Third Party Transfers

1
Third Party Transfers Attribute URI ideas

• Andrew McNab
• University of Manchester

2
Third Party Transfers

• GridSite now provides Third Party Transfers for
  HTTP
• htcp command supports this on client side
• although it can also be done using curl etc
• gridsite-copy.cgi provides the necessary extra
  server-side support
• mod_gridsite used as the passive server
• security based on X.509, VOMS etc as normal
• Onetime passcode used as minimal delegation

14 December 2005
Grid Security
3
Doing a transfer
GET /file Cookie PASSCODE
A Server with file
B Server to receive file
file
Onetime Passcode
HEAD /file
COPY https//A/file Destination /file Cookie
PASSCODE
Client
(All HTTPS except GET /file)
14 December 2005
Grid Security
4
Passcodes

• Onetime passcodes originally added for GridHTTP
  uncrypted transfers
• Since HTTP stream unencrypted, want simple
  authentication just a random, single-use number
• Extend this idea for third-party, so the
  single-use is when it is used over an unencrypted
  stream
• This provides a basic form of delegation
• Passcode can only be used for the specified file
• Time limit on the passcode imposed by the server

14 December 2005
Grid Security
5
Multistream

• We've added support for multistream HTTP to htcp
  client
• Client opens multiple HTTP connections fetches
  multiple blocks of the file
• The necessary server-side Range support is
  always there in Apache
• Now deciding how to merge this with 3rd Party
  Transfers
• in simplest case, each block needs a passcode
• Ideally, want to generate or request new
  passcodes on B server, based on original
  passcode

14 December 2005
Grid Security
6
Attribute URI ideas
7
Attribute URIs?

• We've discussed the benefits of tying VOMS
  certificate names and attributes together
  somehow
• Simplest would be that VO names are DNS names
• eg if FQAN is like /atlas.cern.ch/analysis/higg
  s
• Benefit is that dynamic or small VOs don't need
  to distribute their VOMS certificates via a
  trusted channel
• ie like the one for CA root certificates
• However, this renaming of VOs isn't happening...
• Is there something we can do in policy engines
  instead?

14 December 2005
Grid Security
8
Proposal

• We interpret our current Fully Qualified
  Attribute Names as relative attribute names
• So /atlas/analysis/higgs (1) is now short for
  voms//voms.atlas.cern.ch/atlas/analysis/higgs
  (2)
• If a policy evaluation engine sees (1) in a
  policy, then it processes as normal looks in
  vomsdir for the VOMS server cert
• Change is that if it sees (2), then it can make
  use of a VOMS server cert obtained from the
  client, or by contacting voms.atlas.cern.ch
• Since the policy is trusted anyway, we can check
  the chain back to the VOMS's CA just by checking
  signatures and DNs

14 December 2005
Grid Security
9
Implications (1)

• VOs that are happy to distribute VOMS certifcates
  just carry on as normal
• Other people can create small or dynamic VOs
  without needing to get their VOMS cert (or their
  VOMS contact details) into a centralised
  distribution mechanism
• Users can just start writing policies referencing
  the absolute attribute URIs
• CAs just continue as normal, ensuring that
  host/service certificates are only granted to
  people who own that DNS domain name

14 December 2005
Grid Security
10
Implications (2)

• People running VOMS servers who want to benefit
  from this need to use a generic server name
  (atlas.cern.ch not atlas23421.cern.ch)
• Either get the certificate for the generic name,
  or use SubjectAltName if the CA allows that
• We need to define what (untrustworthy) sources
  the policy evaluators can query for the VOMS
  certificate
• GSI Proxy extension?
• Query the hostname via SSL what port numbers?

14 December 2005
Grid Security
11
Summary

• GridSite now supports third party transfers via
  HTTP
• Based on COPY from WebDAV RFC2518
• This is implemented in the usual modular GridSite
  way so can be incorporated into other
  applications, middleware etc
• We're extending to support multistream third
  party copies!
• Absolute Attribute URIs provide a way of
  maintaining small or dynamic VOs without trusted
  VOMS cert distribution

14 December 2005
Grid Security
