NAME Tier 1 Atmospheric/Ocean Process and Budget Studies

1
NAME Tier 1 Atmospheric/Ocean Process and Budget
Studies
Richard H. Johnson, Paul E. Ciesielski, Brian
McNoldy Colorado State University
2
NAME Scientific Objectives in a Nutshell
Large Scale

• Life cycle of NA summer monsoon mechanisms
  and prediction
• Relationship between precipitation and seasonal
  evolution of continental and oceanic boundary
  conditions
• Intraseasonal variability of precipitation
  interannual variability and relationship to ENSO
• Representation (parameterization) of key
  processes in climate models

Regional and smaller scales, but central to
large-scale issues

• Dynamical and microphysical characteristics of
  precipitation systems
• Diurnal cycle of precipitation
• Precipitation processes in complex terrain
• Mechanisms of Gulf Surges, role of air-sea
  exchanges in water vapor transport to Southwest
  U.S., upper ocean variability in response to
  surges

3
Tier I is a focal point for regional-scale
processes processes linked to objectives of
Tiers II and III
mm
4
Gulf Surges moisture transport to SW US
July 1972
Fuller and Stensrud (2000)

• Some surges are linked to easterly waves, some
  to tropical storms
• What triggers surges? Possibility convection
  and downdraft outflows
• What is role of local evaporation vs advection
  in the moisture budget?
• Surge propagation coastal gravity currents or
  other mechanism(s)?
• How does the upper ocean influence and respond
  to surges?

8 m s-1
Brenner (1974)
5
Gulf of California Surges
Meridional flow from QuikScat
Head of Gulf
Mouth
Many surges originate at mouth of Gulf
6
Expanded view, Junemid-July
7 m s-1
July 4-8 surge
7
July 4-8, 2000
GULF SURGES
8
To what extent does cooler air that passes around
the southern tip of Baja contribute to surges?
BEFORE
POES AVHRR/HIRS
AFTER
9
TRMM 3B42
10
Much of the worlds heaviest rainfall occurs in
coastal environments
11
(18-21 L 09-12 L)
Tb?235 K
Garreaud and Wallace (1997)
SSM/I data
12
Diurnal cycle of convection a
continuing enigma
an accurate representation of the diurnal cycle
over land and ocean provides a key test of many
aspects of the physical parameterizations in a
climate model. The Met. Office Unified Model has
demonstrated considerable difficulty in capturing
the observed phase of the diurnal cycle in
convection.
Yang and Slingo (1997 MWR)
13
Processes producing nocturnal offshore rainfall
maximum are not well understood
Mapes et al. (2003)
14
TIER 1 SOUNDINGS
M
M
10P
M
M
NOAA ETL surface flux system
15

NCAR ISS (GPS sounding, UHF profiler, RASS, sfc
station)
Sounding network designed to determine
initiation mechanisms, structure, and propagation
of surges mechanisms for diurnal cycle
air-sea exchanges, upper-ocean changes
atmospheric budgets, latent heating profiles over
land and ocean

Mexico soundings
? UHF profiler w/RASS




?





fluxes, upper-ocean
16
Environmental response to convection depends on
vertical distribution of heating
U
2 h
Impulsive heating
W
H
P
Combined Heating
L
Nicholls et al. (1991)
b
17
CONCLUSIONS
TIER I will provide data that will enhance basic
understanding of phenomena of this region, as
well as contribute to prediction and climate
objectives of NAME
Within a climate context, many of the
smaller-scale processes such as the diurnal
cycle, surges, etc., are highly nonlinear
Specifically, the application of a mean solar
zenith angle (rather than the diurnal cycle) or
mean flow conditions (rather than surges) may
yield a quite different distribution of
precipitation and climate than the representation
of the full dynamic ranges of these phenomena
