SOWN Code Review

1
SOWN Code Review

• Top-level Control

2
SOWN Configuration
SOWN
Main
MainControlC
TripWireM
BackboneC
RoutingC
TimeSyncC
etc.
SD

• SOWN.nc and MainControlC.nc specify wiring of
  components

3
MainControlC Wiring Details
4
SOWN Files

• Makefile
• SOWN.nc
• SOWN configuration definition
• MainControl.h
• System states
• MainControl.nc
• Interface definition
• MainControlC.nc
• Wiring of components
• MainControlM.nc
• Implementation of top-level state-machine

5
MainControl.h

• / legitimate system phases/states /
• enum
• STATE_CHAOS,
• STATE_INIT,
• STATE_SYSSYNC,
• STATE_LOCALIZE,
• STATE_DISCNEIGHBORS,
• STATE_BUILDBACKBONE,
• STATE_COMMITBACKBONE,
• STATE_SENTRYSEL,
• STATE_STATUS_REPORT,
• STATE_PM,
• STATE_TRACKING_PM,
• NETWORK_STATES

6
MainControl.nc

• interface MainControl
• command result_t start()
• command result_t stop()
• command result_t setParameters (phaseDelay,
  PM_COUNT, SendPowerForSentrySelection,
  reportPeriod)
• command bool isSentry()
• command result_t getMySentry(id)
• command result_t getSentries(sentries,
  num_sentries)
• command result_t getNonsentries(nonsentries_ptr
  , num_nonsentries)
• event result_t ready (bool isReady)
• command result_t getNetworkStatus()

Delegated to SentrySelC
7
MainControlC.nc

• Uses components
• MainControlM, BackboneC, ReportC, TimeSyncC, SD,
  TripWireM, TimeUtilC, TimerC, SentryPmC,
  SentrySelC, RandomLFSR, LedsC, ResetC, LocalC,
  TrackingC, GenericBaseRecvC, RoutingC,
  ConfigureC, DebugC, GenericComm, RadioResetC,
  RadioModelC, XTestXnpM, XnpC, CC1000ControlM
• Wiring as shown previously

8
MainControlM.nc Data

• uint8_t state
• uint8_t phase_bits
• bool DynamicSettingDone
• bool GlobalTimeDone
• uint32_t round_start_time
• uint16_t roundCount 0
• uint8_t sending_power_for_sensing_radius
• uint32_t PHASE_DELAY
• uint32_t REPORT_PERIOD
• uint16_t PM_PHASE_COUNT
• uint8_t SENTRY_SEND_POWER
• uint32_t SYNC_DELAY

State of network
Progress flags
Round start and counter
For sentry selection
9
MainControlM.nc Functions

• command result_t StdControl.init()
• command result_t StdControl.start()
• command result_t StdControl.stop()
• command result_t MainControl.start()
• event result_t Configure.SettingsReady(...)
• command result_t MainControl.setParameters(...)
• event result_t SysSync.GlobalTimeReady()
• event result_t PhaseTransitionTimer.fired()
• event uint8_t Backbone.GenericReceive(...)
• event result_t PM.wakeup()
• event result_t PM.sleep()

NOP
10
Initialization

• StdControl.init()
• Initialize Leds, Random, SysSyncControl,
  SDControl
• Initialize module data
• StdControl.start()
• Call Debug.start(), MainControl.start()
• MainControl.start()
• Set STATE_CHAOS, radio power
• Start 5s timer

11
MainControlM State Diagram
12
PhaseTransitionTimer.fired()

• STATE_CHAOS
• roundCount
• call Configure.start()

13
Configure.SettingsReady()

• // only do the following once
• DynamicSettingDone TRUE
• state STATE_INIT
• post ReportTask()
• ResetNodeStatus()
• stop sub-component timers
• initParameters(settings)
• save and push settings down to components
• call PhaseTransitionTimer.start
  (TIMER_ONE_SHOT,1000
• call Random.rand()1000)

14
PhaseTransitionTimer.fired()

• STATE_INIT
• call Configure.stop()
• EnableSync()
• sets master/slave for time sync
• call SysSyncControl.start()

15
SysSync.GlobalTimeReady()

• GlobalTimeDone TRUE
• state STATE_SYSSYNC
• post ReportTask()
• get global time and compute delay until round
  start (6 GridX 5s)
• call PhaseTransitionTimer.start2 (TIMER_ONE_SHOT,
  round_start_time - now )

16
PhaseTransitionTimer.fired()

• STATE_SYSSYNC
• state STATE_LOCALIZE
• post ReportTask()
• call SysSyncControl.stop()
• call Local.start( PHASE_DELAYgtgt2)
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  PHASE_DELAY)
• if (!call TripWire.isTripWireBase())
• call RoutingControl.init()

17
PhaseTransitionTimer.fired()

• STATE_LOCALIZE
• call Local.stop()
• if (localized)
• state STATE_DISCNEIGHBORS
• post ReportTask()
• call SDControl.start()
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  2PHASE_DELAY)
• else
• state CHAOS
• call RoutingControl.init()
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  5000)

18
PhaseTransitionTimer.fired()

• STATE_DISCNEIGHBORS
• state STATE_BUILDBACKBONE
• post ReportTask()
• call SDControl.stop()
• if (call TripWire.isTripWireBase())
• call SentrySel.setSentry(TRUE)
• call Backbone.build(BRODCAST_PERIOD)
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  PHASE_DELAY)

19
PhaseTransitionTimer.fired()

• STATE_BUILDBACKBONE
• state STATE_COMMITBACKBONE
• post ReportTask()
• call Backbone.commit()
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  SHORT_PHASE_DELAY)

20
PhaseTransitionTimer.fired()

• STATE_COMMITBACKBONE
• state STATE_SENTRYSEL
• post ReportTask()
• call Backbone.stop()
• call SDNeighborTable.free()
• call SentrySel.reset()
• set non-leaves to be sentries
• if (!call TripWire.isTripWireBase())
• call SentrySel.startSelection(sending_power...,
  PHASE_DELAY)
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  PHASE_DELAY)

21
PhaseTransitionTimer.fired()

• STATE_SENTRYSEL
• state STATE_STATUS_REPORT
• post ReportTask()
• call SentrySel.stopSelection()
• call Report.startReport(REPORT_PERIOD)
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  2 PHASE_DELAY)

22
PhaseTransitionTimer.fired()

• STATE_STATUS_REPORT
• state STATE_PM
• post ReportTask()
• call Report.stopReport()
• call PM.enable()
• call WakeupCom.EnablePowerM(TRUE)
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  SHORT_PHASE_DELAY)

23
PhaseTransitionTimer.fired()

• STATE_STATUS_PM
• state STATE_TRACKING_PM
• post ReportTask()
• call Tracking.init()
• call Tracking.start()
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  PHASE_DELAY PM_PHASE_COUNT)

24
PhaseTransitionTimer.fired()

• STATE_STATUS_TRACKING_PM
• state STATE_CHAOS
• post ReportTask()
• if (!call TripWire.isTripWireBase())
• Reset.reset()
• else
• call PhaseTransitionTimer.start (TIMER_ONE_SHOT,
  SHORT_PHASE_DELAY)
• ResetNodeStatus()

25
task ReportTask

• call Leds.set(state)
• call Report.ReportNetworkStatus(state)

26
MainControlM State Diagram
