TEN COMMANDS TO BE A COLPOSCOPIST

1
TEN COMMANDS TO BE A COLPOSCOPIST

• By
• Prof. Mohammad A. Emam Director Of Early Cancer
  Detection Unit OB GYN Dept.
• Mansoura Faculty Of Medicine - EGYPT

2
What is a Colposcope?

• Colposcope
• Stereoscopic, Binocular
• Microscope with 3 specifications
• low magnification (10 40)
• Focal length (20 25 CM)
• Width of visual field gt 25 MM.
• - NB Colpomicroscope (150 200)

3
TEN COMMANDS TO BE A COLPOSCOPIST

• Gynecologist should be aware of
• 1. Value
• 2. Instruments.
• 3. Different terminology (Anatomical
  histological Pathological Cytological and
  Colposcopic)
• 4. Indications.
• 5. Steps for colposcopy
• 6. Diagnostic Criteria. 7. Interpretation.
• 8. Pitfalls. 9.
  Training.
• 10. Treatment.

4
Value of Colposcopy

• 1. Fill the gap bet. N/E Cytopathology.
• 2. Early detection for precancerous lesions of
  lower genital tract (CIN, VAIN, VIN).
• 3. Decrease diagnostic conization and
  hysterectomy.
• 4. Complementary for cytology or VIA (Each one
  cover the disadvantages of the other).
• CYTOLOGY DISCOVERS THE CRIME COLPOSCOPY LOCATES
  THE CULPRIT.

5
Instrument
1.Colposcope

• Optical system ( 7.5 40 ).
• Illumination system ( Dim or Bright ).
• Stand (Easy movement).
• Accessories ( Gray filter Camera Electronic
  flash ).

6
Instrument cont
2.Auxillary

• Set for cytology.
• Set for Biopsy.
• Speculae ( non polished or plastic ) Kogans.
• Chemicals( Lugols Iodine - Acetic acid 3 -
  Monsols sol .saline)
• Cotton Buds-singleys forceps iris hook

7
Instrument cont..
III-extra auxillary

• Eye piece.
• Video printer.
• Computer graphic.

8
TERMINOLOGY
Anatomical Terminology

• 1. Ectocervix ( vaginal surface of CX.).
• 2. Endocervix ( cervical canal).
• 3. Eversion (Dynamic process) may be true
  (erosion) or false (ectropion).

9
TERMINOLOGY cont..
Pathological terminology

• Metalplasia.
• Dysplasia (BET SQU. Epith CIS.) (Dediff.
  disarrangement).
• CIN (I, II, III).
• Micro invasive (lt 5mm no vascualr and lymphatic
  extension).
• Invasive carcinoma
• Hyper keratoses ( leukoplakia)
• Parakeratosis.

10
HISTOLOGICAL TERMINOLOGY

• Epith. Covering
• Original epithelia . Squamous.
• .
  Columnar
• Metaplastic epithelia (Neonatal Period puberty
  pregnancy).
• Squamo Columnar J. (primary Secondary)
• Underlying Stroma.

11
Cytological Terminology

• positive smear.
• negative smear.
• doubtful Smear.
•
• ( N/C Anisocytosis Hyperchromsia-Clumping).

Smear comment
Dyskaryotic cell
12
Colposcopic Terminology

• Many classifications

13
(No Transcript)
14
Transformation zone TZ

• Definition
• The area between the original squamocolumnar
  junction caudally (which is now squamo
  _Metaplastic junction) to the current (secondary)
  squamo Metaplastic columnar junction cranially
  (where islands of physiological Metaplastic
  Epithelium is identified)

15
Transformation zone TZ cont....
T Z can be altered by

• Age
• Pregnancy
• Oestrogen
• Menopause

16
Indications
I) Diagnostic

• Abnormal pap, smear.VIAM
• Any suspicious lesion (CX Vagina vulva).
• In utero exposure to diethyl stilbestrol (or)
  related drugs.
• Infertility (?) cervical factor.
• Sexual assault victims.
• Cryocautery.
• Diathermy (loop).
• Laser.

