DIRA: Automatic Detection, Identification, and Repair of ControlHijacking Attacks

1
DIRA Automatic Detection, Identification, and
Repair of Control-Hijacking Attacks

• Alexey Smirnov and Tzi-cker Chiueh
• SUNY at Stony Brook
• alexey, chiueh_at_cs.sunysb.edu
• DEFCON 13

2
Outline of the Talk

• Introduction
• Related Work
• DIRA Architecture
• Attack Detection
• Attack Identification
• Attack Repair
• Performance Evaluation
• Conclusion

3
Introduction

• Buffer overflow attacks are the most common type
  of attacks.
• A comprehensive protection strategy should
  consists of the following components
• Attack detection to prevent the attack from
  causing damage
• Attack identification to feed the IDS with the
  attack signature
• Attack repair to allow the compromised
  application to continue its normal execution.
• We propose a compile-time solution that provides
  all three components.

4
What is a Buffer Overflow Attack

• Control-hijacking attacks work by overwriting a
  control pointer such as the return address,
  function pointer, etc.
• Buffer overflows are possible when the length of
  the target buffer is less than the length of the
  data that can be written into it.
• Standard libc functions such as strcpy() or
  sprintf() are responsible for most buffer
  overflows.

5
Outline of the Talk

• Introduction
• Related Work
• DIRA Architecture
• Attack Detection
• Attack Identification
• Attack Repair
• Performance Evaluation
• Conclusion

6
Attack Detection

• Stackguard place a canary word before the
  return address (RA) in the function prolog and
  check it in the function epilog. The assumption
  is that the attacker will have to overwrite the
  canary word in order to overwrite the RA.
• RAD save the original RA in a safe place in the
  function prolog and compare it to the value
  stored in the stack in the function epilog.

7
Approaches to Attack Identification

• Automatic ways to identify attacks (that is, to
  generate their signatures) are very important for
  worm epidemics confinement.
• Previous systems either provided a single
  attacking packet or required a large pool of
  malicious network data.
• Toth and Kruegel look at network packets
  payloads and perform abstract code execution.
• TaintCheck uses the value of compromised
  control pointer as the attack signature.
• Autograph extracts most common subsequences
  from suspicious flows and reports them as
  signatures.
• Polygraph and Nemean use machine learning
  algorithms to derive common patterns from a large
  set of malicious flows.

8
Approaches to Attack Repair

• Program rollback and replay is used in software
  debugging. Two approaches (1) keep execution
  history (Spyder) or (2) do periodic state
  check-pointing. Check-pointing is easy under
  Linux because of copy-on-write fork() system call
  (RECAP and Flashback). Can be more difficult
  under other OS.
• Check-pointing relies on the OS rather than on
  the applications.
• Shadow Honeypot runs two versions of the
  application (protected and non-protected) and
  dynamically switches between the two once an
  attack has been detected.

9
Outline of the Talk

• Introduction
• Related Work
• DIRA Architecture
• Attack Detection
• Attack Identification
• Attack Repair
• Performance Evaluation
• Conclusion

10
DIRA Approach

• DIRA is an extension to GCC 3.4.1. It uses memory
  updates logging to solve the three problems at
  the same time.
• The idea is to maintain a run-time log of all
  changes to the memory state of the program.
• Assignments such as ab and libc function calls
  such as memcpy() change the memory state of the
  program.
• For each memory update DIRA stores its source
  address, destination address, length, and the
  pre-image.

11
DIRA Approach

• How to detect, identify, and repair an attack
  using memory updates log?
• To detect compare the current RA with that saved
  in the log
• To identify trace back the data that replaced
  the control pointer to the point where it was
  read from the network
• To repair restore the memory state using the
  pre-images stored in the log.
• At compile time, DIRA instruments the source code
  to perform logging and to check correctness of
  control pointers.
• At run-time, the logging code generates the
  memory updates log.

12
Memory Updates Logging

• Memory updates log is a circular buffer each
  entry has four fields read_addr, write_addr,
  len, data.
• DIRA logs effect of each operation of the form
  XY where X and Y are directly referenced
  variables, array references (ai), or
  de-referenced variables ((a1)).
• read_addr is set to Y,
• write_addr is set to X,
• len is set to sizeof(Y),
• data is set to the pre-image of X in DIR mode and
  is empty in other modes.

