Title: LCP Directive 200180EC Case study


1
LCP Directive 2001/80/EC Case study
  • Twinning project in Hungary
  • Anneli Karjalainen
  • Ministry of the Environment,
  • Finland

2
LCP Case (1)
  • An existing combination of combustion plants with
    the total thermal effect of 945 MW
  • 3 plants - each plant with thermal effect of 315
    MW
  • all 3 plants have been licensed before 1 July
    1987
  • built 1960 (I), 1964 (II) and 1972 (III)
  • fuels coal- sulphur content app. 0,8
  • SO2 emissions without cleaning 1 600 mg SO2 /m3
    (n)
  • additive fuels heavy fuel oil (start-up, shut
    down)
  • produces heat and electricity combined heat
    power (CHP)

3
LCP Case (2)
  • 2 plants in base-load use (II and III)
  • one plant (I) in reserve or peak-load use
  • two stacks 134 m and 82 m
  • have to apply an environmental permit by 31
    December 2004 (integrated permit)
  • waste gas cleaning at the moment
  • dust removal, desulphurisation, NOx removal
    (primary measures) based on national legislation
  • emission limit values expressed at yearly
    averages for SO2 and NOx

4
LCP Case (3)
  • from 1 January 2008
  • requirements for existing plants of LCP directive
    shall apply as a minimun requirements
  • 4 alternatives
  • (1) emission limit values of Annexes III A to VII
    A or
  • (2) inclusion into the national reduction plan or
  • (3) notify to use the option for remaining life
    time of 20 000 hours
  • (4) use the specified NOx limit values for plants
    of limited hours of operation
  • from 27 November 2004 requirement for continuous
    measurements of emissions according to Annex VIII

5
Requirements from LCP Directive for plant I
  • with thermal effect of 315 MW
  • operation hours between 500 to 2000 per year
  • from 2008 option to choose
  • option 1 ELVs
  • use of low sulphur coal to reach the ELV of 1100
    SO2 /m3 (n) and
  • use primary measures (low-Nox-burners ) to reach
    the ELV of 600 mg NO2 /m3 (n) and
  • dust removal to reach the ELV of 100 mg/m3 (n)
  • option 1 not realistic taking into account that
    plant built in 1960 and investments to be done

6
Requirements from LCP Directive for plant I
  • option 2 operation of 20 000 hours
  • use the option of remaining operation time of 20
    000 hours to close down the plant by the end
    of 2015
  • current ELVs will stay in force until 2016
  • emission measured discontinuously every six month
  • no investments to further waste gas cleaning
  • closer of the plant on 31 December 2015 at the
    latest
  • if the plant I is needed for a longer period a
    new permit application regarded as a new plant

7
Requirements from LCP Directive for plants II and
III
  • operation hours between 5 600 to 7 800 per year
  • thermal effect of 315 MW for each
  • from 2008
  • for SO2 ELV of 1 100 mg SO2 /m3 (n) for solid
    fuels (IIIA)
  • for NOx ELV of 600 mg NO2 /m3 (n) for solid
    fuels (VI A)
  • for dust ELV of 100 mg/m3 (n) for solid fuels
    (VII A)
  • malfunction or breakdown provision of in 48 hours
    to inform authorities
  • limit of 120 hours/year for unabated situations
  • change from yearly average (mg/MJ) to short-term
    values in mg/m3 (n)

8
Requirements from LCP Directive for plants II and
III
  • continuous measurements for all three pollutants
  • how to reach the limit values ?
  • desulphurisation unit for SO2 - limit value could
    be lower if wet scrubber is chosen
  • desulphurisation rates of 90 if the sulphur
    content is high
  • primary measures (low-NOx-burnes, over flow)
  • dust removal ESP (electrostatic precipitator)
    multicyclone cannot be considered

9
Permit regulations for plant s II and III (base
load)
  • Emissions of SO2 not exceed 700 mg SO2 /m3 (n)
    in 6 O2
  • Emissions of NOx not exceed 600 mg NO2 /m3 (n)
    in 6 O2
  • Emissions of dust not exceed 50 mg/m3 (n) in 6
    O2
  • In situations when the desulphurisation unit is
    not in operation because of malfunction or
    breakdown of equipment
  • use of low sulphur fuel or toe return to normal
    operation as soon as possible but in 24 hours at
    the latest possible to extend 24 hours time
  • information to permit authorities in 48 hours

10
Permit regulations for plant s II and III (base
load)
  • Emissions of SO2, NOx and dust shall be measured
    continuously from 27 November 2004
  • Temperature, oxygen content and pressure shall be
    measured continuously
  • the operator shall by the end of February each
    year report to the competent authority of
  • total emissions of SO2, NOx and dust of previous
    year
  • exceedances of limit values and the reasoning of
    it
  • fuel amounts used in the plants and the operation
    hours, their sulphur content
  • emissions of heavy metals
  • exceptional situations

11
Permit regulations for plant I (peak-load)
  • The operational hours of plant I shall not exceed
    20 000 hours starting from 1 January 2008 and
    ending by 31 December 2015.
  • The operator shall report competent authorities
    annually
  • how much of 20 000 hours is remaining
  • fuel amounts used in the plant and their sulphur
    content
  • total emission of SO2, NOx and dust
  • results of measurements
  • exceptional situations

12
Permit regulations for plant I (peak-load)
  • The existing regulations will stay in force
  • the sulphur content of coal shall nor exceed 0,8
  • no continuous measurements required
  • the SO2 emissions shall be determined by mass
    balance calculation based on the sulphur content
    of coal and fuel oils
  • the emissions of NOx shall be measured every
    three years or after 3 000 hours of operation
  • the dust emissions shall be measured continuously
    (or in another way adopted by the competent
    authority) ELV 50/100 mg/m3 (n)

13
Monitoring programme of emissions
  • operator puts forward a proposal for an emission
    monitoring plan/programme
  • includes details of
  • emission measurements
  • emission reporting
  • quality control for measurements
  • monitoring of process parameters
  • what is done in exceptional situations (breakdown
    of equipment, violation of limit values)
  • adopted in the permit or
  • in separate decision

14
National emission reduction plan option for
existing plants
  • combustion plants licensed before 1 July 1987 can
    be subject to a national emission reduction plan
  • all existing combustion plants over 50 MW have to
    be included
  • these 3 plants could be included in this plan
  • total emission reduction target over all plants
    calculated divided to plants as an emission
    ceiling for each
  • some kind of emission trading
  • plant I would be excluded from because
  • if uses remaining operation time option of 20 000
    hours
