Onchip power distribution in deep submicron technologies

1
On-chip power distribution in deep submicron
technologies

• Aida Todri
• Electrical and Computer Engineering Department
• University of California Santa Barbara

2
Outline

• Introduction
• Problem Statement and Formulation
• Electromigration (EM) Phenomena in Power Gated
  Networks
• EM Analysis and Grid Optimization
• Decoupling Capacitor Efficiency in Power Networks
• Metrics and Placement
• Power Supply Noise Reduction in Multi-core System
• Power vs Performance Trade-offs
• Conclusions

3
Technology Scaling

• Advantages
• Increasing device count
• Higher transistor density
• Increasing logic switching speed
• Increasing clock frequencies
• Disadvantages
• Increasing internal capacitance
• Increasing leakage current
• higher standby power
• Increasing dynamic power
• larger transient currents

4
On-Chip Power Delivery Network

• Hierarchical mesh structure on several metal
  layers
• Global grid occupies the top two layers of the
  chip
• Local (block) grid occupies lower metal layers
• Must satisfy reliability constraints
• In DC (steady state) conditions
• Voltage drop (IR) must be within margins
• Current density in power tracks should not
  surpass allowed current density
• In AC (transient) conditions
• Power supply noise must be within margins
• Decaps may be inserted to suppress power supply
  noise and to lower impedance of power tracks

5
Low-Power Strategy

• Idle blocks can be disconnected from the grid
• Their static power can be eliminated
• Sleep transistor controls the wake up or sleep
  mode of the gated block

Power gating technique
6
Power Gating Technique

• Top layer is global grid
• Designed to satisfy reliability constraints (EM
  and IR) when all circuits are switching
• Each block has its local power mesh
• Many power gating configurations exist

7
Research Topics of Interest - 1

• Designing Power Grid for Power-Gated Chips
• Typically designed at the early stages of the
  design process
• Mostly over-designed causing a large overhead in
  chip power consumption
• Power gating is not considered during the design
  of power grids.

8
On-chip Power Delivery for Power Gated Chips
Objective Deliver power to the circuit blocks
while satisfying reliability
constraints in the power grid when power gating
is applied.

• Power tracks are not ideal and have finite
  resistance
• Many possible configurations of operating blocks

9
Electromigration Mechanisms

• Transport of metal atoms under the force of an
  electron flux
• High current density stress
• Depletion/ accumulation of metal material from
  atomic flow can lead to the formation of hillocks
  and voids in metal lines
• lead to shorts and open circuits faults

Photo courtesy of University of Notre Dame
10
Electromigration on Power Gated Grids
Before power gating
After power gating
EM violations may occur only on those branches
where base currents flow in opposite directions.
11
IR Drop Analysis for Power Gating

• Theorem 1 The grid node voltages can only
  increase when a current source is turned off.
• Corollary When a source is turned off, IR drop
  may only decrease when power gating is applied.
• Theorem 2 Uniform track resizing of a resistive
  grid does not change the current flow.
• Corollary Uniform upsizing does not change
  currents on a grid, so we can always upsize
  tracks to meet EM and IR constraints.

Uniform upsizing by guarantees that all EM
and IR constraints are satisfied for all power
gating configurations.
12
Power-Gating Aware Optimization

• We reduce the complexity of the optimization
  problem by reducing the grid granularity by
  applying the multi-grid technique.
• Our optimization scheme has three main steps
• Reduce grid size by folding tracks
• Optimize the reduced grid
• Unfold the grid to its original granularity

13
1. Grid Folding

• Identify a few neighbor tracks around a violation
  that remain unfolded.

14
2. Reduced Grid Optimization

• A three-step iterative process, 3 Step LP
• Derive current and voltage sensitivities to grid
  sizing
• Uniformly upsize the grid by fine scale upsizing
  steps ?1, ?2,, ?r
• Shrink the selected tracks
• The process is repeated until no violations exist.

Upsizing by ?i from ?1, ?2,, ?r
Original grid
Shrink selected tracks
15
LP Problem

• Minimize the total resizing of the grid as
• subject to the three constraints
• Current Density
• Voltage Drop
• Resizing Coefficients

16
3-step Iterative LP Algorithm
Initial Optimized Grid for All
Sources On
Computations from Power Gating Configurations

J
EM violation
VB
V
IR violation
node
Y
Upsizing coefficient
y
Finer scale coefficients
i
J
gtJ
N
Feasible Grid
VB
max
V
lt0.9V
node
DD
Y
y
Upsize Grid by
i
Shrink Grid
17
3. Grid Unfolding

• As we only considered only worst case violations
  on the grid, minor violations after optimization
  and unfolding are possible.
• These violations are miniscule and can be fixed
  by applying greedy upsizing of the track with
  violation.

