VMWORLD EUROPE

1
AP02 NFS iSCSI Performance Characterization
and Best Practices in ESX 3.5

• Priti Mishra
• MTS, VMware
• Bing Tsai
• Sr. RD Manager, VMware

2
Housekeeping

• Please turn off your mobile phones, blackberries
  and laptops
• Your feedback is valued please fill in the
  session evaluation form (specific to that
  session) hand it to the room monitor / the
  materials pickup area at registration
• Each delegate to return their completed event
  evaluation form to the materials pickup area will
  be eligible for a free evaluation copy of
  VMwares ESX 3i
• Please leave the room between sessions, even if
  your next session is in the same room as you will
  need to be rescanned

3
Topics

• General Performance Data and Comparison
• Improvements in ESX 3.5 over ESX 3.0.x
• Performance Best Practices
• Troubleshooting Techniques
• Basic methodology
• Tools
• Case studies

4
Key performance improvements since ESX3.0.x (1 of
3)

• NFS
• Accurate CPU accounting further improves load
  balancing among multiple VMs
• Optimized buffer and heap sizes
• Improvements in TSO support
• TSO (TCP segmentation offload) improves large
  writes
• H/W iSCSI (with QLogic 405x HBA)
• Improvements in PAE (large memory) support
• Results in better multi-VM performance in large
  systems
• Minimized NUMA performance overhead
• This overhead exists in physical systems as well
• Improved CPU cost per I/O

5
Key performance improvements since ESX3.0.x (2 of
3)

• S/W iSCSI (S/W-based initiator in ESX)
• Improvements in CPU costs per I/O
• Accurate CPU accounting further improves load
  balance among multiple VMs
• Increased maximum transfer size
• Minimizes iSCSI protocol processing cost
• Reduces network overhead for large I/Os
• Ability to handle more concurrent I/Os
• Improved multi-VM performance

6
Key performance improvements since ESX3.0.x (3 of
3)

• S/W iSCSI (continued)
• Improvements in PAE (large memory) support
• CPU efficiency much improved for systems with
  gt4GB memory
• Minimizing NUMA performance overhead

7
Performance Experiment Setup (1 of 3)

• Workload Iometer
• Standard set based on
• Request size
• 1k, 4k, 8k, 16k, 32k, 64k, 72k, 128k, 256k, 512k
• Access mode
• 50 read/ write
• Access pattern
• 100 sequential
• 1 worker, 16 Outstanding I/Os
• Cached runs
• 100MB data disks to minimize array/server disk
  activities
• All I/Os served from server/array cache
• Gives upper bound on performance

8
Performance Experiment Setup (2 of 3)

• VM information
• Windows 2003 Enterprise Edition
• 1 VCPU 256 MB memory
• No file system used in VM (Iometer sees disk as
  physical drive)
• No caching done in VM
• Virtual disks located on RDM device configured in
  physical mode
• Note VMFS-formatted volumes are used in some
  tests where noted

9
Performance Experiment Setup (3 of 3)

• ESX Server
• 4-socket, 8 x 2.4GHz cores
• 32GB DRAM
• 2 x Gigabit NICs
• One for vmkernel networking used for NFS and
  software iSCSI protocols
• One for general VM connectivity
• Networking Configuration
• Dedicated VLANs for data traffic isolated from
  general networking

10
How to read performance comparison charts

• Throughput
• Higher is better
• Positive is better ? higher throughput
• Latency
• Lower is better
• Negative is better ? lower response time
• CPU cost
• Lower is better
• Negative is better ? reduced CPU cost
• How does this metric matter?

11
CPU Costs

• Why is CPU cost data useful?
• Determines how much I/O traffic the system CPUs
  can handle
• How many I/O-intensive VMs can be consolidated in
  a host
• How to compute CPU cost
• Measure total physical CPU usage in ESX
• esxtop counter Physical Cpu(_Total)
• Normalize to per I/O or per MBps
• Example MHz/MBps
• (Physical CPU usage percentage out 100) ) X (
  of physical CPUs) X (CPU MHz rating) /
• (throughput in MBps)

12
Performance Data

• First set Relative to baselines in ESX 3.0.x
• Second set Comparison of storage options using
  Fibre Channel data as the baseline
• Last VMFS vs. RDM physical

13
Software iSCSI Throughput Comparison to 3.0.x
higher is better
14
Software iSCSI Latency Comparison to 3.0.x
lower is better
15
Software iSCSI CPU Cost Comparison to 3.0.x
lower is better
16
Software iSCSI Performance Summary

• Lower CPU costs
• Can lead to higher throughput for small IO sizes
  when CPU is pegged
• CPU costs per IO also greatly improved for larger
  block sizes
• Latency is lower
• Especially for smaller data sizes
• Read operations benefit most
• Throughput levels
• Dependent on workload
• Mixed read-write patterns show most gain
• Read I/Os show gains for small data sizes

17
Hardware iSCSI Throughput Comparison to 3.0.x
higher is better
18
Hardware iSCSI Latency Comparison to 3.0.x
lower is better
19
Hardware iSCSI CPU Cost Comparison to 3.0.x
lower is better
20
Hardware iSCSI Performance Summary

