Title: MicrostructureProperties: II Elastic Effects, Interfaces


1
Microstructure-Properties IIElastic Effects,
Interfaces
  • 27-302
  • Lecture 7
  • Fall, 2002
  • Prof. A. D. Rollett

2
Materials Tetrahedron
Processing
Performance
Properties
Microstructure
3
Objective
  • The objective of this lecture is to show how
    important (a) elastic effects are in controlling
    precipitation, and (b) the variety of interface
    structures that occur, and their importance in
    precipitation.
  • More specifically, this lecture examines the role
    of the interface (coherent vs. incoherent) in
    precipitate morphology and growth.
  • The main concepts are the misfit strain between
    two lattices at an interface that determines a
    dislocation density, and the (bulk) misfit
    parameter that determines the elastic energy
    associated with a precipitate.

4
References
  • Phase transformations in metals and alloys, D.A.
    Porter, K.E. Easterling, Chapman Hall.
    Chapter 3 is most relevant to this lecture.
  • Interfaces in Materials (1997), James M. Howe,
    Wiley Interscience.
  • Materials Principles Practice, Butterworth
    Heinemann, Edited by C. Newey G. Weaver.

5
Elasticity and Interface Structure
  • Why consider elasticity and interface structure
    together? Both aspects exert a strong influence
    over not just the shape of the new phase that
    appears during a phase transformation but also
    which phase appears in the first place.
  • The fact that a new phase has a different
    composition means that its lattice has a
    different set of repeat distances (lattice
    parameters), even if the crystal structure is the
    same as the parent phase.
  • These differences mean (a) different elastic
    moduli between parent and product phase and (b) a
    mismatch in atomic positions at a parent-product
    interface.

6
Basic results
  • For small precipitates (lt 5nm), precipitates are
    usually spherical with coherent interfaces in
    order to minimize surface energy.
  • For intermediate sizes, precipitates are often
    plates or needles in order to minimize surface
    energy in situations where one plane or direction
    is atomically similar between parent and product
    phases.
  • Large precipitates (gt 1µm) are often spherical
    with incoherent interfaces in order to minimize
    volumetric free energy.

7
Coherence at interfaces
  • Coherent/semi-coherent/incoherent interfaces
    these terms are based on the degree of atomic
    matching across the interface.
  • Coherent interface means an interface in which
    the atoms match up on a 1-to-1 basis (even if
    some elastic strain is present).
  • Incoherent interface means an interface in which
    the atomic structure is disordered.
  • Semi-coherent interface means an interface in
    which the atoms match up, but only on a local
    basis, with defects (dislocations) in between.

8
Homophase vs. Heterophase
  • There is a useful comparison that can be made
    between grain boundaries (homophase) and
    interphase boundaries (heterophase).Structure
              G.B.                         Interface
  • atoms no boundary coherentmatch (or, S3
    coherent twin in fcc) interface
  • dislocations low angle g.b. semi- coherent
  • disordered high angle g.b. incoherent
  • Remember for a grain boundary to exist, there
    must be a difference in the lattice position
    (rotationally) between the two grains. An
    interface can exist even when the lattices are
    the same structure and in the same (rotational)
    position because of the chemical difference.

9
LAGB to HAGB Transition
  • LAGB steep risewith angle.HAGB plateau

Disordered Structure
Dislocation Structure
10
Read-Shockley model
  • Start with a symmetric tilt boundary composed of
    a wall of infinitely straight, parallel edge
    dislocations (e.g. based on a 100, 111 or 110
    rotation axis with the planes symmetrically
    disposed).
  • Dislocation density (L-1) given by1/D
    2sin(q/2)/b ? q/b for small angles.

D
11
Read-Shockley, contd.
  • For an infinite array of edge dislocations the
    long-range stress field depends on the spacing.
    Therefore given the dislocation density and the
    core energy of the dislocations, the energy of
    the wall (boundary) is estimated (r0 sets the
    core energy of the dislocation) ggb E0 q(A0
    - lnq), whereE0 µb/4p(1-n) A0 1
    ln(b/2pr0)

12
LAGB experimental results
  • Experimental results on copper.

Gjostein Rhines, Acta metall. 7, 319 (1959)
13
Low Angle Grain Boundary Energy Yang et al.
Scripta Materiala (2001) 44 2735-2740
High
117
105
113
205
215
335
203
Low
8411
323
727
Measurements of low angle grainboundary energy
in 99.98Al
? vs.
14
High angle g.b. structure
  • High angle boundaries have a disordered
    structure.
  • Bubble rafts provide a useful example.
  • Disordered structure results in a high energy.

Low angle boundarywith dislocation structure
15
Energy of High Angle Boundaries
  • No universal theory exists to describe the energy
    of HAGBs.
  • Abundant experimental evidence for special
    boundaries at (a small number) of certain
    orientations.
  • Good fit for special boundaries based on good fit
    of a certain fraction of the atoms at the
    interface.
  • Mathematically, special orientations are easier
    to characterize in terms of coincidence of
    lattice points between the two lattices (by
    imagining that they interpenetrate) leading to
    the Coincident Site Lattice (CSL).
  • Each special point (in misorientation space)
    expected to have a cusp in energy, similar to
    zero-boundary case but with non-zero energy at
    the bottom of the cusp.
  • Special boundaries defined by a sigma number
    which is the reciprocal of the fraction of
    lattice points (not atoms!) that coincide. For
    cubic materials, this number is always odd, so we
    have S1, S3, S5, S7.

