Using ModelBuilder Landslide Susceptibility

1
Using ModelBuilder Landslide Susceptibility

• Ann Johnson
• TRESTE - 2006

2
Modeling Landslides

• What factors influence landslides?
• What data can be used to model landslides
  susceptibility and what are we going to use?
• What analyses can suggest probabilities of
  landslides?
• What is ModelBuilder and how can it be used to
  model landslides
• How can the results be visualized in 3D

3
Landslide Susceptibility steep mountain slopes,
faults, climate
4
Add Fires
5
3D View of burned area
6
Factors Influencing Landslide Susceptibility

• Slope steeper more susceptible
• Aspect South facing dry, little vegetation
• Burn Severity least vegetation as severity of
  burn increases and creating hydrophobic soil
• Weigh each outputs affect to determine areas
  with highest susceptability

7
Our Analysis Will Use

• Raster
• pixels
• a location and value
• Elevation of study area
• hIllshade of elevation
• DRG of study area
• Vector
• Lines Polygons
• Features
• Roads, Streams, Faults, geology, burn severity

Real world
8
Basic Data Sets for Our Model

• Raster
• Elevation data (DEM)
• Continuous data set with each center of a grid
  containing the value for the elevation (10 x 10 m
  grid, Z in meters)
• Digital Raster Graphic of study area
• Vector
• Severity of burn
• Road, streams, faults, geology, historic
  landslides
• Vector to Raster Conversion
• Severity of burn from Vector (polygon) to raster

9
Faults Layer
Streams Layer
Landslide Layer
Roads Layer
DEM Layer
Four Vector and One Grid Data Layers
10
DEM - Raster
Properties of elevation layer
11
Geology Old Slides
12
Grids Layers can be Combined - binary
suitability models

• Use for simple problems
• Map Algebra or Boolean And Tools
• Classify layers into good (1) and bad (0)
• Combine with AND, addition or multiplication
• ski snow slope sun
• Advantages
• Easy
• Disadvantages
• No nextbest sites
• All layers have same importance
• All good values have same importance

13
Using Tools in ArcToolbox one by one
14
Spatial Analyst gt Surface gt Hillshade To shade
and make elevation look 3D
15
Spatial Analyst gt Surface gt Slope To determine
slope from elevation
16
Spatial Analyst gt Reclass gt Reclassify gt Slope To
determine the Angles of the Slope
17
Conversion gt To Raster gt Feature to Raster To
Convert burn Polygon to Raster
18
Weighted suitability models

• Use for complex problems
• Overlay tool from Spatial Analysis Toolbox
• Classify layers into suitability 1-9 (9 best)
• Weight and add together
• Ski (snow .5) (slope .3)
  (sun .2)
• Advantages
• All values have relative importance
• All layers have relative importance
• Returns suitability on a scale 1-9
• Disadvantages
• Preference assessment is harder

19
Spatial Analyst gt Overlay gt Weighted Overlay To
use relclassified Slope, Aspect, and Burn
Severity datasets and weigh effect of Slope most
20
Finals Output Possible Slide Areas
21
Automating Analysis ModelBuilder
. . . And Shared
22
Landslide ModelBuilder
23
3-D Analyst ArcScene
24
www.geodata.gov, http//seamless.usgs.gov/
http//www.census.gov/geo/www/tiger/
25
Hands On all work together

• Use Handout
• Introduce data and ArcCatalog
• Look at a Landslide data sets
• Use ModelBuilder and build a Model
• Use results and create an ArcScene project and
  create a fly through animation
• If you know GIS and want to go ahead, you can do
  them on your own

26
Lets have fun!

• Angela Lee alee_at_esri.com
• Ann Johnson - ajohnson_at_esri.com
