CHEE 222 CHEMICAL PROCESS DYNAMICS AND NUMERICAL
METHODS Module 3 Dynamic Lumped Parameter
System
2
Topics to be covered in this module

• Origin of Ordinary Differential Equations
• Transient balance for lumped parameter systems
• Steady state balance for distributed parameter
  system
• Numerical Methods
• Numerical Integration of Ordinary Differential
  Equation
• Eulers Method
• Explicit and Implicit Methods Numerical
  Stability of Explicit Method
• Runge-Kutta Method
• Second- and Fourth-Order Runge-Kutta Methods
• Computer-Based ODE Solution Techniques
• Matlab Integration Routines
• Ode23 and Ode45Study of transient behavior
• Process Dynamics
• Case study CSTR with first-order reaction
  kinetics

3
Types of System and Resulting Equations
Distributed Parameter System
Lumped Parameter System
Dynamic
Dynamic
Steady State
Steady State
X
Algebraic Equations
Differential Equations
Differential Equations
Partial Differential Equations
Linear
Non-Linear
Single Variable
Multi- Variable
4
Transient Lumped Parameter System

• For a constant density (r) fluid of density being
  flowed in and out of a storage tank of uniform
  cross-section area (A), the transient mass
  balance (derived earlier in the class) takes the
  following form

h
Note The density parameter does not appear
because it cancels out
5
Steady State Distributed Parameter System

• Consider viscous flow in a pipe.
• The differential equation to describe the local
  pressure drop takes the following form (youll
  learn more in CHEE 223)

D
6
Numerical Methods for SolvingOrdinary
Differential Equations
7
Eulers Method
8
Numerical Solutions for ODEs The Euler Method

• Let us consider a single-variable ODE by the
  following equation
• with the initial
  condition
• Objective To find the solution x(t).
• Strategy Approximate or over a
  finite time length or
• time-step (Dt)
• The basic idea is to approximate by a
  difference scheme
• The value of expression f(x) is evaluated and is
  then used to estimate the value of x (tDt)

Graphical illustration will be provided in class
9
Explicit Euler Methods

• In this method, the value of f(x) is evaluated at
  known value of x or at xk. The term dx/dt is
  represented by the following difference scheme
• The derivative is then equated to f(x)
• The value of x at ttDt is then calculated by
  the following equation
• Note that the RHS of the above equation contains
  all known values, therefore, the equation can be
  solved explicitly

10
Eulers IMPLICIT Method
11
Implicit Euler Methods

• This method differs from the implicit method in
  that the value of f(x) is evaluated at unknown
  value of x or at xk1. The dx/dt is represented
  by a difference scheme
• The derivative is equated to f(xk1) and we get
• The equation can be rearranged as follows
• Clearly, the equation is implicit in the unknown
  xk1 . Depending on the non-linearity of f(x), an
  iterative solution may be required

12
Stability of Explicit Method
13
Explicit Eulers Method Stability

• Tutorial5 problem illustrates that explicit
  Eulers Method may result in a solution that
  generates oscillatory solution.
• The oscillatory behavior is due to numerical
  approximation.
• The solution can also be unstable.
• For Eulers explicit method, both the instability
  and oscillation are the result of step-size
  chosen for integration.
• From mathematical theory, the conditions for
  stability can be found. Here, we provide you with
  that condition (the derivation is beyond the
  scope of this course).

14
Explicit Eulers Method Stability

• The general form of solution for Explicit Euler
  Method is as follows
• Let us denote the RHS of the above equation as a
  function g(xk). The requirement for stable
  solution is as follows
• where, g?(xk) is the derivative of g(xk) with
  respect to xk
• In lecture, we will apply this criterion to the
  Tutorial6 problem

15
Eulers Method Closing Remarks

• Eulers method is rarely used in advanced
  computational routines. Nonetheless, it is very
  useful in demonstrating the general concept on
  numerical integration
• Explicit Euler Method is easy to implement due to
  explicit nature of the equation but numerical
  stability can be a problem
• Stability problems can be overcome with an
  appropriate choice of step-size.
• Smaller steps sizes are always desirable because
  they lead to increased accuracy. However, small
  step-size come at the cost of increased
  computation time.
• Implicit methods are inherently stable.
• Implicit Euler Method for non-linear equations
  require an iterative solution such as Newtons
  method.
• Finally, stable does not mean accurate.

16
Runge-Kutta Method
17
Runge-Kutta Methods

• Runge-Kutta methods are variations of explicit
  methods.
• Runge-Kutta methods are used extensively in
  computational packages.
• MATLAB uses 2nd and 4th order methods ode23
  and ode45 solvers
• The basic idea is to estimate an improved guess
  for the derivative and, in turn, a better
  estimate for the integrated variable.

