NIC Components Corp.

1
NIC Components Corp.

• Low ESR Capacitors

2
What is ESR?

• ESR is an abbreviation for Equivalent Series
  Resistance, the characteristic representing the
  sum of resistive (ohmic) losses within a
  capacitor.
• While ESR is undesirable, all capacitors exhibit
  it to some degree. Capacitor manufacturers look
  to ways to reduce the ESR of the capacitor

3
Low ESR Capacitor Applications

• DSL equipment
• Computers Servers
• Networking Routers
• Telecom equipment,
• Semiconductor etching equip
• FM transmitters
• Power Supplies
• Broadband
• Ballast
• A/V remote control
• Slot machines, gaming tables

• Controller boards
• Ethernet
• Video Interfaces
• Servers
• Laser printers
• Optical Networking
• Storage Area Network Equipment
• Motherboards, routers, servers, mini PC
• Smoke detectors, alarms, sensors
• Lighting Ballast

4
Market Segments

• Computer
• Medical
• Automotive
• Telecommunications
• Industrial Control

5
Associated Sell

• Microprocessors
• Heat Sinks
• PC board mount fans
• Power Transistors

6
Low ESR Electrolytic Capacitors

• NIC Components Corp.
• Product Offering

7

• Low ESR Electrolytic Capacitors
• Aluminum
• Liquid Electrolyte NACZ, NACZF, NACX
• V-Chip larger size SMT
• Lowest Cost of SMT types
• Highest capacitance values (to 6800uF)
• Highest ESR of the low ESR family
• Wears out (electrolyte dissipation) under high
  temperature operation
• Crosses to
• Elna RVH series
• Nichicon UWF UUJ series
• Panasonic FC series
• Sanyo CV-GV

8

• Low ESR Electrolytic Capacitors
• Aluminum
• Hybrid Electrolyte NSPE
• V-Chip
• 22uF 820uF
• Moderate Cost
• 0.025 100KHz ESR
• BEST VALUE OF LOW ESR FAMILY
• Wears out (electrolyte dissipation) under high
  temperature operation

9

• Low ESR Electrolytic Capacitors
• Aluminum
• Solid Electrolyte NSP
• Small Flat Chip (D- 7343 case)
• 2.2uF 270uF
• 0.010ohm 100KHz ESR Specs
• BEST LONG TERM PERFORMANCE OF LOW ESR FAMILY
• Solid Electrolyte does not exhibit WEAR-OUT
• LOWEST ESR HIGHEST COST
• NSP Crosses to
• Panasonic - CD series ( same specs sizes)
• Kemet A700 series

Solid OS-CON Organic Semi-Conductor ,
Polymer Aluminum, Solid Aluminum (all terms
for the same thing)
10

• Low ESR Electrolytic Capacitors
• Aluminum
• Solid Electrolyte NSPZ
• V-Chip
• 15uF 680uF
• 0.020 ohm 100KHz ESR
• BEST LONG TERM PERFORMANCE OF LOW ESR FAMILY
• Solid Electrolyte does not exhibit WEAR-OUT
• LOW ESR HIGH COST
• NSPZ Crosses to
• Sanyo SV SVP SVQP series OS-CON
• Nichicon NA series
• Vishay 94SV, OS-CON
• United Chemi-Con - PX series

Solid OS-CON Organic Semi-Conductor ,
Polymer Aluminum, Solid Aluminum (all terms
for the same thing)
11

• Low ESR Electrolytic Capacitors
• Tantalum
• Polymer Cathode NTP
• Small Flat Chip (A D sizes)
• 3.3uF 470uF
• 0.025 ohm 100KHz ESR
• Lowest ESR Tantalum type
• Polymer Cathode suppressions combustion
  improved safety
• HIGHEST COST of tantalum types
• NSP Crosses to
• NEC - PSL PSN series ( same specs sizes)
• Kemet KO-Cap - T520 series
• Sanyo- POS-Cap TPA, TPB, TPC series
• Nichicon- F55 series

Also referred to Polymer Tantalum, KO-CAP
or POS-CAP (all terms for the same thing)
12

• Low ESR Electrolytic Capacitors
• Tantalum
• Standard Cathode (MnO2) NTC-L
• Small Flat Chip (B D sizes)
• 10uF 330uF
• 0.10 0.70ohm 100KHz ESR Specs
• Solid Electrolyte does not exhibit WEAR-OUT
• Lower costly than NTP (polymer cathode) series
• NTC-L Crosses to
• AVX TPS series
• Cornell Dubilier SHJL series
• Kemet T494 T495 series
• NEC SVZ
• Vishay Sprague 593D

13

• Low ESR Electrolytic Capacitors
• Aluminum
• Liquid Electrolyte NRSZ, NRSX, NRSY, NRSJ, NRSG
  NRSX
• Radial can largest sizes
• Lowest Cost (up to ½ the cost of SMT versions)
• Highest capacitance values (to 15,000uF)
• Lowest ESR (to 0.012 ohm) of leaded type
  products
• Wears-out (electrolyte dissipation) under high
  temperature operation

14
Series Cross Reference
