist
    vertical loads only.
  • These connections consist of angles or plates
    bolted or welded to the girder web and usually
    bolted to the supporting column flange or web.

(a) Double-Angle Bolted Connections (b)
End-Plate Connection (c) Seated Connection.
31
Pin-Type Connections
  • Pin-type connections cannot resist lateral loads.
    They provide no lateral stability to the
    structural frame.
  • Cross-bracing, shear walls, or a concrete core
    must be used to absorb the effects of lateral
    forces and to provide the necessary stability.

32
Moment Connections
  • Building frames that are designed as rigid frames
    that depend on the stiffness of the column
    sections to provide lateral stability use
    moment-resisting connections.
  • Moment connections between the girders and the
    columns provide lateral stability in the
    structural frame by preventing rotation between
    the girders and the columns.
  • Moment connections may be welded, bolted, or a
    combination of bolts and welds.

33
Moment Connections
34
(6)Beams
  • Beams, generally smaller than girders, may be
    connected to either a column or a girder.
  • Beam connections at a column are similar to the
    girder-to-column connections.
  • In beam-to-girder connections, the main
    consideration is the shear connection, because
    the beams are considered to be carrying the floor
    loads and transferring them to girders as
    vertical loads.

35
Floor Beams Framed between Girder Flanges
  • The simplest is to frame the beam between the top
    and bottom flanges of the girder.

36
Coped and Blocked Beam Ends
  • If the top or bottom flanges of girders and beams
    will be flush, it is necessary to cut away a
    portion of the upper or lower beam flange.
  • If the girder is an S shape, the end of the beam
    is coped, whereas if it is a W shape, the end is
    blocked.
  • In many cases, the shear connection angles are
    bolted or welded to the beam ends in the shop,
    and the member comes to the job ready for
    connection to the girder web.

37
(7)Channels and Angles
  • Channels and angles, because of their shape,
    light weight, and wide range of sizes, have many
    different uses in the structural frame.
  • Channels are usually used as secondary framing
    members when loads and spans are not too great.

38
(7)Channels and Angles
  • They are used as wall girts and roof purlins,
    girts being the horizontal members attached to
    the columns to support siding and purlins being
    the roof framing members spanning between the
    roof beams and supporting the roof deck.
  • Other uses for channels are as
  • framing for doors and windows
  • stair stringers
  • web and chord members in trusses
  • built-up sections (eave struts and spandrel beams)

39
7.4 Construction Procedures and Practices
  • There are two distinct stages in the construction
    of a steel frame.
  • The first stage is performed in the shop where
    the individual pieces are cut to length, coped or
    blocked, and punched or drilled for bolts. Detail
    material such as gusset plates, clip angles, and
    end plates for beams are attached so that the
    connections in the field can be made quickly.

40
7.4 Construction Procedures and Practices
  • The second stage begins when the fabricated steel
    arrives on the site.
  • The field crew, with the aid of a crane,
    assembles the individual pieces according to the
    erection drawings.
  • The connections are aligned with drift pins, and
    temporary bolts are used to hold the sections
    together.

41
7.4 Construction Procedures and Practices
  • The building is plumbed using a building transit
    and held in alignment with temporary cable
    bracing equipped with turnbuckles (to allow for
    adjustments) until permanent bracing has been put
    in place and final bolting and welding have been
    completed.
  • The final stages of completing a bolted
    connection--removal of a drift pit that was used
    to align the bolt holes--so that the final
    structural bolt can be put in place.

42
Structural Steel Floor Frames Hang from Straps
  • The conventional methods of steel erection,
    beginning at the bottom and working up, do not
    always apply. Unusual designs sometimes require
    unorthodox erection schemes to be used.

43
Some general safety rules
  • 1. Do not attempt steel erection on rainy days.
    It is dangerous to work on wet steel.
  • 2. Wear shoes with sewn leather or rubber soles.
  • 3. Do not allow anyone to stand beneath a load
    boom.
  • 4. Do not allow anyone to ride a load.
  • 5. Wear heavy gloves that do not have loose cuff
  • 6. Do not wear loose clothing that could easily
    catch on projections or swinging objects.
  • 7. Use shackles instead of hooks.
  • 8. Use cable slings instead of chains for lifting
    steel.
  • 9. Make sure that the brakes on hoisting drums
    are inspected daily.
  • 10. Keep a constant lookout for frayed or broken
    strands in cables and repair or replace them if
    necessary.

44
Some essential site requirements
  • 1. Proper ladders are provided for access from
    one level to another.
  • 2. Handrails are provided around elevator shafts
    and the building perimeter once floor decking is
    in place.
  • 3. Safety nets are provided, not only for the
    safety of the workers above, but also to protect
    personnel working below from falling objects.
  • 4. All equipment must be maintained and have the
    proper warning devices when in operation.
  • 5. Conduct weekly safety meetings to ensure that
    all personnel are aware of all safety rules.

45
Summary
  • Structural Steel Shapes
  • Principles of Structural Steel Frames
  • Structural Steel Connections
  • Erection of Steel Frame
  • Construction Procedures and Practices
  • Homework
  • P.144 1, 2, 3, 6/8, 9

46
Gerneral Report
  • To illustrate the general process of a civil
    engineering construction
Write a Comment
User Comments (0)
About PowerShow.com