13
Memory Updates Logging

• If the right-hand side is a complex expression
  then a log record is created for each variable of
  it.
• To handle updates performed by libc functions
  DIRA proxies several of them string manipulation
  functions, format string functions, file and
  network I/O functions
• The log is also used to store tags, special
  records indicating change of programs run-time
  state
• FUNCTION_ENTRY tag is inserted when a function is
  called
• FUNCTION_EXIT tag is inserted before a function
  returns.
• Tags are used for signature generation and repair.

14
Memory Updates Logging Example

• At compile time
• Source code xyz
• Instrumented code
• (log(x, y, sizeof(y), x), (log(x, z,
  sizeof(z), x), xyz))
• At run time log() adds two records to the memory
  updates log
• read_addr y write_addr x len sizeof(y)
  data x
• read_addr z write_addr x len sizeof(z)
  data x

15
Memory Updates Logging Example

• At compile time
• Source code strcpy(a,b)
• Instrumented code dira_strcpy(a,b)
• At run time
• Proxy function dira_strcpy() adds a log record
• read_addrb, write_addra, lenstrlen(b)1,
  dataa

16
Attack Detection (D-mode)

• DIRA uses RAD-like approach the code to save the
  RA in a protected buffer is added to the function
  prolog. The actual RA stored in the stack is
  compared with this value in function epilog.
  Using a special buffer to store RAs is an
  optimization of using a common memory update log
  to store RAs.
• DIRA can protect other control-sensitive data
  structures such as GOT, signal handler tables in
  a similar fashion (not implemented yet).

17
Attack Identification

• The desired properties of an attack signature
• Context-aware (to reduce false positives)
• Semantics-aware (to reduce false positives)
• Provides a degree of flexibility within each
  packet (to reduce false negatives)
• DIRAs signatures consist of multiple packets,
  each packet is a regular expression. The length
  constraint limits the length of the attacking
  part of the last packet.
• Memory updates log is used to build attack
  signatures.

18
Attack Identification

• Two types of dependencies data and control
  dependencies.
• A data dependency is created when one variable is
  assigned to another.
• A control dependency is created between variable
  X and variable Y if value of variable Y depends
  on the value of variable X used in a conditional
  expression. Example
• if (xgt0)
• y1
• else
• y2
• Why we need control dependencies? Example FTP
  server attack involving authentication.

19
Vulnerable FTP Server Example

• A vulnerable FTP server pseudo-code
• char buf16
• Is_authis_user0 // user not authenticated
  initially
• while (1)
• recv_packet(p)
• if (!strncmp(p, QUIT,4)) break
• if (!strncmp(p, USER, 4)) is_user1
  continue
• if (!strncmp(p, PASS, 4) is_user)
  is_auth1 continue
• if (!is_auth) continue // authentication
  required
• if (!strncmp(p, GET, 3))
• strcpy(buf, p4) // copy filename
• send_file(buf)

20
FTP Server Attack

• FTP server GET attack (3 packets)
• USER alexey
• PASS my_pass
• GET very_long_file_name_that_will_overwrite_the_re
  turn_address

21
FTP Server Attack

• FTP server GET attack (3 packets)
• USER alexey
• PASS my_pass
• GET very_long_file_name_that_will_overwrite_the_re
  turn_address
• Log records
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt

22
FTP Server Attack

• FTP server GET attack (3 packets)
• USER alexey
• PASS my_pass
• GET very_long_file_name_that_will_overwrite_the_re
  turn_address
• Log records
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt

23
FTP Server Attack

• FTP server GET attack (3 packets)
• USER alexey
• PASS my_pass
• GET very_long_file_name_that_will_overwrite_the_re
  turn_address
• Log records (third packet)
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

24
FTP Server Attack

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

25
Identifying Attack Using Data Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

26
Identifying More Packets Using Control
Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

27
Identifying More Packets Using Control
Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

28
Identifying More Packets Using Control
Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

29
Identifying More Packets Using Control
Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

30
Identifying More Packets Using Control
Dependencies

• The return address (RA) is located after buf
  RAbuf17.
• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

31
Definition of Control Dependencies

• Whenever variable X can prevent control flow from
  reaching variable Y, a control dependency is
  created between X and Y.
• stmt1 and stmt2 are always dependent.

• Control dependencies are also created for for and
  while. Tags START_SCOPE and END_SCOPE are used to
  store control dependencies in the memory updates
  log.

