Dimensioning

1
Dimensioning
Ch. 9
2
Dimensions

• Dimensions are used to describe the sizes and
  relationships between features in your drawing.
• Dimensions are used to manufacture parts and to
  inspect the resulting parts to determine if they
  are acceptable.
• Proper dimensioning increases clarity of the
  drawing and reduces ambiguity
• ANSI/ASME Y14.5M-1994 is the current standard.

3
Standard Practices

• Criteria of designs dimensioning
• Basic sizes and locations of features
• Details for manufacturing
• Rules for dimensioning include
• Lines, symbols, and abbreviations
• Size and location dimensions
• Placement of dimensions

4
Terminology

• Basic dimension
• Theoretically, considered the exact size,
  location or orientation.
• Reference dimension
• Provided for information only and not directly
  used in the fabrication of the part
• Tolerance
• Limits of size (The largest and minimum
  acceptable size)
• Plus and minus (The allowable positive and
  negative variance)
• Datum
• A theoretically exact point (Surface, plane,
  axis) used as a reference

5
Terminology
6
Leaders
7
Placement of dimensions
8
Placement of Dimensions
9
Stagger Dimension Values
Rule
10
Dimensioning Systems

• Unidirectional
• Read horizontally from bottom of sheet

11
Dimensioning Systems
2. Aligned All numerals, figures and notes be
aligned with dimension lines
12
Dimensioning Systems
3. Tabular Coordinate Size and location
dimensions from datums or coordinates are given
in a table identifying features in the drawing.
13
Dimensioning Systems
4. Chart Used when dimensions change depending
on a specific application
14
Dimensioning Cylinders
15
Dimensioning Holes
16
Using Diameter Symbol
17
Locating Holes
