Advances in Structural Software

1
Advances in Structural Software

• 2006 - 2007

2
Oasys Structural Suite
3
Ongoing maintenance
4
ADC

• Concrete Analysis and Design

5
ADC 8.1 - International codes
BS 8110 1985 BS 8110 1997 BS 8110 1997 (2005)
EN 1992-1-12004 Eurocode 2
Code of Practice 1987 Code of Practice 2004
6
ADC 8.1 - interface
7
ADC 8.1 - interface
8
Compos

• Composite Beam floor analysis and design

9
Compos 8.0 - improved output
10
AdSec

• Non-linear section analysis

11
AdSec - International design codes
BS 8110 1985 BS 8110 1997 BS 5400
EN 1992-1-12004 Eurocode 2
Code of Practice 1987 Code of Practice
2004 Structures Design Manual 2002
12
AdSec 8.0 - International design codes
BS 8110 1985 BS 8110 1997 BS 8110 1997
(2005) BS 5400
EN 1992-1-12004 Eurocode 2
Code of Practice 1987 Code of Practice
2004 Structures Design Manual 2002
ACI 318 2002 ACI 318M 2002
AS 3600 2001
IS 456 2000
13
AdSec - existing Template Reinforcement
14
AdSec 8.0 - new Template Reinforcement
15
AdSec 8.0 - New Materials
16
AdSec 8.0 - user defined materials
17
GSA

• General Structural Analysis and design

18
GSA 8.2 - Footfall Analysis

• Footfall induced vibration (vertical) in floors
  and stairs
• Arup SCI methods
• Constant or calculated damping for each vibration
  modes

19
GSA 8.2 - Footfall Response of Stair
20
GSA - Footfall Response Chart Views
21
GSA 8.2 - Harmonic Analysis Option

• Structural responses at steady state under
  harmonic loads
• A frequency range can be given for the same
  harmonic analysis to enable the evaluation of the
  critical harmonic frequency

22
GSA 8.2 - Non-linear spring element

• User defined force/moment displacement/rotation
  curve of springs
• Tension and compression curve can be different

23
GSA 8.2 - Sparse Solver

• New GSS solver option
• Allows much larger models to be analysed than the
  traditional active column solver

24
GSA 8.2 - Constraint Equations

• Allow constraint to be applied to a node (the
  slave) as a function of the displacement of other
  nodes (the masters)
• Constraint equations generalise the constraint
  types in GSA Restraints, Settlements, Joints,
  Rigid Constraints

25
GSA 8.2 Plate Buckling

• Modal buckling of 2D plates

26
GSA 8.2 - Revit Structure link

• GsRevit is a Revit Structure plug-in
• Export from Revit to GSA
• Update Revit model from GSA model
• Import from GSA to Revit

27
GSA 8.2 - Revit Model
28
GSA 8.2 - GsRevit GSA model
29
GSA 8.2 - Revised Grids
30
GSA 8.2 - New Geometric Entities
Adding Grid Nodes and Lines at intersection of
Grid Lines
31
GSA 8.2 - New Geometric Entities
Lines bounding an Area
32
GSA 8.2 - New Geometric Entities
A Region with bounding Area, an internal void
Area and Grid Nodes.
33
GSA 8.2 - Region prepared for meshing
A Region with adjacent bounding Areas, internal
Grid Nodes, Lines and Areas, one of which is void.
34
GSA 8.2 - the meshed region
The resulting mesh takes into account the
internal Grid Nodes, Lines and Areas.
35
GSA 8.2 - RC Member Design
36
GSA for Free

• First order analysis
• Limited elements and nodes

37
Oasys Structural Suite
