A Framework for Packet Trace Manipulation

1
A Framework for Packet Trace Manipulation

• Christian Kreibich

2
Motivation

• Say you need to solve a problem that involves
  manipulating network traffic
• complex filtering (e.g. data analysis)
• fine-grained editing (e.g. header field bitflips)
• large-scale editing (e.g. anonymization)
• visualization (e.g. behavioural analysis)
• What do you do?

3
Motivation II

• Find a tool that does it
• where? ?does it build? ?maintained?
• If so, lucky you!

4
Motivation II

• Find a tool that does it
• where? ?does it build? ?maintained?
• If so, lucky you!
• Mhmm ... write your own.
• Okay, pcap.
• Now you typically need infrastructure
• data types ?conn. state tracking ?protocol
  header lookup
• Lots of duplicated effort
• Cutnpaste is bad

5
Motivation III

• Current practice

6
Introducing ...

• Netdude NETwork DUmp Data Editor
• Framework for packet inspection and manipulation
• Multiple usage paradigms GUI command line
• Scales to arbitrary trace sizes
• Reusable at all levels
• Extensible

7
Architecture
8
Architecture
9
Architecture
10
libpcapnav

• Enables random packet access
• Jump to arbitrary timestamps and fractional
  offsets
• Thin wrapper around pcap
• Based on Vern Paxsons tcpslice tool
• Uses heuristics to get in sync with packet stream
• Slightly more robust algorithm
• Harder to fool ? Tolerates packets not in
  temporal order
• Nasty accidental test case trace of NFS-copied
  trace

11
Architecture
12
libnetdude

• Packet manipulation back-end
• Transparent handling of arbitrarily large traces
• High-level data types
• Extensible through plugin mechanism
• connection tables, flow demuxer, flow reassembly,
  TCP connection filter, importers/exporters,...
• Structured packet content easy header access,
  protocol plugins provide the knowledge
• Provides per-packet tcpdump output
• Observer/observee API to be informed of updates

13
Handling big trace files

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

14
Handling big trace files

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

15
Handling big trace files

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

16
Handling big trace files II

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

17
Handling big trace files II

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

18
Handling big trace files II

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

19
Handling big trace files II

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

20
Handling big trace files III

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

21
Handling big trace files III

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

22
Handling big trace files III

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

23
Handling big trace files III

• Always limit the number of packets in memory
• Cant just mmap() if you want to insert/delete
• Edit at granularity of trace areas libpcapnav
  helps
• Modified trace areas become layered trace parts

24
Architecture
25
Netdude GUI

• GTK-based front-end to libnetdude (sorry Matthias
  -)
• Extensible through protocol and feature plugins
• Protocol plugins visualize header content
• Feature plugins can essentially do anything
• Uses libnetdudes observer API to update GUI

26
Demo

• Fingers crossed, please.

27
Experience

• Fine-grained header field modifications
• M. Handley, C. Kreibich, V. Paxson Network
  Intrusion Detection Evasion, Traffic
  Normalization, and End-to-End Protocol Semantics,
  9th USENIX Security Symposium, 2001
• Large-scale filtering and reassembly
• A. Moore, J. Hall, C. Kreibich, E. Harris, I.
  Pratt Architecture of a Network Monitor, PAM
  Workshop, 2003
• Fine-grained payload editing
• C. Kreibich, J. Crowcroft Honeycomb - Creating
  Intrusion Detection Signatures Using Honeypots,
  HotNets II, 2003

28
Future Work
Progress Chart
Visual interpretation
0
1
Perceived length (normalized)
29
Future Work
Progress Chart
Visual interpretation
0
1
Perceived length (normalized)
30
Future Work
Progress Chart
Visual interpretation
0
1
Perceived length (normalized)
31
Future Work
Progress Graph
Visual interpretation
0
1
Perceived length (normalized)

• Seriously, lots to do
• Packet resizing ? Less coding ?
  Scriptability
• Help me out!

32
Dont get me wrong ...
?

• I

• Well, mostly -)

33
Summary

• Framework for packet trace manipulation
• Can handle traces of arbitrary size
• Multiple usage paradigms GUI command line
• Reusable at all levels
• libpcapnav for navigation
• libnetdude for packet mangling
• Netdude GUI for visualization
• Extensible through protocol and feature plugins

34
Thanks!

• Shoutouts to all contributors!
• Debian packagers needed ...
• Questions?
• http//netdude.sf.net
