Introduction to CMOS VLSI Design Lecture 3: DC

1
Introduction toCMOS VLSIDesignLecture 3 DC
Transient Response
David M. Zar Washington University in St.
Louis Based on original work, with permission,
by David Harris Harvey Mudd College
2
Outline

• Pass Transistors
• DC Response
• Logic Levels and Noise Margins
• Transient Response
• RC Delay Models
• Delay Estimation

3
Activity

• 1)     If the width of a transistor increases,
  the current will
• increase decrease not change
• 2)     If the length of a transistor increases,
  the current will
• increase decrease not change
• 3)     If the supply voltage of a chip increases,
  the maximum transistor current will
• increase decrease not change
• 4)     If the width of a transistor increases,
  its gate capacitance will
• increase decrease not change
• 5)     If the length of a transistor increases,
  its gate capacitance will
• increase decrease not change
• 6)     If the supply voltage of a chip increases,
  the gate capacitance of each transistor will
• increase decrease not change

increase
decrease
increase
increase
increase
not change
4
Pass Transistors

• We have assumed source is grounded
• What if source gt 0?
• e.g. pass transistor passing VDD

5
Pass Transistors

• We have assumed source is grounded
• What if source gt 0?
• e.g. pass transistor passing VDD
• Vg VDD
• If Vs gt VDD-Vt, Vgs lt Vt
• Hence transistor would turn itself off
• nMOS pass transistors pull no higher than VDD-Vtn
• Called a degraded 1
• Approach degraded value slowly (low Ids)
• pMOS pass transistors pull no lower than Vtp
• Transmission gates are needed to pass both 0 and
  1

6
Pass Transistor Ckts
7
Pass Transistor Ckts
8
DC Response

• DC Response Vout vs. Vin for a gate
• Ex Inverter
• When Vin 0 -gt Vout VDD
• When Vin VDD -gt Vout 0
• In between, Vout depends on
• transistor size and current
• By KCL, must settle such that
• Idsn Idsp
• We could solve equations
• But graphical solution gives more insight

9
Transistor Operation

• Current depends on region of transistor behavior
• For what Vin and Vout are nMOS and pMOS in
• Cutoff?
• Linear?
• Saturation?

10
nMOS Operation
Vtn
Vtn Vgsn Vtn
Vtn Vgsn Vtn
11
nMOS Operation
Vgsn Vin Vdsn Vout
12
nMOS Operation
Vgsn Vin Vdsn Vout
13
pMOS Operation
14
pMOS Operation
15
pMOS Operation
Vgsp Vin - VDD Vdsp Vout - VDD
Vtp lt 0
16
pMOS Operation
Vgsp Vin - VDD Vdsp Vout - VDD
Vtp lt 0
17
I-V Characteristics

• Make pMOS wider than nMOS such that bn bp

18
Current vs. Vout, Vin
19
Load Line Analysis

• For a given Vin
• Plot Idsn, Idsp vs. Vout
• Vout must be where currents are equal in

20
Load Line Analysis

• Vin 0

21
Load Line Analysis

• Vin 0.2VDD

22
Load Line Analysis

• Vin 0.4VDD

23
Load Line Analysis

• Vin 0.6VDD

24
Load Line Analysis

• Vin 0.8VDD

25
Load Line Analysis

• Vin VDD

26
Load Line Summary
27
DC Transfer Curve

• Transcribe points onto Vin vs. Vout plot

28
Operating Regions

• Revisit transistor operating regions

29
Operating Regions

• Revisit transistor operating regions

30
Beta Ratio

• If bp / bn ? 1, switching point will move from
  VDD/2
• Called skewed gate
• Other gates collapse into equivalent inverter

31
Noise Margins

• How much noise can a gate input see before it
  does not recognize the input?

32
Logic Levels

• To maximize noise margins, select logic levels at

33
Logic Levels

• To maximize noise margins, select logic levels at

• unity gain point of DC transfer characteristic

34
Transient Response

• DC analysis tells us Vout if Vin is constant
• Transient analysis tells us Vout(t) if Vin(t)
  changes
• Requires solving differential equations
• Input is usually considered to be a step or ramp
• From 0 to VDD or vice versa

35
Inverter Step Response

• Ex find step response of inverter driving load
  cap

36
Inverter Step Response

• Ex find step response of inverter driving load
  cap

37
Inverter Step Response

• Ex find step response of inverter driving load
  cap

38
Inverter Step Response

• Ex find step response of inverter driving load
  cap

39
Inverter Step Response

• Ex find step response of inverter driving load
  cap

40
Inverter Step Response

• Ex find step response of inverter driving load
  cap

41
Delay Definitions

• tpdr
• tpdf
• tpd
• tr
• tf fall time

42
Delay Definitions

• tpdr rising propagation delay
• From input to rising output crossing VDD/2
• tpdf falling propagation delay
• From input to falling output crossing VDD/2
• tpd average propagation delay
• tpd (tpdr tpdf)/2
• tr rise time
• From output crossing 0.2 VDD to 0.8 VDD
• tf fall time
• From output crossing 0.8 VDD to 0.2 VDD

43
Delay Definitions

• tcdr rising contamination delay
• Minimum delay from input to rising output
  crossing VDD/2
• tcdf falling contamination delay
• Minimum delay from input to falling output
  crossing VDD/2
• tcd average contamination delay
• tcd (tcdr tcdf)/2

44
Simulated Inverter Delay

• Solving differential equations by hand is too
  hard
• SPICE simulator solves the equations numerically
• Uses more accurate I-V models too!
• But simulations take time to write, may hide
  insight

45
Delay Estimation

• We would like to be able to easily estimate delay
• Not as accurate as simulation
• But easier to ask What if?
• The step response usually looks like a 1st order
  RC response with a decaying exponential.
• Use RC delay models to estimate delay
• C total capacitance on output node
• Use effective resistance R
• So that tpd RC
• Characterize transistors by finding their
  effective R
• Depends on average current as gate switches

46
Effective Resistance

• Shockley models have limited value
• Not accurate enough for modern transistors
• Too complicated for much hand analysis
• Simplification treat transistor as resistor
• Replace Ids(Vds, Vgs) with effective resistance R
• Ids Vds/R
• R averaged across switching of digital gate
• Too inaccurate to predict current at any given
  time
• But good enough to predict RC delay