18
2nd Order Runge-Kutta (RK2) Method

• Objective To numerically integrate the following
  ordinary differential equation.
• Integration Procedure
• Apply Eulers method to estimate the slope or
  derivative at xk
• Estimate the value of state variable at a
  mid-point, i.e. x(tDt/2).
• Calculate the slope or derivative at this
  mid-point
• Estimate the value of state variable at next time
  step, i.e. xk1 using slope at mid-point
• Illustrative examples to be discussed in lecture

19
4th Order Runge-Kutta Method (RK4 Method)

• Integration Procedure
• Apply Eulers method to estimate the slope (m1)
  or derivative at xk
• Estimate the value of state variable at a
  mid-point, i.e. x(tDt/2).
• Calculate the slope or derivative (m2) at this
  mid-point to estimate new mid-point state
  variable x?k1/2
• Find corrected mid-point slope (m3) at this new
  mid-point x?k1/2
• A final slope (m4)is evaluated at the end of the
  step

20
4th Order Runge-Kutta Method (Cont.)

• The new state variable at the integration step is
  calculated by a weighted average of three slopes

21
Multi-variable RK method
22
RK Methods Closing Remarks

• 2nd order Runge-Kutta Method is more accurate
  than Eulers explicit method
• 4th order Runge-Kutta Method is preferred when
  higher accuracy is required.
• Selection of step-size is crucial for accuracy
  and usually class problems are solved using a
  fixed step-size. However, Most of the integration
  routines use a variable step-size.

23
Numerical Integration in Matlab

• So far, we have learned about Runge-Kutta methods
  for integration of ordinary differential
  equation.
• Runge-Kutta methods are used extensively in
  computational packages.
• MATLAB uses 2nd and 4th order methods ode23
  and ode45 solvers

24
Study of Transient Behavior of a Chemical
ProcessCSTR with 1st-order Rate Kinetics
25
CSTR Steady State and Transient Behavior

• CSTR Behavior and Transience
• CSTRs are designed to operate at steady-state
  and, as such, transient effects arise from the
  following situations
• start-ups or shut-down of reactor
• upsets or disturbances (fluctuations) of state
  and/or design variables during operation
• transience from one steady-state to the other.
• Role of a process engineer operating a CSTR.
• The primary interest is to analyze the steady
  state conditions. As well, to predict how the
  system behaves during transient period.
• How do we undertake this study of steady state
  and transient behavior?
• Derivation of Total Mass Balance
• Derivation of Mole Balance on Reactant A
• Calculation of Steady-State Concentration
• Determination of analytical solution for the
  problem, i.e. C(t) ?

26
Case Study CSTR Transient Behavior
27
Study of SS Transient Behavior of a CSTR

• Objective Apply differential mass and mole
  balance to a CSTR to study transient effects,
  i.e. to investigate the process dynamics of the
  system.
• Problem description Consider the following CSTR
  system wherein a chemical reaction following
  first-order rate kinetics is being carried out.

Initial Condition at t0, CA CA,initial 2
mol/L
Reaction A ? B Rate Kinetics (-rA) k?CA
where, k0.005 s-1
V 10 (L)
28
Fundamental Balance Equations for a CSTR

• 1. Differential Mass Balance Equation
• Accumulation Input Rate Output Rate
• ? for constant density system (e.g. liquids)
• 2. Differential Mole Balance on Reactant A
• Accumulation Input Rate Output Rate Gen.
  Rate Cons.Rate

Rate of consumption is given by a constitutive
relationship reaction kinetics. Reaction
kinetics describes how reaction rate is related
to CA via a reaction rate constant
29
Fundamental Balance Equations for a CSTR (cont.)

• 2. Differential Mole Balance on Reactant A
  (Cont.)
• For constant volume system, the following
  equation
• reduces to
• and can be rearranged as follows
• Introducing a new variable (tp,) below, the
  above equation can be re-written as

30
Steady State Behavior of the CSTR

• 3. Calculation of the Steady-State Concentration
• The steady-state (SS) concentration (CA,s) can be
  calculated by setting dCA/dt term equal to zero
  in the following equation
• Thus, we have
• ?
• tp 1/(0.15/10 .005)-1 seconds 50 s
• CA,s 50 s ? (.15/10) s-1? 10 mol/L 7.5 mol/L

31
Transient Behavior of the CSTR

• 4. Analytical Solution for Transient Mole Balance
  Equation
• The mole balance equation below represents a
  first-order ordinary differential equation.
• ?
• The equation can be re-written as follows
• ?
• The above equation can be solved to yield CA (t)
  by simple integration
• Applying the initial condition (at t0, CA CA,
  initial) to the above equation, we get

32
Transient Behavior of the CSTR

• The solution can therefore can be derived as
  follows
• Dividing by -tp
• Rearranging, we get
• Finally,

DCA
33
Case Study Graphical Representation of the
Solution
0.865 DCA
0.993 DCA
0.633 DCA
DCA
t 2tp
t 5tp
t tp
Can you see the relevance and utility of tp ?
34
Where do we go from here ?
35
Transient Effects of a CSTR

• Let us explore the dynamic behavior of the CSTR
  subjected to the following WHAT IF scenarios
• What if the initial concentration was varied.
• What if there was upset in feed concentration
  after SS operation was established.
• What if there was upset in feed volumetric rate
  after SS operation was established.
• The above scenarios will be explored via MATLAB
  simulations (to be demonstrated in class)

This exercise aims to demonstrate application of
computer-aided balance equations.
