Chapter 13: Application Architecture and Modeling

1
Chapter 13 Application Architecture and Modeling
2
Objectives

• Define an information systems architecture in
  terms of the KNOWLEDGE, PROCESSES, and
  COMMUNICATION building blocks.
• Differentiate between logical and physical data
  flow diagrams, and explain how physical data flow
  diagrams are used to model an information
  systems architecture.
• Describe centralized and distributed computing
  alternatives, including client/server and
  Internet-based computing options.
• Describe database and data distribution
  alternatives for system design.
• Describe user and system interface alternatives
  for system design.
• Describe various software development
  environments for information system design.
• Describe strategies for developing or determining
  architecture of an information system.
• Draw physical data flow diagrams for an
  information systems architecture and processes.

3
(No Transcript)
4
Application Architecture

• Application architecture a specification of the
  technologies to be used to implement information
  systems. The blueprint to communicate the
  following design decisions
• The degree to which the information system will
  be centralized or distributed.
• The distribution of stored data.
• The implementation technology for software
  developed in-house.
• The integration of commercial off-the-shelf
  software.
• The technology to be used to implement the user
  interface.
• The technology to be used to interface with other
  systems

5
Physical Data Flow Diagram
6
Physical Data Flow Diagram (DFD)

• Physical data flow diagram (DFDs) a process
  model used to communicate the technical
  implementation characteristics of an information
  system.
• Communicate technical choices and other design
  decisions to those who will actually construct
  and implement the system.
• Recall from Chapter 9 that DFDs are a type of
  process model.

7
Sample Physical Data Flow Diagram
8
Physical Processes

• Physical process either a processor, such as a
  computer or person, or a technical implementation
  of specific work to be performed, such as a
  computer program or manual process.
• Logical processes may be assigned to physical
  processors such as PCs, servers, people, or
  devices in a network. A physical DFD would model
  that network structure.
• Each logical process requires an implementation
  as one or more physical processes.
• A logical process may be split into multiple
  physical processes
• To define aspects performed by people or
  computers.
• To define aspects implemented by different
  technologies.
• To show multiple implementations of the same
  process.
• To add processes for exceptions and security.

9
Physical Process Notation
10
Samples of Physical Processes
11
Possible Computer Process Implementations

• A purchased application software package
• Also called commercial off-the-shelf (COTS)
  software
• A system or utility program
• Such as an e-mail/message server or third-party
  framework
• An existing application program from a program
  library
• May require modification
• A program to be written

12
Sample Physical Process Implementations
13
Physical Data Flows

• A physical data flow represents
• Planned implementation of an input to, or output
  from a physical process.
• Database command or action such as create, read,
  update, or delete.
• Import of data from, or export of data to
  another information system.
• Flow of data between two modules or subroutines
  (represented as physical processes).

14
Sample Physical Data Flows
15
Sample Physical Data Flows (continued)
16
Physical External Agents

• Physical external agents are carried over from
  the logical DFD models.
• If scope changes, the logical models should be
  changed before the physical models are drawn.

17
Physical Data Stores

• A physical data store represents the planned
  implementation of one of
• A database
• A table in a database
• A computer file
• A tape or media backup of anything important
• A temporary file or batch
• Any type of noncomputerized file

18
Physical Data Store Notation
19
Physical Data Store Implementations
20
Information Technology Architecture Distributed
Systems
21
Distributed versus Centralized Systems

• Distributed system a system in which components
  are distributed across multiple locations and
  computer networks.
• Accordingly, the processing workload is
  distributed across multiple computers on the
  network.
• Centralized systems a system in which all
  components are hosted by a central, multi-user
  computer.
• Users interact with the system via terminals (or
  a PC emulating a terminal).
• Virtually all the actual processing and work is
  done on the host computer.

