Hot Water Temperature Maintenance

1
Hot Water Temperature Maintenance
2
HWAT Simply Keeps Hot Water Hot
Heat lost through the insulation
Water provided from Water Heater
Air at 70F
Pipe
Insulation
HWAT heating cable
Heat provided by HWAT heating cable
3
Movement of Water in HWAT System
Water heater is set to the desired maintain
temperature
Water in untraced section cools to ambient 70F
HWAT-Y2
HWAT maintains the hot water by replacing the
heat lost through the thermal insulation
4
HWAT or Recirculation?
Recirculation
HWAT
5
Typical Recirculation System
Return Piping
Balancing Valves
Water Heater
Recirculation Pump
6
Typical HWAT System
HWAT Heating Cable
Water Heater
7
HWAT History

• System developed by Raychem in 1976
• Installed in more than 300,000 buildings
• More than 2,500,000 feet of HWAT cable installed
  every year
• More successful in Europe due to a greater focus
  on water and energy conservation which is only a
  recent trend in North America

8
Advantages of HWAT

• Easy to design
• Low installed and operating costs
• No flow-balancing issues
• Compatible with low-flow fixtures
• Easy to provide instant hot water to the point of
  use
• Water conservation/Reduced time to tap

9
Time to Tap Water Conservation

• Water in 10 of ½ pipe 0.1 gallons
• Water in 40 of ¾ pipe 0.9 gallons
• Water between fixture and recirculation loop
  1.0 gallons
• If this fixture is used 5 times per day, the
  annual water waste would be 1,825 gallons per
  year!

10
Disadvantages of HWAT

• Perceived as new technology
• May not be economical for certain building
  configurations
• Me-Too competitive systems fail to perform as
  expected on an HWAT design

11
Typical HWAT Building
Why is this a good HWAT application?
12
Typical HWAT Building

• No horizontal return piping
• No booster pumps or booster heaters
• No balancing
• Reduced supply piping

13
Typical HWAT Building
14
HWAT Performance Issues
Sections without insulation or power
Hot water heater continues to maintain the water
at 115F.
HWAT-G2
Heated water moves into pipes.
15
HWAT Performance Issues
Cold to Hot water by-pass
Cold to hot cross connection at fixture.
Hot water heater continues to maintain the water
at 115F.
HWAT-G2
Heated water moves into pipes.
Heated water mixes with by-pass water
16
Mixing Valves
Main Mixing Valves Main mixing valves are usually
flow dependent. There should be a low flow and a
high flow valve. If theres only one, be sure it
can function in a low/no flow situation.
17
Typical Maintain Temperatures

• Temperature Application
• 105F Hospitals, Nursing Homes
• 115F Schools, Prisons
• 125F Hotels, Apartments, Offices
• 140F Kitchens, Laundries
• 125F Residential

18
HWAT Heating Cables

• B2 - 105F
• G2 - 115F
• Y2 - 125F
• R2 - 140F

• Y2 or R2
• R2

19
HWAT Selling Tools
20
HotCAP

• Hot Water Cost Analysis Program
• Introduced in March, 2004
• Integrates HWAT-ECO
• Updated material costs
• Updated labor, electricity and fuel rates
• Download from web

21
HWAT-ECO Electronic Controller

• Flexible temperature control
• Insulation schedule
• Energy savings
• 9 pre-defined programs
• Heat-up cycle
• Alarm events
• Water heater sensor
• BMS interface
• Master/slave function
• Power correction factor

22
Flexible Temperature Control

• Maintain Temp
• HWAT-Y2 105F 125F
• HWAT-R2 105F 140F
• Depending on the ambient temperature and
  voltage

23
Fiberglass Insulation Schedule

• Copper pipe size (in) IPS insulation size
  (in) Insulation thickness (in)
• ½ ¾ ½
• ¾ 1 1
• 1 1¼ 1
• 1¼ 1½ 1½
• 1½ 1½ 1½
• 2 2 2 2½ 2½
  2½
• 3 3 3
• Insulation thickness matches pipe diameter for
  equal heat loss
• Pipes 1¼ and smaller require oversized
  insulation to allow room for the heating cable
• For pipes 3 and larger, 1/3 the thickness of
  insulation can be used with 2 runs of heating
  cable

24
HWAT-ECO Limits the Power Output

• 400 seconds duty cycle
• On time depends on the desired maintain
  temperature
• 4 Modes Off, Economy, Maintain Heat-Up Cycle

25
9 Pre-defined Programs
26
Programming Options

• (48) ½ hour time blocks
• Additional energy savings during Off and
  Economy

27
Heat-Up Cycle and Cool Down

• Raise the water temperature of stagnant pipes
• Determine the amount of time required to reach a
  desired maintain temperature
• Program the number of hours required
• Allow time to cool down before hot water usage

28
Alarm Events

• Water heater temperature too low (next slide)
• Water heater temperature too high (Y2 gt 150F, R2
  gt 185F)
• Loss of power relay closes
• Loss of power for more than 8 hours clock reset
• Internal controller temperature too high (gt
  185F)
• Master/slave error

29
Water Heater Sensor (Optional)

• Ensures maintain temp does not exceed the water
  heater temp
• Controller stores highest water temperature
  measured over last 24 hours
• Delta between supplied water temperature and the
  maintain temperature setpoint selected between
  9F and 27F
• Connected to single or master controller only
• Sensor cable can be extended up to 328 feet

30
BMS Interface

• BMS input is 0-10 Vdc
• BMS controls the temperature setpoint
• If water heater sensor is installed, it overrules
  the BMS temperature setting if necessary
• Loss of power alarms BMS

31
Master/Slave Function

• Control up to eight additional controllers
• Total maximum length of cable between all
  controllers is 328 ft
• RS-485 connection
• Water heater sensor connects only to master
  controller
• Controllers on the same phase (max 3 controllers)
  have a delayed On and Off

32
Multiple Circuits with Single Controller

• For controlling multiple circuits with the same
  parameters (i.e. voltage, maintain temp, ambient
  temp, economy temp), connect the heating cable
  output relay to an external contactor coil

33
Power Correction Factor

• Fine tuning of system
• Increase or decrease the actual pipe maintain
  temperature
• 0.6 1.4 percent of duty cycle

34
Legionella What is it?

• Received its name from a 1976 break out at an
  American Legion Convention in Philadelphia
• Bacteria common to warm water environments
• Cause of Legionellosis any illness caused by
  the bacteria (Legionnaires disease and Pontiac
  Fever most common)
• Attacks the respiratory system

35
Legionella www.awt.org

• Legionella 2003 an Update and Statement by the
  Association of Water Technologies (AWT)
• raising water temperature to 122F a 90 kill
  of legionella in 2 hours, 140F a 90 kill of
  legionella in 2 minutes and 158F a 100 rapid
  kill of legionella.

36
Hot Water Temperature Maintenance

• Questions?
