Scruffy Validation

1
Scruffy Validation

• Alex BrownGriffin Brown Digital Publishing Ltd.

2
Menu

• Background
• A Case Study using the NLM DTD
• Limitations of neat grammars
• Possible solutions
• XPath-based validation
• The user perspective
• Seeing it work
• Other scruffy validation problems

3
Background

• Neat vs. Scruffy a common opposition in
  computing
• Neat algorithmic, function-based, mathematical
• Scruffy heuristic, procedural, narrative

4
Neat Validation

• DTDs, Relax-NG (for example) grammar-based
  schema languages
• Syntax-directing, so suitable for editor
  implementations
• In practice, models can be represented
  diagrammatically

5
Scruffy Validation

• Includes many non-grammatical tests, shading into
  application-specific data testing (aka business
  rules)
• Sees validation not as a boolean test but as a
  more nuanced report on a instances state good
  enough
• Includes concept of validation management from
  user perspective

6
A Simple Example

• NCBI/NLM DTD family http//dtd.nlm.nih.gov/publish
  ing/
• Journal Publishing application enjoying some
  traction
• State of the art DTD

7
NCBI/NLM Publishing DTD
8
NCBI/NLM Publishing DTD
9
Data Rules

• The ltfpagegt and ltlpagegt elements should have
  numeric content
• If one exists, both must exist
• The number contained by ltlpagegt must be equal to
  or greater than that contained by ltfpagegt

10
The DTD cannot enforce this

• Content model is(PCDATA fpage lpage )

• Enforcement of the data rules is beyond the
  abilities of the schema language.

11
Solution 1 Programming

• Either using specialised XML processing language,
  or standards-based approach (SAX)
• Pseudocode
• When ltfpagegt is encountered, check value and
  store
• When ltlpagegt is encounteed, check format and
  compare with stored ltfpagegt value

12
Advantages of SAX-based validation

• Powerful the limits are those of the
  implementing system
• Fast execution stream based parsing is fast
• Memory efficient no need to build in-memory
  tree may be only route for certain applications

13
Disadvantages of SAX-based validation

• Can be cumbersome to code
• Therefore is difficult to maintain moves
  validation firmly into the realm of software
  development
• Conceptually messy it feels like theres a
  generalisation to be made (API?)

14
Solution 2 Schema Language

• Schematron, XMLProbe/SILCN, CLiX,BI-ICS4J XSLT
• Generally higher-level expression of rules in
  XML! (well )
• Generally, built around an in-memory tree
  representation of XML to be tested

15
Using XPath to express a constraint

• //lpagematch-regexp("(\d)",.) and
  match-regexp("(\d)",preceding-siblingfpage)
  not(number(.)gt number(preceding-siblingfpage
  ))
• N.B. XPath has here been extended (thus we have a
  route to the power of the implementing system)

16
Advantages of XPath-based validation

• In harmony with XML model extensible (and needs
  to be!)
• Visual tools available for expression testing
• Maintainable by non-programmers

17
Disadvantages of XPath-based validation

• Needs an in-memory tree
• Not suitable for certain kinds of testing, where
  programming is required, and the result is more
  complex than a node list
• NB where XPath is, XQuery will be

18
Fitting Scruffy Validation into a Process
Well-formed?
NeatValidation
ScruffyValidation
DTDRELAX NGW3C Schema
SchematronXSLTXMLProbe
XML 1.0/1.1
19
Finding interesting nodes
20
The User Perspective Reporting Data Faults

• Users ideally want to know
• What is wrong
• Why (or how much) its wrong
• Where its wrong
• How to fix it
• Not good enough to say this is a quality of
  implementation issue

21
Zooming Out Deviations from Neatness

• Some defects may be acceptable
• Correctness may ultimately only be decidable by a
  human
• Different audiences may want different views onto
  data validation reports

22
A Comparison with Software Development

• lint purify augmenting syntax checking
• For many users XML validation is stuck in the 80s
  (generally)
• This is partly a tools issue but XML can help

23
XML Can Help

• XML validation tools should emit reports in XML
  (preferably in a well-defined language)
• Constraints should have identity
• Bad nodes should be located within the tested
  instance, and associated with the constraint they
  have violated
• formal statement this has gone wrong here

24
this has gone wrong here

• Enables filtering (and other transformation) of
  results
• Enables annotation of source instance
• Enables onward machine processing of all kinds

25
In Practice

• An instance
• A rule
• Processing
• Result (XML)
• Result (styled)

26
Other scruffiness

• Content-mandated structure, e.g.
• Urls should be marked-up //not(name()'uri')
  and not(name()'ext-link')text()match-regexp("\
  bwww.", .) or match-regexp("\bhttp", .)
• Conformance to non-XML specifications (e.g. ISO
  formats)

27
Other scruffiness (contd.)

• Co-location tests (long-range grammar)
• Lexical checks (on CDATA marked sections, entity
  use, PI format, comments, e.g.)
• External resource availability / type (moving
  beyond validation?)

28
Other scruffiness (contd.)

• Tables !
• Constrained vocabulary checking
• Weird stuff (no numeric character entities?)

29
Conclusions

• XML datasets have data quality problems beyond
  the scope of neat validation languages
• There is scope to generalise beyond custom
  programming
• Most XML processing pipelines need one!
• Consider unchecked data faulty

30
Any Questions?
