Sound Waves From the Northern Lights

1
Sound Waves From the Northern Lights
Jada Maxwell
Photo courtesy of Bjorn Jorgensen, 18 January
2005, near Tromsø, Norway http//www.spaceweather.
com/aurora/images2005/17jan05/Jorgensen1.jpg
2
Synergy means behavior of whole systems
unpredicted by the behavior of their parts taken
separately.- Buckminster Fuller
3
Can magnetic waves in the aurorae transform into
sound waves?

• What creates the aurora?
• Sound waves from the aurora
• Wave transformation on the Sun
• Beginning to answer my question

4
What creates the aurora?
5
Chain of Events
The aurora is created by a chain of events,
beginning with energy from the sun.
Image courtesy of Tom Michalikhttp//faculty.rmwc
.edu/tmichalik/solarwind.htm
6
The Magnetosphere
Image courtesy of Minnesota Technologhttp//techn
olog.it.umn.edu/technolog/novdec97/cover.htm
7
Coronal Mass Ejection (CME)
Illustration by Steele Hill, courtesy of
NASAhttp//sohowww.nascom.nasa.gov/localinfo/stee
le.html
8
South-North Magnetic Orientation of CME
9
North-South Magnetic Orientation of CME
10
Magnetic Reconnection on Dayside of Earth
11
Magnetic Field Lines are Drawn Back to Magnetotail
12
Magnetotail is Compressed
13
Magnetic Reconnection in Magnetotail
14
Particles Spiral Down Field Lines
Image Fundamentals of Physics, 2005
15
Particles 2
Particles Spiral Down Field Lines

• Collide with atomic and molecular oxygen and
  nitrogen

• Emit energy as light

16
This Creates the Aurorae

• Northern Lights Aurora Borealis
• Southern Lights Aurora Australis

Image courtesy of Shawn Malonehttp//www.lakesupe
riorphoto.com
17
Nearly Mirror Images
Aurora Borealis
Aurora Australis
Images courtesy of NOAAhttp//sec.noaa.gov/pmap/
18
Can we hear the aurorae?

• Anecdotal evidence of auroral sounds

• hissing, popping, crackling, swooshing
• corresponds with motions of light

19
6 minutes

• Sound would take at least 6 minutes to travel
  from the aurora to the ground

• No recordings of audible aurorae

20
Explanations of Audible Sounds

• Psychological
• Freezing Breath
• Brush discharge

21
Evidence of Infrasound from Aurorae

• Humans can hear between 20 and 20,000 Hertz (Hz)
• Infrasound is below 20 Hz
• Currently being investigated
• Gas expansion

22
The Sun Creates Sound Waves
23
Sound Waves on the Sun Created by Convection
24
Sound Waves Propagate through Suns Atmosphere
Sun
25
Energy of Sound Waves is Transformed into
Magnetic Waves
Sun
26
Types of Magnetic Waves

• Alfvén waves (s-mode)

• Magnetosonic waves (p-mode)

Images courtesy of Georgia State
Universityhttp//hyperphysics.phy-astr.gsu.edu/hb
ase/sound/tralon.html
BBC animations
27
My Question
Can magnetic waves in the aurorae transform into
sound waves?
28
Magnetic Waves
Earth
29
Transform into Sound Waves
Earth
30
Finding Beta
Gas (atmospheric) Pressure
Beta ß
Magnetic Field Pressure
ß 1 ?
31
Resonance

• All material has a frequency that it vibrates at
• Matching the frequency allows the material to
  absorb energy
• Singing wine glass

32
Resonance in the Aurora
When ß 1,

• Energy from magnetic waves can be transferred to
  the atmosphere
• Found the right frequency

33
When Beta 1
ß 1 ?

• At 120 km
• Near bottom of aurorae

34
More Questions to Investigate

• How does ß vary?
• Compare gas expansion theory to wave
  transformation
• How much might Alfvén and magnetosonic waves each
  contribute to this effect?
• Which is more likely to transform?

35
Thanks to

• Dr. E.J. Zita for her guidance and helpful
  discussions
• Beth Stinson for instruction in PowerPoint

36
Image Sources

• NOAA (National Oceanic Atmospheric
  Administration)http//sec.noaa.gov/pmap/
• NASAhttp//sohowww.nascom.nasa.gov/localinfo/ste
  ele.html
• SpaceWeather.com http//www.spaceweather.com/auro
  ra/images2005.htm
• Shawn Malonehttp//www.lakesuperiorphoto.com
• Tom Michalikhttp//faculty.rmwc.edu/tmichalik/so
  larwind.htm
• Minnesota Technologhttp//technolog.it.umn.edu/t
  echnolog/novdec97/cover.htm
• Fundamentals of Physics, Halliday/Resnick/Walker,
  John Wiley Sons, 2005, p 746
