Introduction

• Purpose
• Provide an overview of Sullins 1.0mm pitch header
  series
• Objectives
• Discuss the SMH Male Header Series features
  benefits
• Discuss the SFM Male Header Series features
  benefits
• Content
• 20 pages
• Learning Time
• 15 minutes

3
Overview
4
Features

• Single row and dual row
• Available in 2-50 positions
• Termination types dip solder, right angle, and
  surface mount
• SMH series mates with SFM series
• SMH Male Header series offers 1.0mm and 1.5mm
  profiles, as well as 1.65mm and 1.90mm head
  heights in the surface mount type
• Corresponding SFM female header mates are
  available in 2.10mm or 3.15mm profile
• Plating options include 10u gold or gold flash
• Support operating temperatures up to 125C with
  reflow processes up to 260C peak for 10 seconds
• RoHS compliant

5
Benefits

• High density board-to-board interconnection
• Space saving
• Design flexibility with profile and head height
  options
• Tail length options available upon special
  request
• Board stacking configurations available upon
  special request

6
Product Application Examples - Headers
7
Product Application Examples Stacker Headers
8
Applications

• Aircraft Electronic Controls Radio
  Communications
• Computing Equipments Peripherals
• Consumer Electronics Household Appliances
• Office Equipment
• Automotive Electronics Accessories
• Casino Gaming Devices
• Medical Device
• Industrial Machinery Process Control Equipment
• Telecommunication
• Vending Machines

9
Part Number Coding
10
SMH100-LPPE-D10-ST-BK-M
SERIES NAME SERIES NUMBER DESCRIPTION
SMH 100 Sullins Male Header 1.0mm Profile, 1.80mm Head Height
SMH 101 Sullins Male Header 1.0mm Profile, 1.65mm Head Height (SMT only)
SMH 102 Sullins Male Header 1.0mm Profile, 1.90mm Head Height (SMT only)
SMH 150 Sullins Male Header 1.5mm Profile, 1.80mm Head Height
SMH 151 Sullins Male Header 1.5mm Profile, 1.65mm Head Height (SMT only)
SMH 152 Sullins Male Header 1.5mm Profile, 1.90mm Head Height (SMT only)
SFM 210 Sullins Female Header 2.10mm Profile
SFM 315 Sullins Female Header 3.15mm Profile
11
SMH100-LPPE-D10-ST-BK-M
HOUSING MATERIAL HOUSING MATERIAL
L Liquid Crystal Polymer (LCP)
12
SMH100-LPPE-D10-ST-BK-M
CONTACT MATERIAL CONTACT MATERIAL
P Phosphor Bronze
13
SMH100-LPSE-D10-ST-BK-M
PLATING PLATING PLATING
CONTACT SURFACE TERMINATION
G .000010 Gold Gold Flash
P Gold Flash Overall Gold Flash Overall
S .000010 Gold Overall .000010 Gold Overall
14
SMH100-LPPE-D10-ST-BK-M
CONTACT CENTERS CONTACT CENTERS
E .039 1.0mm
15
SMH100-LPPE-D10-ST-BK-M
ROW OPTIONS ROW OPTIONS
S Single Row
D Dual Row
16
SMH100-LPPE-D10-ST-BK-M
POSITION NUMBER
02 - 50
17
SMH100-LPPE-D10-ST-BK-M
TERMINATION TYPE TERMINATION TYPE
ST Straight
RA Right Angle
SM Surface Mount Without Guide Posts
SP Surface Mount With Guide Posts
SC Surface Mount Pin 1 Left
SD Surface Mount Pin 1 Right
18
SMH100-LPPE-D10-ST-BK-M
COLOR COLOR
BK Black
19
SMH100-LPPE-D10-ST-BK-M
ADD M FOR SPECIAL OPTIONS ADD M FOR SPECIAL OPTIONS
M81 Tape Reel Packaging With Pick and Place Pad
20
Sullins Advantage

• Short lead time
• Free samples Fast!
• High quality reliable connectors
• Design build custom parts
• Dedicated technical support resources
• Dedicated inside sales team
• Flexible delivery schedules

21
Summary

• Sullins 1.0mm SMH SFM series offers
• High density board-to-board interconnection
• Space saving
• Design flexibility with various options
