Power Tool Revision Questions
PCS
2
Screwdriver Bit
Cordless Drill
Keyless Chuck
Forward / Reverse Switch
Adjustable Clutch
On / Off switch
Battery Pack
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
3
Delta Sander
On/Off Switch
Flex
Sanding Pad
Dust Extraction Port
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
4
The Pillar Drill
Q. Name the machine shown on the left
Q. List three safety precautions you would take
when using this machine
A. Wear Goggles, Tie long hair back Tuck in
loose clothing.
5
The Pillar Drill
On / Off Switch
Depth Stop
Drill Chuck
Table
Q. Name the parts of the pillar drill shown on
the left
6
On/Off Lock Button
Jig Saw
Variable Speed Control
Flex
Pendulum Adjustment Lever
Blade
On / Off Switch
Base Plate
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
7
Mortise Machine
Depth Stop
Q. Name the machine shown on the left
Chisel
Q. Name the parts of the machine shown
Q. Name the Joint shown below
Mortise Tenon Joint
8
Portable Belt Sander
Dust Collection Bag
On/Off Button
Q. Name the tool shown above.
Belt
Q. Name parts of the tool indicated above.
9
Revolving Centre
Forked Centre
Headstock
Tailstock
Bed
ToolPost
Toolrest
On/Off Switch
Q. Name the machine shown?
Q. Name the parts of the machine shown above?
Wood Lathe
10
4kg SDS Hammer Drill
Hammer On/Off Switch
On/Off Switch
Variable Speed Control
SDS Chuck
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
11
BeltSander
PowerIsolator
DiskSander
Q. Name the machine shown?
Q. Name the parts of the machine shown above?
12
Orbital Sander
Variable Speed Control
Flex
On / Off Switch
Q. Name the tool shown above.
Q. Name parts of the machine indicated above.
13
Biscuit Jointer
Beech Biscuit
On/Off Button
Flex
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
14
Router
On/Off Button
Depth Stop
Router Bit
Q. Name the tool shown above.
Q. Name parts of the tool indicated above.
15
The End