18
Experiments- Floorplans
Low/medium current density blocks
Power gating configurations.
High current density blocks
High density blocks located in the center of the
grid.
Gated blocks
Low/medium density blocks located in the center
of the grid.
Power gating configurations
19
Results

• Experiments to observe
• Various current density blocks (high, med, low)
• Various power grid granularities
• 20x20, 30x30, 50x50, 100x100
• All vs. some power gating configurations
• Percentages in area savings compared to uniform
  upsizing
• up to 48 of area savings
• 100x100 granularity grid with high density blocks
  placed on the center of the grid

20
Decoupling Capacitor vs. PSN

• Inserted decoupling capacitor (decaps) can
  provide charge to switching circuit to reduce
  power supply noise (PSN).
• Decaps consume power due to switching
• PSN suppression depends on decap efficiency

21
Research Topics of Interest - 2

• How to Use Decoupling Capacitors Most Efficiently
  ?
• Decoupling capacitor is a reservoir of charge
• Used to reduce voltage drop at the switching
  current load
• Amount of charge supplied depends on
• Parasitic conductance between decap and current
  load
• Parasitic conductance between decap and power
  supply
• Switching frequency of the current load

22
Decoupling Capacitance Effectiveness

• Decoupling capacitors suppress power supply noise
• Decaps reduce the impedance of the power delivery
  system operating at high frequencies.
• Efficacy of decoupling capacitors depends upon
• Impedance of conductors connecting the capacitor
  to current loads and power sources
• Charge-back ability after a transitions is
  completed.

23
Decap Effectiveness in Mesh Grids
Original mesh
Mesh A circuit
Mesh B circuit
Mesh C circuit
24
Decap Effectiveness on Mesh Grids
Detrimental decoupling capacitance.
25
Decap Effectiveness in Mesh Grids
Ineffective decoupling capacitance.
26
Decap Effectiveness in Mesh Grids
Effective decoupling capacitance
27
Mesh Analysis

• Decap effectiveness depends upon
• Zd impedance has an impact on how fast Cdecap
  will be recharged
• Zs,impedance has an impact on how much voltage
  drop will be at the switching circuit
• Zsd,impedance has an impact on how much current
  (charge) Cdecap can provide to the switching
  circuit.
• tr, tf, Ipeak, switching frequency and current
  magnitude
• Cdecap, decap size

28
Decaps effectiveness metrics
a effective distance between decap and Vdd
pin b effective distance between current source
and decap u minimum distance between decap and
Vdd pin to avoid spurious switching.
29
Decap Effectiveness Model
30
Decap Budget Optimization Function
LP optimization problem

• Subject to
• Voltage drop margin
• Charge transfer balance
• Allowed cap constraint
• Efficiency metrics constraints

31
Sequence of Linear Programs

• Cdecapi is dependent on the node voltage Vi
  Cdecapi and Vi are variables.
• Sequence of linear programs
• Initial transient analysis performed with
  existing decaps, solved for Vis
• Determine decap budgets Cdecapi based on LP
  formulation where node voltages are determined in
  step 1.
• Re-perform transient analysis with Cdecapi to
  check the node voltages. Update node voltages Vi.
• Check if Vi gtVthresh.
• If Vi gtVthreshs, run decap budget to reduce
  decaps, step 2
• If Vi ltVthresh-s, run decap budget to allocate
  more decaps, step 2

32
Case Study
Courtesy of STMicroelectronics
33
Experiments
34
Experiments
35
Experiments

• Total Decap Reduction
• Total amount of decap reduced on chip 297pF
• Percentage 5.56
• Number of Filler Cells Reduction (placed decaps)
• 297pF out of 623pF gt 52
• Correlations

36
Multi-Core System

• Several cores integrated on a chip
• Chips with
• Several cores have been produced
• Tens to hundreds of cores per chip are envisioned

• Physical design problems
• Thermal management
• Power management
• Power delivery
• Noise control

37
Research Topics of Interest - 3

• How to Suppress Power Supply Noise?
• Sources
• Fast transient currents of switching blocks
• Turn on/off of power gated blocks
• Parasitic impedance of power tracks (package)
• Detrimental Effects
• Circuit delay increase
• Logical faults due to increased delay

38
Multi-Core Systems
Objective Assign task to cores such that minimum
power supply noise is generated.

• Shared global grid
• Uniform controlled collapse chip connection (C4s)
  distribution

39
PSN vs. Workload Assignments
3
2
1
5
4
6

• PSN vs. proximity between working cores
• PSN vs. available decap
• PSN vs. operating frequencies

7
9
8
40
Grid Models
Base grid
Global grid
Core grid
41
Circuit Reduction

• Reducing base grid (a) to a simplified model (b)
• Circuit voltage response maintained for the worst
  case voltage drop
• Assumption the worst case voltage drop is on
  node 5

42
Power Supply Noise Aware Assignment

• We apply simulated annealing (SA) based algorithm
  to minimize PSN.
• A workload can be assigned to any core
• Task assignments on cores will vary due to
• Location
• same task at different location
• Frequency
• Same location but varying workloads
• Location and Frequency

43
Assignment Heuristics

• Current Demand-Based Assignment (CDA)
• Workloads assigned to cores which are farther
  away from large current workloads to minimize
  noise propagation.

44
Experiments

• Experiments to observe
• Various core granularities
• 3x3,5x5,7x7, 10x10
• Various operating frequencies
• Various core sizes
• Impact of initial task assignment on the
  multicore system
• Results
• No initial assignment
• Up to 30 less in PSN compared to CDA method
• With initial assignment
• Up to 37 less in PSN compared to CDA method.

45
Conclusions

• On-chip power distribution for low-power
  applications
• Power gating induced electromigration issues in
  the power networks
• Analysis and optimization of power network
• Analysis of decoupling capacitance efficiency in
  power grids
• Decoupling capacitance placement in power
  networks
• Low power supply noise task assignment for
  multicore systems
• Analysis of multicore systems power network
• Task assignment optimization for low power noise