22
Why the Trend Toward Distributed Systems?

• Modern businesses are already decentralized
  (distributed).
• Distributed computing moves information and
  services closer to the customers and users who
  need them.
• Distributed computing consolidates the power of
  personal computers across the enterprise.
• Distributed computing solutions are in general
  more user-friendly because they use the PC as the
  user interface processor.
• Personal computers and network servers are less
  expensive than mainframe computers
• Though total cost of ownership is at least as
  expensive

23
Computing Layers

• Presentation layerthe user interface
• Presentation logic layerprocessing that must be
  done to generate the presentation, such as
  editing input data or formatting output data.
• Application logic layerthe logic and processing
  to support business rules, policies, and
  procedures
• Data manipulation layerto store and retrieve
  data to and from the database
• Data layerthe actual business data

24
Types of Distributed Computing
25
File Server Architecture

• Local area network (LAN) a set of client
  computers (PCs) connected over a relatively short
  distance to one or more servers.
• File server system a LAN in which a server
  hosts the data of an information system.
• All other layers are implemented on the client
  computers.
• Frequently excessive network traffic to transport
  data between servers and clients.
• Client must be fairly robust (fat) because it
  does most of the work.
• Database integrity can be compromised.

26
File Server Architecture
27
Client/Server Architecture Clients

• Client/server system a distributed computing
  solution in which the presentation, presentation
  logic, application logic, data manipulation, and
  data layers are distributed between client PCs
  and one or more servers.

• Thin client a personal computer that does not
  have to be very powerful because it only presents
  the user interface to the user.

• Fat client a personal computer, notebook
  computer, or workstation that is typically
  powerful.

28
Client/Server Architecture Servers

• Database server a server that hosts one or more
  databases and executes all data manipulation
  commands at the server.
• Transaction server a server that hosts services
  which ensure that all database updates for a
  transaction succeed or fail as a whole.
• Application server a server that hosts
  application logic and services for an information
  system.
• Messaging or groupware server a server that
  hosts services for e-mail, calendaring, and other
  work group functionality.
• Web server a server that hosts Internet or
  intranet websites.

29
Client/ServerDistributed Presentation

• Distributed presentation a client/server system
  in which the presentation and presentation logic
  layers are shifted from the server to reside on
  the client.
• The application logic, data manipulation, and
  data layers remain on the server (frequently a
  mainframe).
• Character user interface (CUI)
• Graphical user interface (GUI)

30
Building a GUI From a CUI Screen Scrapers
31
Client/ServerDistributed Presentation
32
Client/ServerDistributed Data

• Distributed data a client/server system in
  which the data and data manipulation layers are
  placed on the server(s), and other layers are
  placed on the clients.
• Sometimes called two-tiered client/server
  computing.
• Difference to file server systems is where the
  data manipulation commands are executed.
• Much less network traffic than file server
  systems because only the database requests and
  the results of those requests are transported
  across the network.
• Database integrity is easier to maintain.

33
Client/ServerDistributed Data
34
Client/ServerDistributed Data and Application

• Distributed data and application client/server
  system
• The data and data manipulation layers are placed
  on their own server(s),
• The application logic is placed on its own
  server,
• The presentation logic and presentation layers
  are placed on the clients.
• Also called three-tiered or n-tiered
  client/server computing.
• Requires design partitioning.
• Partitioning the art of determining how to best
  distribute (duplicate) application components
  across the network.

35
Client/Server Distributed Data and Application
36
Internet- and Intranet-based Architectures

• Network computing system presentation and
  presentation logic layers implemented in
  client-side Web browsers using content downloaded
  from a Web server.
• Presentation logic layer connects to application
  logic layer running on application server, which
  connects to database servers on the backside of
  the system.
• The greatest potential of this approach is its
  applicability to redesign of traditional
  information systems to run on an intranet.
• Intranet a secure network that uses Internet
  technology to integrate desktop, work group, and
  enterprise computing into a cohesive framework.

37
Network Computing System Internet/Intranet
38
Internet and Intranet Technologies

• Java
• Mostly for programming server-side application
  logic called servlets
• Occasionally for programming client-side
  application logic called applets
• HTML (HyperText Markup Language)
• Mostly for programming the presentation layer
• XML (Extensible Markup Language)
• Mostly for programming data content to be
  transported across the web
• SQL (Structured Query Language)
• Universal standard language for database
  manipulation
• Web Browsers

39
Information Technology Architecture Distributed
Relational Database
40
Data Architectures

• Relational database stores data in tabular form.
  Each file is implemented as a table. Each field
  is a column in the table. Related records between
  two tables are implemented by intentionally
  duplicated columns in the two tables.
• Distributed relational database A database
  system that duplicates tables to multiple
  database servers located in geographically
  important locations.
• Distributed relational database management system
  a software program that controls access to and
  maintenance of stored data in the relational
  format.