II) Therapeutic
17
Role of Colposcope
1. During Diagnosis
Localization of TZ

• Prove (or) disprove invasive cancer.
• Localization of the most ABN. Site for biopsy.
• Evaluation of extent (need for Conization).

18
Role of Colposcope cont...
2. During therapy

• Suitability of the lesion for local destruction.
• Indications for conization
• No Colposcopic lesions (ve pap. Smear).
• Too extensive lesion.
• ECC Atypia.
• Micro invasion by Colposcopy Biopsy.
• Extensive CIN III but fertility is needed.

19
Steps for Colposcopy

• History ( VIA - pap smear drugs infections
  sexual.. etc)
• Counseling explanation of the procedure to the
  patient (psychic element).
• Timing (8 12 day of the cycle).
• Position Examination table.

20
Steps for Colposcopy cont..

• Exam.
• Inspection.
• Bimanual exam, (?!).
• Insertion of speculum (precautions).
• Cytology (spatula cytobrush CVE Cotton buds
  or aspirator)
• Colposcopy.

21
Steps for Colposcopy cont..
A) Direct (saline)

• SQ. COL. J. endocervix vascular.
• Green filter.
• Use (Kogans speculum cotton bud singleys
  forceps).

B) Amplified

• Acetic Acid 3 (3 4 min).
• Lugols iodine (?) (1 part I2 2KI 97H20).

C) Endo C.C. OR ECB (easier)
D) Colposcopic Guided Punch biopsy.
22
Diagnostic criteria of Colposcopy
- Major (5)

• Vascular pattern.
• Intercapillary distance.
• Contour (surface pattern).
• Colour tone opacity.
• Borders (Dermarcation).

23
Diagnostic criteria of Colposcopy cont..
Minor (5)

•
• Size (Extent).
• Keratosis.
• Aceto white areas.
• Iodine uptake.
• Cervical gland openings.

24
Interpretation
25
Interpretation cont
26
Pitfalls of Colposcopy

• 1. False squamo- columnar j.(finger speculum
  smear ).
• 2. High squamo columnar J. in canal (gt 5mm up).
• 3. Previously treated cervix by cryo, or laser.
• 4. Adenocarcinoma in situ (difficult) -?
  hysterocolpomicroscope.
• 5. Subjective method (cervicography digital
  color imaging Colposcopy (DCIC) are objective
  methods.

27
Lines of Treatment

• 1. No treatment.
• 2. Follow up.
• 3. Local destructive therapy (Electro
  coagulation diathermy cryocautery cold
  coagulation laser , photodynamic).
• 4. Cone biopsy.
• 5. Hysterectomy.

28
Criteria for local destructiveTherapy (LDT)

• 1. Satisfactory Colposcopy.
• 2. Expert colposcopist.
• 3. No suspicious of invasion (Cytology
  Colposcopy Histopathology).
• 4. ECC or ECB is negative.
• 5. Done by the expert colposcopist.
• 6. Good follow up.

29
Recommendations

• Colposcopy is not a difficult procedure, but
  without good training, maximum benefits are not
  realized and serious mistakes can be made.
• In modern practice, Colposcopy has become an
  integral part of the gynecologic examination.

30
Recommendationscont

• Colposcopy, can not be done in a vacuum, rather
  it must be performed in combination with cytology
  ,VIA and tissue sampling.
• Cervicography , digital colour imaging Colposcopy
  (DCIC) computer aided colposcopy are objective
  rather than subjective methods.

• Colposcopy, can not be done in vacuum, rather it
  must be performed in combination with cytology
  ,VIA
• Cervicography , digital colour imaging Colposcopy
  (DCIC) computer aided colposcopy are objective
  rather than subjective methods.

31
Thank you
Prof. MOHAMMAD EMAM
OB GYN, Mansoura Faculty of Medicine Mansoura
Integrated Fertility Center (MIFC) EGYPT Telfax
0020502319922 0020502312299 Email.
mae335_at_hotmail.com