• Lower CPU costs
• Results in higher throughput levels for small IO
  sizes
• CPU costs per IO are especially improved for
  larger data sizes
• Latency is better
• Smaller data sizes show the most gain
• Mixed read-write and read I/Os benefit more
• Throughput levels
• Dependent on workload
• Mixed read-write patterns show most gain for all
  block sizes
• Pure read and write I/Os show gains for small
  block sizes

21
NFS Performance Summary

• Performance also significantly improved in ESX
  3.5
• Data now shown here for interest of time

22
Protocol Comparison

• Which storage option to choose?
• IP Storage vs. Fibre Channel
• How to read the charts?
• All data is presented as ratio to the
  corresponding 2Gb FC (Fibre Channel) data
• If the ratio is 1, the FC and IP protocol data is
  identical if lt 1, FC data value is larger

23
Comparison with FC Throughput
if lt 1, FC data value is larger
24
Comparison with FC Latency
lower is better
25
VMFS vs. RDM

• Which one has better performance?
• Data shown as ratio to RDM physical

26
VMFS vs. RDM-physical Throughput
higher is better
27
VMFS vs. RDM-physical Latency
lower is better
28
VMFS vs. RDM-physical CPU Cost
lower is better
29
Topics

• General Performance Data and Comparison
• Improvements in ESX 3.5 over ESX 3.0.x
• Performance Best Practices
• Troubleshooting Techniques
• Basic methodology
• Tools
• Case studies

30
Pre-Deployment Best Practices Overview

• Understand the performance capability of your
• Storage server/array
• Networking hardware and configurations
• ESX host platform
• Know your workloads
• Establish performance baselines

31
Pre-Deployment Best Practices (1 of 4)

• Storage server/array a complex system by itself
• Total spindle count
• Number of spindles allocated for use
• RAID level and stripe size
• Storage processor specifications
• Read/write cache sizes and caching policy
  settings
• Read-Ahead, Write-Behind, etc.
• Useful sources of information
• Vendor documentation manuals, best practice
  guides, white papers, etc.
• Third-party benchmarking reports
• NFS-specific tuning information SPEC-SFS
  disclosures in http//www.spec.org

32
Pre-Deployment Best Practices (2 of 4)

• Networking
• Routing topology and path configurations of
  links in between, etc.
• Switch type, speed and capacity
• NIC brand/model, speed and features
• H/W iSCSI HBAs
• ESX host
• CPU revision, speed and core count
• Architecture basics
• SMP or NUMA?
• Disabling NUMA is not recommended
• Bus speed, I/O subsystems, etc.
• Memory configuration and size
• Note NUMA nodes may not have equal amount of
  memory

33
Pre-Deployment Best Practices (3 of 4)

• Workload characteristics
• What are the smallest, largest and most common
  I/O sizes?
• What is the read? write?
• Is access pattern sequential? random? mixed?
• Response time more important or aggregate
  throughput?
• Response time variance an issue or not?
• Important know the peak resource usage, not just
  the average

34
Pre-Deployment Best Practices (4 of 4)

• Establish performance baselines by running
  standardized benchmarks
• Whats the upperbound IOps for small I/Os?
• Whats the upperbound MBps?
• Whats the average/worst case response time?
• Whats the CPU cost of doing I/O?

35
Additional Considerations (1 of 3)

• NFS parameters
• of NFS mount points
• Multiple VMs using multiple mount points may give
  higher aggregate throughput with slightly higher
  CPU cost
• Export option on NFS server affects performance
• iSCSI protocol parameters
• Header digest processing slight impact on
  performance
• Data digest processing turning off may result in

• Improved CPU utilization
• Slightly lower latencies
• Minor throughput improvement
• Actual outcome highly dependent on workload

36
Additional Considerations (2 of 3)

• NUMA specific
• If only one VM is doing heavy I/O, may be
  beneficial to pin the VM and its memory to node 0
• If CPU usage is not a concern no pinning
  necessary
• On each VM reboot, ESX Server will place it on
  the next adjacent NUMA node
• Minor performance implications for certain
  workloads
• To avoid this movement, VM should be affinitized
  using VI client
• SMP VMs
• For I/O workloads within an SMP VM that migrate
  frequently between VCPUs
• Pin the guest thread/process to a specific VCPU
• Some versions of Linux has KHz timer rate and may
  incur high overhead

37
Additional Considerations (3 of 3)

• CPU headroom
• Software initiated iSCSI and NFS protocols can
  consume significant amount of CPU in certain I/O
  patterns
• Small I/O workloads require large amount of CPU
  ensure that CPU saturation does not restrict I/O
  rate
• Networking
• Avoid link over-subscription
• Ensure all networking parameters or even the
  basic gigabit connection is consistent across the
  full network path
• Intelligent use of VLAN or zoning to minimize
  traffic interference

38
General Troubleshooting Tips (1 of 3)

• Identify
• Components in the whole I/O path
• Possible issues at each layer in the path
• Check all hardware software configuration
  parameters, in particular
• Disk configurations and cache management policies
  on storage server/array
• Network settings and routing topology
• Design experiments to isolate problems, such as
• Cached runs
• Use a small file or logical device, or a physical
  host configured with RAM-disks Minimizing
  physical disk effects
• Indicate upper-bound throughput and I/O rate
  achievable

39
General Troubleshooting Tips (2 of 3)

• Run tests with single outstanding I/O
• Easier for analysis on packet traces
• Throughput entirely dependent on I/O response
  times
• Micro benchmarking each layer in the I/O path
• Compare to non-virtualized, native performance
  results
• Collect data
• Guest OS data But dont trust the CPU
• Esxtop data
• Storage server/array data Cache hit ratio,
  storage processor busy, etc.
• Packet tracing with tools like TCPdump, Ethereal,
  Wireshark, etc.

