Telecommunications

1
Telecommunications Networks
2
Structure of the Internet

• IP address (Internet Protocol)
• Packet
• Router
• TCP/IP Video

3
Communications Media

• Communications medium
• The hardware that connects computers and other
  digital equipment
• Bandwidth
• Indicates how much data can be transferred
  through the medium in a fixed amount of time
• Usually measured in bits per second (bps)

4
ANALOG SIGNAL

• CONTINUOUS WAVEFORM
• PASSES THRU SYSTEM
• VOICE COMMUNICATIONS

5
DIGITAL SIGNAL

• DISCRETE WAVEFORM
• TWO DISCRETE STATES
• 1-BIT 0-BIT
• ON / OFF PULSE
• DATA COMMUNICATION
• USES MODEM TO TRANSLATE ANALOG TO DIGITAL,
  DIGITAL TO ANALOG

00101110100111010010101011101111001000100001011110
10110100111010010010110010101101100
6
COMMUNICATION CHANNELS

• MEANS BY WHICH DATA ARE TRANSMITTED
• TWISTED WIRES (Copper Wires)
• COAXIAL CABLE (Insulated Copper Wires)
• FIBER-OPTIC CABLE
• MICROWAVE

7
FIBER OPTICS

• SUPER CLEAR GLASS STRANDS
• FAST, LIGHT, DURABLE
• BILLIONS OF BITS PER SECOND, FULL DUPLEX
• EXPENSIVE, HARDER TO INSTALL
• OFTEN USED AS BACKBONE OF NETWORKS

8
5.3.2 Communications Media

• Fiber-optic cable
• Composed of flexible glass fiber, is thinner and
  lighter than traditional copper wire, yet has
  much wider bandwidth
• Uses short bursts of light to represent bits
• Optical modem
• Modem stands for modulator and demodulator
• Translates digital signals from computers into
  light through a process called modulation
• Opto chip
• Converts the most basic particle of light, the
  photon, into an electric current
• Allows tremendous amounts of data to be sent over
  fiber-optic networks through particles 100 times
  smaller than the diameter of a human hair

9
ORBITING SATELLITES
MICROWAVE TRANSMISSION
UPLINK
DOWNLINK
10
WIRELESS TRANSMISSION TECHNOLOGIES

• PAGING SYSTEM Small pager beeps when receives
  short message
• CELLULAR TELEPHONE Device uses radio waves to
  reach antennas within areas called cells
• MOBILE DATA NETWORKS Radio - based data network
  using hand-held computers cheap, efficient

11
WIRELESS TRANSMISSION TECHNOLOGIES

• PERSONAL COMMUNICATION SERVICE Cellular lower
  power higher frequency. Smaller phones not
  shielded by buildings, tunnels
• PERSONAL DIGITAL ASSISTANT Pen sized,
  hand-held, digital communicator
• SMART PHONE Wireless, voice, text, Internet

12
SPEEDS COST OF MEDIA
13
Connecting to the Internet

• Most home users subscribe to an Internet Service
  Provider (ISP) to connect to the Internet
• Analog modem
• Takes digital signals from the computer and turns
  them into analog signals
• A modem at the ISP then converts the sound back
  into a digital signal that can be transmitted
  over the Internet

14
Integrated Services Digital Network (ISDN)

• Provides high-speed connections to the Internet
  over both digital and standard telephone lines
• Limited service
• Costly connection

15
Digital Subscriber Lines

• Digital Subscriber Lines (DSL)
• Offers high-bandwidth Internet access over
  existing copper telephone lines
• Splits your phone line into three
  information-carrying channels
• DSL connections require special hardware at the
  local telephone companys central office and at
  the users location

16
Digital Subscriber Lines

• IAD (integrated access device)
• High-speed Internet access, and for multiple
  voice lines
• ADSL (asymmetric DSL)
• Speed for sending data (upstream) is slower than
  for receiving (downstream)
• VoDSL (voice over DSL)
• Voice services and high-speed data access over a
  single telephone line
• SDSL (symmetric DSL)
• Same speed both upstream and downstream

17
T-1 and T-3 Lines

• T-1 line
• A dedicated connection that supports data rates
  of 1.544 Mb per second
• Made up of 24 channels
• T-3 line
• Supports data rates of 43Mbps and is made up of
  672 channels that each support 64Kbps
• T-1 and T-3 lines can be used for both voice and
  data communication