16
Exptl. vs. Calculated G.B. energies for 99.89 Al
lt100gtTilts
Twin
lt110gtTilts
Hasson Goux
17
Dislocation models of HAGBs
  • Boundaries near CSL points expected to exhibit
    dislocation networks, which is observed.

lt100gt twist boundariesin gold.
S5 twist Boundary in gold, showing dislocation
structure
18
Heterophase boundaries coherent interfaces
  • Coherent interfaces have perfect atomic matching
    at the boundary.
  • See figures 3.32, 3.33 in PE.
  • The indices of the planes comprising the boundary
    do not have to be the same in each phase.
  • In general, a coherent interface is based on an
    orientation relationship. This relationship is
    specified crystallographically in terms of a pair
    of planes and directions as in hklA//hklB
    with ltuvwgtA//ltuvwgtB.
  • For example, the hcp k phase precipitate in fcc
    copper has an almost perfect match through the
    orientation relationship, 111fcc//(0001)hcp and
    lt110gtfcc//lt11-20gthcp. The interfacial energy is
    estimated to be as low as 1 mJ.m-2.
  • Even in the case of perfect atomic matching,
    there is always a chemical contribution to the
    interface energy.

19
Strained interfaces
  • Unlike the case of grain boundaries, there is an
    important elastic aspect of coherent interfaces.
  • Small differences in lattice parameter are
    accommodated by elastic strain.
  • Given lattice parameters specified as interplanar
    spacings, dA and dB, the misfit parameter, d is
    given by the following simple formula d
    (dB - dA)/ dA
  • See figs. 3.34, 3.35.
  • We shall see later, that the misfit that can be
    accommodated by elastic strain is limited.

20
Semi-coherent interfaces
  • The logical next step in typing interfaces is to
    note that too-large misfit strains can be
    accommodated (i.e. lower energy interfaces
    constructed) by replacing uniform elastic strains
    with dislocations (which localizes the strain
    into the dislocation cores), fig. 3.35.
  • The dislocation spacing in 1D is given by D
    dB/ d .For small enough misfits, this can be
    written as D d/ d.
  • The Burgers vector, d, of the interface
    dislocations is given by d (dAdB)/2

21
Semi-coherent interfaces, contd.
  • Just as for low angle grain boundaries, the
    interface energy is proportional to the
    dislocation density at small misfits and then
    following a logarithmic dependence at larger
    misfits.
  • In two dimensions, a network involving more than
    one Burgers vector may be required to accommodate
    the misfit.
  • The limit to dislocation-based structures is at
    d 0.25, corresponding to one dislocation every
    four plane spacings (where the cores start to
    overlap).
  • Interface energies are in the 200-500 mJ.m-2
    range.

22
Complex semi-coherent interfaces
  • It can often happen that an orientation
    relationship exists despite the lack of an exact
    match.
  • Such is the case for the relationship between bcc
    and fcc iron (ferrite and austenite).

Note limited atomic match for the NS relationship
23
Orientation relationships in iron
  • There are two well-known orientation
    relationships for fcc-bcc iron.
  • The Nishiyama-Wasserman (NW) relationship is
    specified as 110bcc/111fcc,
    lt001gtbcc//lt101gtfcc.
  • The NS relationship only gives good atomic fit in
    8 of the boundary area.
  • The Kurdjumov-Sachs (KS) relationship is
    specified as 110bcc/111fcc,
    lt111gtbcc//lt101gtfcc.
  • These two differ by only a 5.6 rotation in the
    interface plane.
  • Better atomic matching is possible for irrational
    planes used.

24
Orientations from KS OR
  • Based on a particular orientation relationship
    (OR), the orientations of new grains of the
    product phase can be predicted, as derived from a
    product phase.
  • Illustrated for the Kurdjumov-Sachs (KS)
    relationship for iron, with the 001lt100gt
    starting orientation for the fcc (austenite)
    phase.
  • The different new orientations are called
    variants.

001 pole figure, showing 001 poles in the
eight variant positions of the ferrite phase for
the KS OR, starting from a single austenite
crystal in (001)100 position.
25
Incoherent Interfaces
  • Not surprisingly, incoherent interfaces have a
    disordered structure similar to high angle grain
    boundaries.
  • Their energies range up to 1 J.m-2.
  • Little is known about the detailed structure of
    such interfaces.
  • Large differences in crystal structure and
    lattice parameter between parent and product
    phases tend to mean that the interface must be
    incoherent.
  • Possibilities for partially coherent interfaces
    exist even under the latter circumstance, but
    better tools are need for prediction of interface
    structure and energy (current research topic,
    e.g. W. Reynolds).