32
Representing Packets as Regular Expressions

• For each byte of the attacking packet DIRA
  determines whether it was looked at by the
  program or not looked at. For example, strcmp()
  applied to the packet bytes converts them into
  looked-at bytes. If the bytes are blindly copied
  with strcpy() then they are non-looked-at.
  Initially all bytes are not-looked-at.
• DIRA traverses the log forward from where the
  packets were received and records all packet
  bytes that were looked at.
• When it outputs the bytes, a looked-at byte is
  output as is, a non-looked-at is output as ?.

33
Building Regular Expressions

• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

34
Building Regular Expressions

• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

35
Building Regular Expressions

• ltDIRA_RECV, p, 11, USER alexeygt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltNULL, is_user, 4, is_usergt
• ltDIRA_RECV, p, 12, PASS my_passgt
• ltDIRA_STRNCMP, p, 4, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltDIRA_COND, is_user, 0, NULLgt
• ltNULL, is_auth, 4, is_authgt
• ltDIRA_RECV, p, 62, GET gt
• ltDIRA_COND, is_auth, 0, NULLgt
• ltDIRA_STRNCMP, p, 3, NULLgt
• ltDIRA_COND, p, 0, NULLgt
• ltp4, buf, strlen(p)-41, (p4)gt

36
Length Constraint Generation

• The length constraint limits the attacking part
  of the packet by specifying the terminating
  character and its maximum offset in any benign
  packet.

37
DIRAs Signature File Format

• N number of packets
• L_i length of i-th packet
• Regular expression of the packet. Possible
  characters are shown on the right

• The length constraint is specified for the last
  attacking packet.

38
Complete Signature for FTP Attack

• 3 number of packets
• 11 1st packet length
• USER???????
• 12 2nd packet length
• PASS????????
• 62 3rd packet length
• GET???...???
• 4 17 \0 length constraint

39
Attack Recovery (DIR-mode)

• Main goal bring the program to the state in
  which it was before the attack packet(s) was
  received.
• How to restore the pre-attack state?
• From which point to continue execution?
• Program restart points can only be at the
  beginning of a function because only global
  updates are logged in DIR mode (for performance
  reasons).
• The proper function is the least common dynamic
  ancestor of the function in which the attack was
  detected and the function in which the data was
  read in.

40
Choosing the Restart Point

• depth is a loop invariant it is the relative
  depth of the current function with respect to the
  greatest dynamic ancestor seen so far.

41
Choosing the Restart Point

• When all updates are tracked it is possible to
  resume execution from the middle of a function.
• No system support is required for restarting
  longjmp() and setjmp() are used. A setjmp() call
  is inserted before the function that can be a
  potential restart point is called (to push the
  arguments again).
• DIRA inserts the first local update tag when it
  encounters such an update after a function call.

42
Outline of the Talk

• Introduction
• Related Work
• DIRA Architecture
• Attack Detection
• Attack Identification
• Attack Repair
• Performance Evaluation
• Conclusion

43
DIRA Evaluation

• Programs tested
• ghttpd 1.4 have exploit
• drcatd 0.5.0 have exploit
• named 8.1 have exploit
• qpopper 4.0.4
• proftpd 1.2.9
• Two goals measure run-time overhead and quality
  of automatically generated signatures
• Configuration server machine (P-4M 1.7GHz, 512
  MB RAM), two clients (Athlon 1.7GHz, 512 MB RAM).
• Used exploit programs from securiteam.com and
  insecure.org.

44
Run-time Overhead

• The following two graphs show run-time overhead
  for programs compiled in DIR-mode

45
Signature Generation

• Signatures were produced for all programs that we
  had exploits for. ghttpd signature specifies
  length constraint using terminating character
  named signature specifies maximum value of the
  length field. The drcatd signature has three
  packets in it login, password, and the attacking
  packet

46
Is Recovery Really Useful?

• Recovery incurs significant overhead. Is it
  really better than just terminating the
  application? Yes, because
• Terminating a single-threaded program disconnects
  all clients.
• Same tradeoff exists in the case of source-code
  checking tools using them requires developers
  time investment and we can always use Stackguard
  instead to protect the programs.

47
Outline of the Talk

• Introduction
• Related Work
• DIRA Architecture
• Attack Detection
• Attack Identification
• Attack Repair
• Performance Evaluation
• Conclusion

48
Conclusion

• DIRA solves the problems of attack detection,
  identification, and repair in a unified way.
• It produces accurate multi-packet signatures from
  a single attack instance.
• Dynamic slicing of the memory updates log is the
  underlying technique.
• Same technique can be used for automatic patch
  generation our future work.

49
Questions? http//www.ecsl.cs.sunysb.edu/dira