18
Technology Speed
19
Broadband

• A category of high-bandwidth Internet service
• Can handle voice, data and video information
• Enables videoconferencing, real-time voice and
  streaming-media applications

20
Internet2

• Consortium developing next generation of the
  Internet
• Abeline - A high-speed network able to transfer
  2.4 gigabits of data per second
• Teleimmersion - Allows users to share information
  in real timeeven 3D images
• Virtual laboratory - Enable researchers worldwide
  to collaborate on projects
• Digital libraries - Storage of audio and video
  files enabling a search capabilities.

21
Metromedia Fiber Network
22
Software

• Application Service Providers
• Databases

23
Application Service Provider

• Provide customized business software applications
  over the Internet
• Maintains and updates the application as
  necessary
• Companies can eliminate the costs associated with
  developing and maintaining business applications
• Virtual private networks (VPNs) using the
  point-to-point tunneling protocol (PPTP)

24
Databases

• Database management system (DBMS)
• Provides mechanisms for storing and organizing
  data in a manner that facilitates satisfying
  sophisticated queries and data manipulations
• Structured Query Language (SQL
• Almost universally used with relational database
  systems to make queries (i.e., to request
  information that satisfies given criteria) and
  manipulate data

25
Databases

• Relational database model
• A logical representation of the data that allows
  the relationships between the data to be
  considered independently of the physical
  implementation of the data structures
• Popular enterprise-level relational database
  systems Microsoft SQL Server, Oracle , Sybase ,
  DB2

26
Enhancing Business Communication

• Intranets Extranets
• Streaming audio and video
• Internet telephony - Makes PC-to-PC and
  PC-to-phone calls possible, dramatically reducing
  the cost of communication
• Web casting
• Virtual conferencing
• Wireless technology

27
Intranets and Extranets

• Intranet
• An organizations internal network that uses
  TCP/IP protocols of the Internet
• Only authorized parties have access to an
  organizations intranet
• Used to store internal information
• Extranet
• An intranet that is accessible by authorized
  external parties who are not employees of the
  organization
• Employees might have unrestricted access to
  information on the extranet, whereas customers or
  vendors might have access to a limited subset of
  that information

28
Webcasting and Web Conferencing

• Webcasting
• Broadcasting over the Web
• Businesses can stream seminars, conferences,
  shows, sales presentations and more though their
  Web sites
• Live or prerecorded
• Web conferencing
• Allows businesses to meet and collaborate online,
  in real time from anywhere in the world

29
NETWORK TOPOLOGIES
STAR
30
NETWORK TOPOLOGIES
BUS
31
NETWORK TOPOLOGIES
RING
32
LOCAL AREA NETWORKS

• Limited distance (less than 2000 foot radius
• Share expensive hardware software
• GATEWAY Connection to other networks
• ROUTER Forwards data to other networks
• NETWORK OPERATING SYSTEM (NOS) Manages file
  server routes communications on network
• PEER - TO - PEER In some small networks all
  computers have equal power

33
WIDE - AREA NETWORK (WAN)

• Network spans large geographic distances. Can
  include cable, satellite, microwave
• SWITCHED LINES Route determined by current
  traffic
• DEDICATED LINES Constantly available for
  high-volume traffic

34
VALUE-ADDED NETWORK (VAN)

• PRIVATE MULTIPATH DATA ONLY
• 3rd PARTY MANAGED
• USED BY SEVERAL ORGANIZATIONS
• SUBSCRIPTION BASIS

35
TELECOMMUNICATIONS PLAN

• KNOW LONG-RANGE PLANS
• AUDIT EXISTING CAPABILITIES
• IDENTIFY, PRIORITIZE CRITICAL IMPROVEMENTS
• ENHANCE FIRMS STRATEGIC POSITION
• IMPLEMENT PLAN

36
IMPLEMENTATION FACTORS

• DISTANCE
• RANGE OF SERVICES
• SECURITY
• MULTIPLE ACCESS
• UTILIZATION
• COST
• INSTALLATION
• CONNECTIVITY

37
Getting a Technology Job

• http//www.techjobsonline.com