41
Types of Data(base) Distribution

• Data partitioning truly distributes rows and
  columns of tables to specific database servers
  with little or no duplication between servers.
• Vertical partitioning assigns different columns
  to different servers.
• Horizontal partitioning assigns different rows to
  different servers.
• Data replication duplicates some or all tables on
  more than one database server.
• Propagates updates on one database server to any
  other database server where the data is
  duplicated.

42
Data Partitioning versus Data Replication
43
Information Technology Architecture Interface
Architecture
44
Interface Architectures Inputs, Outputs,
Middleware

• Batch inputs and outputs
• Online inputs and outputs
• Remote batch
• Keyless data entry (and automatic identification)
• Pen input
• Electronic messaging and work group technology
• Electronic Data Interchange (EDI)
• Imaging and document interchange
• Middleware

45
Batch Inputs and Outputs
46
On-Line Inputs and Outputs
47
Remote Batch
48
Keyless Data Entry (and Automatic Identification)
49
Pen Input
50
Electronic Data Interchange (EDI)

• Electronic Data Interchange (EDI) the
  standardized electronic flow of business
  transactions or data between businesses.
• Typically, many businesses must agree to a common
  data format to make EDI feasible.

51
Middleware

• Middleware utility software that enables
  communication between different processors in a
  system.
• It may be built into the respective operating
  systems or added through purchased middleware
  products.
• Presentation middleware
• Application middleware
• Database middleware

52
????????,????????,?????????
53
Information Technology Architecture Process
Architecture
54
Process Architectures

• Software development environment (SDE) a
  language and tool kit for developing
  applications.
• SDEs exist for centralized computing
• SDEs exist for distributed presentation
• SDEs exist for two-tiered client/server
• SDEs exist for multi-tiered client/server
• SDEs exist for Internet and intranet
  client/server
• Clean layering a design strategy that requires
  that presentation, application, and data layers
  of an application be physically separated.
• Allows components of each layer to be revised or
  enhanced without affecting the other layers.

55
Application Architecture Strategies for System
Design

• The Enterprise Application Architecture Strategy
• Enterprise-wide information technology
  architecture to be followed in all development
  projects.
• Approved network, data, interface, and processing
  technologies and development tools.
• Strategy for integrating legacy systems and
  technologies.
• On-going process for continuously reviewing
  application architecture.
• On-going process for researching emerging
  technologies
• Process for analyzing requests for variances from
  the above.
• The Tactical Application Architecture Strategy
• Defines architecture for each new system on an
  application-by-application basis as needed.
• Requires feasibility analysis for each
  application.

56
Drawing Physical DFDs for Network Architecture

• Develop a physical data flow diagram (DFD) for
  the network architecture.
• Each process symbol represents a server or class
  of clients.
• For each processor, develop a physical DFD to
  show the event processes (from Chapter 9) that
  are assigned to that processor.
• All but simple processes should be factored into
  design units and modeled as a more detailed
  physical DFDs.

57
Design Units

• Design unit a self-contained collection of
  processes, data stores, and data flows that share
  similar design characteristics.
• A design unit serves as a subset of the total
  system whose inputs, outputs, files and
  databases, and programs can be designed,
  constructed, and tested as a self-contained unit.
• Ultimately, design units must be integrated into
  a whole system.

58
The Network Architecture DFD

• Network architecture a physical DFD that
  allocates processors (clients and servers) and
  devices (machines and robots) to a network and
  establishes
• the connectivity between clients and servers
• where users will interface with the processors

59
Network Architecture DFD
60
Data Distribution Options

• Store all data on a single server.
• Store specific tables on different servers.
• Store subsets of specific tables on different
  servers.
• Replicate (duplicate) specific tables or subsets
  on different servers.

61
Data Distribution and Technology Assignments DFD
62
Process Distribution and Technology Assignments

• For two-tiered client/server systems, all logical
  even diagrams are assigned to the client.
• For three-tiered client/server and network
  computing systems, must closely examine each
  events primitive (detailed) DFD.
• Determine which primitive processes should be
  assigned to the client and which should be
  assigned to an application server.
• Generally data capture and editing are assigned
  to servers
• If different aspects of a single DFD are
  partitioned to different clients and servers,
  draw separate physical DFD for each.

63
Physical DFD for an Event
See Figure 13-13 in text for a more readable
version
64
The Person/Machine Boundary
See Figure 13-14 in text for a more readable
version
65
A Manual Design Unit
