Range Estimation

1
Range Estimation
2
Factors Affecting Range Estimation

• Nature of Terrain
• Light Conditions
• Nature of target

3
Nature of Terrain

• Upward sloping terrain distance appears shorter
• Downward sloping terrain distance appears farther
• Dead space makes target appear closer
• Smooth and flat terrain makes target appear
  farther

4
Light Conditions

• Bright and clear, the target appears closer
• Dull and dark, the target appears farther
• Sun behind viewer, the target appears closer
• Sun behind target, the target appears farther

5
Nature of Target

• The larger the target the closer it will appear
• The smaller the target the farther it will seem
• A light colored target will appear farther
• A dark colored target will appear closer

6
Range Estimation Methods

• Football Field Method
• Appearance of Objects Method
• Front Sight Post Method
• Visible Detail Method
• Bracketing

7
Methods (cont)

• Halving
• Estimating Distance by Sound
• ACOG

8
Football Field Method

• Estimate 100 yards, then determine how many of
  these units will fit between you and the target
• This methods accuracy is limited to the ground
  visibility
• Accurate to about 800 yards

9
Appearance of Objects

• This method requires the viewer to be familiar
  with the sizes and details of personnel and
  equipment at certain distances
• Limited by visibility and familiarity of target

10
Front Sight Post Method

• This method is used by comparing the front sight
  post to the target
• A man size target appears the same size as the
  front sight at 175 yards and half of the post at
  350 yards
• A target larger than the post would be closer
  than 175 yds. and smaller than half would be
  farther than 350 yds.

11
Visible Detail Method

• Observing the amount of detail on the target at
  various ranges indicates the distance
• A human target at
• 100 yds- facial features are identifiable
• 200 yds- loss of facial detail, but skin and
  equipment color identifiable
• 300 yds- clear body outline, face color
  visible, but other details blurry

12
Visible Detail Method (cont)

• A human target at
• 400 yds- body outline is clear but remaining
  details blurred
• 500 yds- body shape tapers at ends and the
  head becomes indistinct from the
  shoulders
• 600 yds- body appears wedge-shaped
  without the appearance of a head

13
Bracketing

• The viewer estimates the shortest possible
  distance, then the farthest possible distance
• The average of those distances is the estimated
  range to the target

14
Halving

• The viewer estimates the halfway point to the
  target, then estimates the range to that point
• Double that estimate to get the estimated
  distance to the actual target

15
Estimating by Sound

• Sound travels at 1100 feet or 366 yards per
  second
• If the muzzle flash of a weapon can be seen,
  observe the flash and count the number of seconds
  before the report is heard, then multiply the
  seconds by 366 to get the distance

16
RANGING with TA01NSN

• The outside legs of the stadia lines equals 19
  inches (shoulder width of average size man)
  starting at 200m.
• Between 200m 600m the horizontal stadia lines
  represent 19 inches at each respective range
  (average width of a man shoulders).

17
RANGING with TA01NSN cont.
200 meters
18
RANGING with TA01NSN cont.
300 meters
19
RANGING with TA31F
Each stadia is 19 at the listed range
20
RANGING with TA31F cont.
Target ranged at 300 meters- outside of chevron
legs
Target engaged at center mass using the 300m post
21
RANGING with TA31F cont.
Target ranged at 400m
Target engaged at center mass using the 400m line
22
What are your questions?
