AccuDraw 2D and 3D
Toni Kucan Kansas Department of Transportation
Rex Kraus Kansas Department of Transportation
2
Getting Started

• To start click on the Accudraw Button on the main
  tool bar. It looks like a T square with a
  triangle sitting on top of it.

3
Deactivate Accudraw

• Ways to deactivate Accudraw
• Just shut the window down
• The other is to hit the Q button.

4
Accudraw Setting

• Settings box can be displayed 2 ways under the
  settings pull down or hitting G and S.
• Changes that can be made in the settings window
• Context Sensitivity
• How to bring up short cut window
• How some of the sort cuts work

5
(No Transcript)
6
Accudraw Short cut

• How to bring up short cut window hold the shift
  key then hit the ?
• How some of the sort cuts work
• Add new short cut keys
• Edit existing Short cut keys

7
Using AccuDraw in 2D

• Lock the X or Y axis
• Change from polar to rectangular
• Rotate views
• Snaps with Accudraw
• Type in lengths for lines, radius, offsets and
  many more.

8
2D Short cut key-in

• N - Nearest
• C Center Snap
• I - Intersection
• O Origin
• A Angle Lock
• RQ Rotate Quick
• B Change the Campus back to square

9
Using AccuDraw in 3D

• Start and ending AccuDraw is the same as
  Microstation 2D.
• Changing drawing plans
• Short cut Key-ins for 3D

10
3D Short cut key-in

• All the ones I mentioned for 2D work in 3D with
  some additions
• F Front View
• S Side View
• T Top View
• B Base View
