ECE-1466 Modern Optics Course Notes Part 8

1
ECE-1466Modern OpticsCourse NotesPart 8

• Prof. Charles A. DiMarzio
• Northeastern University
• Spring 2002

2
Phase Microscopy

• Differential Interference
• Phase Contrast
• True Phase Microscopy
• Phase Reconstruction from Amplitude

3
Phase Contrast Microscopy
F
F
F
F
A
A
Obscuration in Pupil Plane Removed DC and Low
Spatial Frequencies
4
Phase Contrast 1-D Example
5
Phase Contrast 2-D Example
Image Plane
Pupil Plane
6
Differential Interference Contrast
Polarizing Cube at Illumination Lens Splits Beam
and Another Polarizing Cube at the Objective Puts
it Back Together.
7
DIC 1-D Example
8
Quadrature Imaging Concept
Quadrature
Balanced Mixing
9
How Could QTM Count Cells in Compact Embryo?
QTM Phase
DIC
Assumed Index Profile Before Compaction
M10026.m
M10026.m
Assumed Index Profile During Compaction
M10026.m
M10026.m
10
Phase Retrieval from Amplitude
Measure Irradiance at Plane A
Measure Irradiance at Plane B
Guess Field at Plane A
Object
A
B
Keep Phase, and Change Amplitude to Match the
Measurement
Compute Field at Plane B
Keep Phase, and Change Amplitude to Match the
Measurement
Compute Field at Plane A
