Title: Disaster Recovery


1
Disaster Recovery
  • Sudath Wijeratne 15-Sep-06

2
Agenda
  • Background
  • Methodology
  • Our DR Strategy
  • Learning Management system (Blackboard) DR
    implementation
  • Discussions

3
Background
  • Griffith has 5 campus locations from Brisbane's
    Southbank to the Gold Coast
  • Servers have been installed local to campus
  • Nathan centric corporate systems and servers

4
Background
  • The University AUQA audit in 2003 identified risk
    management as a priority, and the impact of
    failure of electronic infrastructure was
    identified as a risk requiring mitigation. A loss
    of the core Nathan Data Centre has the potential
    to cripple the Universitys ability to deliver
    its core services.
  • Achieving sufficient involvement and sponsorship
    from core business units to undertake a
    traditional top down Business Impact Statement
    (BIA) approach to disaster recovery has proven
    difficult over the last few years.

5
Background
  • In absence of BCP plan/strategy, ICTS management
    team commissioned a disaster recovery project to
    jumpstart the process via a bottom up approach
    for three critical University systems
  • Learning_at_Griffith
  • Staff Email
  • Corporate Web Services

6
Methodology
  • Dozens Of Systems
  • Hundreds of IT Components (building blocks)
  • How they relate to each other and what is a real
    impact of failure of any particular building
    block?
  • We needed a process / methodology to guide us to
    approach DR system by system

7
Methodology
  • We have developed a methodology called Building
    Block
  • Methodology is about
  • Systems / Services
  • Architectural components
  • And their dependencies

8
Methodology
9
Building Block methodology
  • Top down approach is to analyse IT services
    iteratively decomposing them into key
    technological components and dependencies.
  • As a result of this process the key building
    blocks required to deliver the service are
    identified.
  • Recovery solutions for each building block are
    then undertaken.
  • A second round of analysis identified common
    building blocks that are reusable for other
    systems, or as base components for holistic
    disaster recovery (e.g. DNS services, LDAP).

10
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
11
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
Apps Servers (S1-APS-SRV)
Storage Services (S1-APS-SS)
DNS01
LBS (S1-APS-NW)
12
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
Apps Servers (S1-APS-SRV)
Storage Services (S1-APS-SS)
DNS01
LDAP servers (S1-AUS-SVR)
LBS (S1-APS-NW)
LBS (S1-AUS-NW)
13
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
Apps Servers (S1-APS-SRV)
Storage Services (S1-APS-SS)
DNS01
LDAP servers (S1-AUS-SVR)
LBS (S1-APS-NW)
Database Server (S1-DBS-SVR)
Storage Service (S1-DBS-SS)
LBS (S1-AUS-NW)
14
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
Apps Servers (S1-APS-SRV)
Storage Services (S1-APS-SS)
DNS01
LDAP servers (S1-AUS-SVR)
LBS (S1-APS-NW)
Database Server (S1-DBS-SVR)
Storage Service (S1-DBS-SS)
LBS (S1-AUS-NW)
15
Understanding Environment Interdependencies
System-1 (S1)
Web/Apps Services (S1-APS)
Database Services (S1-DBS)
Authentication (S1-AUS)
Network Services (S1-NW)
Apps Servers (S1-APS-SRV)
Storage Services (S1-APS-SS)
DNS01
LDAP servers (S1-AUS-SVR)
LBS (S1-APS-NW)
Database Server (S1-DBS-SVR)
Storage Service (S1-DBS-SS)
LBS (S1-AUS-NW)
16
Methodology application to Backboard
17
Methodology Summary for Blackboard
18
Fact sheets
19
(No Transcript)
20
Our DR Strategy is based around
  • Two physically separated primary Data Centres
  • Distributed operation of major systems between
    these Campuses
  • Near real-time data replication capabilities
    between these Data Centres

21
Key Dependencies for DR Project
  • SAN Infrastructure provisioning at Gold Coast
    campus
  • Network server campus virtualisation (Between
    Nathan and Gold Coast)

22
SAN Infrastructure design
  • Tiered storage capabilities
  • Provide inter campus (Inter SAN) copy (TRUE Copy)
    and snapshot (Shadow Image) capabilities
  • Tier to tier copy capabilities
  • Central management of storage
  • Allow for DR implementation using above
    capabilities

23
Virtual server campus network design
24
Virtual server campus network design
  • Provide equal access to servers from anywhere
  • Well defined access points into the server
    subnets
  • Greater server to server connectivity
  • Allow for DR planning by allowing a shared layer
    2 between sites
  • Easy to migrate servers and services between sites

25
Learning_at_Griffith Distributed DR Architecture
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
DR Plans
  • DR Management Framework
  • DR Plans for each building block
  • Resumption plans

31
Lesions learnt
  • Resource issues and priorities with multiple
    projects
  • Distributed environment
  • Benefits and challenges
  • Resources at 2nd primary site
  • External audit ? University Audit committees
  • BCP awareness

32
Discussions