40
General Troubleshooting Tips (3 of 3)

• Analyze performance data
• Do any stats, e.g., throughput or latency, change
  drastically over time?
• Check esxtop data for anomalies, e.g., CPU spikes
  or excessive queueing
• Server/array stats
• Compare array stats with ESX stats
• Is cache hit ratio reasonable? Storage processor
  overloaded?
• Network trace analysis
• Inspect packet traces to see if
• NFS and iSCSI requests are processed timely
• IO sizes issued by the guest match the transfer
  sizes over the wire
• Block addresses aligned to appropriate boundaries?

41
Isolating Performance Problems Case Study1 (1
of 3)

• Symptoms
• Throughput can reach Gigabit wire speed doing
  128KB sequential reads from a 20GB LUN on an
  iSCSI array with 2GB cache
• Throughput degrades for larger data sizes beyond
  128KB
• From esxtop data
• CPU utilization also lower for l/O sizes larger
  than 128KB
• CPU cost per I/O is in expected range for all I/O
  sizes

42
Isolating Performance Problems Case Study1 (2
of 3)

• From esxtop or benchmark output
• I/O response times in the 10 to 20ms range for
  the problematic IOs
• Indicates constant physical disk activities
  required to serve the reads
• From network packet traces
• No retransmissions or packet loss observed
  indicating no networking issue
• Packet time stamps indicating array takes 10ms to
  20ms to respond to a read request, no delay in
  the ESX host
• From cached run results
• No throughput degradation above 128KB!
• Problem exists only for file sizes exceeding
  cache capacity
• Array appears to have cache-management issues
  with large sequential reads

43
Isolating Performance Problems Case Study1 (3
of 3)

• From native tests to same array
• Same problem observed
• From the administration GUI of the array
• Read-ahead policies set to highly aggressive
• Is the policy appropriate for the workload?
• Solution
• Understand performance characteristics of the
  array
• Experiment with different read-ahead policies
• Try turning off read-ahead entirely to get the
  baseline behavior

44
Isolating Performance Problems Case Study2 (1
of 4)

• Symptoms
• 1KB random write throughput much lower (lt 10)
  than sequential writes to a 4GB vmdk file located
  on an NFS server
• Even after extensive warm-up period
• But very little difference in performance between
  random and sequential reads
• From NFS server spec
• 3GB read/write cache
• Most data should be in cache after warming up

45
Isolating Performance Problems Case Study2 (2
of 4)

• From esxtop and application/benchmark data
• CPU utilization lower but CPU cost per I/O
  mostly same regardless of randomness
• Not likely a client side (i.e., ESX host) issue
• Random write latency in the 20ms range
• Sequential write lt 1ms
• From NFS server stats
• cache hit much lower for random writes, even
  after warm-up

46
Isolating Performance Problems Case Study2 (3
of 4)

• From cached runs to a 100MB vmdk
• Random write latency almost matches sequential
  write
• Again, suggests that issue is not in ESX host
• From native tests
• Random and sequential write performance is almost
  same
• From network packet traces
• Server responds to random writes in 10 to 20ms,
  sequential writes in lt1ms
• Offset in NFS WRITE requests is not aligned to
  power-of-2 boundary
• Packet traces from native runs show correct
  alignment

47
Isolating Performance Problems Case Study2 (4
of 4)

• Question
• Why are sequential writes not affected?
• NFS Server file system idiosyncrasies
• Manages cache memory at 4KB granularity
• Old blocks are not updated in place writes go to
  new blocks
• Each lt 4KB write incurs a read from the old block
• Aggressive read-ahead masks the read latency
  associated with sequential writes
• Solution
• Use disk alignment tool in the guest OS to align
  disk partition
• Alternatively, use unformatted partition inside
  guest OS

48
Summary and Takeaways

• IP-based storage performance in ESX is being
  constantly improved Key enhancements in ESX 3.5
• Overall storage subsystem
• Networking
• Resource scheduling and management
• Optimized NUMA, multi-core, and large memory
  support
• IP-based network storage technologies are
  maturing
• Price/performance can be excellent
• Deployment and troubleshooting could be
  challenging
• Knowledge is key server/array, networking, host,
  etc.
• Stay tuned for further updates from VMware

49
Questions?

• NFS iSCSI Performance Characterization and
  Best Practices in ESX 3.5
• Priti Mishra Bing Tsai
• VMware

50
(No Transcript)