26
Interfaces in precipitates
  • In order to present examples of real systems, it
    is important to keep in mind that the interface
    around a precipitate is not, in general, the same
    over the entire surface.
  • Analogy with grain boundaries the boundary of an
    island grain (fully enclosed within another
    grain) varies from pure twist at opposite poles,
    to pure tilt around its equator.
  • Thus, some precipitates possess a mixture of
    interface types around their perimeter.

Misorientation axis
Tilt boundary on the equator
Twist boundaries on the poles
27
Fully coherent precipitates
  • One example of the Cu-Si system has been given.
  • Precipitation of Co from Cu is another example.
  • Guinier-Preston zones in the early stages of
    precipitation in Al alloys are another example.
  • See fig. 3.39 in PE for Ag-rich zones in Al-4Ag.
  • In all cases, the crystal structure is the same
    in parent and product also the lattice
    parameters are similar.

28
Partially coherent precipitates
  • When only part of the surface of a precipitate
    can be coherent, it is said to be partially
    coherent.
  • Typically, one plane is coherent or
    semi-coherent.
  • As fig. 3.40 shows, the shape of the precipitate
    can be determined by the Wulff shape through the
    inverse ratio of the interfacial energies. Large
    coherent facets are terminated by incoherent
    edges.
  • Caution! An anisotropic shape can also be
    determined by either growth anisotropy or elastic
    anisotropy.

29
Widmanstätten morphology
  • Widmanstättens name is associated with platy
    precipitates that possess a definite
    crystallographic relationship with their parent
    phase.
  • Examples - ferrite in austenite (iron-rich
    meteors!) - g precipitates in Al-Ag (see fig.
    3.42) - hcp Ti in bcc Ti (two-phase Ti alloys,
    slow cooled) - q precipitates in Al-Cu
  • The latter example is based on the orientation
    relationship (001)q//001Al, 100q//lt100gtAl.
    See fig. 3.41 for a diagram of the tetragonal
    structure of q whose a-b plane, i.e. (001),
    aligns with the (100) plane of the parent Al.

30
Incoherent precipitates
  • Al alloys provide many examples of incoherent
    precipitates that lack orientation relationships.
  • CuAl2 (q) in Al - fig. 3.44Al6Mn in AlAl3Fe in
    Al
  • Note that heterogeneous nucleation at grain
    boundaries can give rise to precipitates that are
    incoherent on one side, and semi-coherent on the
    other side. This leads to significant
    differences in growth rate, fig. 3.45.

31
Elastic Effects
  • The effects of elastic interactions between the
    matrix and the precipitate can be as important as
    for the interfacial energy.
  • The two effects can compete this is one reason
    for changes during growth, such as the loss of
    coherency.
  • Elastic effects can influence precipitate shape.

32
Misfit
  • Imagine that a certain volume of the parent phase
    (matrix) is removed and replaced by a different
    volume of product phase (precipitate). The
    difference in volume leads to a dilatational
    strain which is positive or negative, depending
    on the sign of the volume change.
  • In the case of identical crystal structures and a
    coherent interface, the parent and product have
    equal and opposite forces at the interface, see
    fig. 3.47c.

33
Misfit definitions
  • Given lattice parameters specified as aA and aB,
    the misfit parameter, d is given by the following
    simple formula d (aB - aA)/ aA
  • Note the similarity to the definition of misfit
    for coherent and semi-coherent interfaces.
  • In the case of dilatational/hydrostatic strains,
    one can define a constrained misfit or in situ
    misfit based on the strained precipitate lattice
    parameter, aB e (aB - aA)/ aA

34
Elastic strain energy
  • The constrained misfit and the unconstrained
    misfit are related to each other. For the
    simplest case of identical moduli in parent and
    product, e 2d/3
  • For typical variations in moduli, the range of
    values observed is d/2 lt e lt d.
  • The elastic energy associated with the
    dilatational strains is of order d2 V, where V is
    the volume. For the simplest case of isotropic
    matrix and precipitate, the elastic energy is
    independent of shape ?Gs 4µd2V - µ is
    the shear modulus.

35
Strain energy anisotropy
  • The effect of modulus differences is interesting
    and asymmetric Precipitate stiffer than matrix
    minimum elastic energy occurs for a
    sphere.Precipitate more compliant than matrix
    minimum elastic energy occurs for a disc (oblate
    ellipsoid).
  • Note that differences in elastic modulus can be
    synergistic or antagonistic to effects of
    interface structure.
  • Anisotropic matrix most cubic metals are more
    compliant along lt100gt, hence elastic energy
    considerations favor discs perpendicular to lt100gt.

36
Elasticity vs coherency
  • The competition between elastic energy and
    interfacial energy is illustrated by reference to
    specific examples in Al alloys.
  • Observation a sequence of precipitation
    reactions is observed in Al-Cu alloys (containing
    up to, say 5Cu, i.e. the maximum solid
    solubility of Cu in Al, at the eutectic
    temperature).
  • The sequence can be explained as the appearance
    of successively more stable precipitates, each of
    which has a larger nucleation barrier.

37
Al-Cu precipitation sequence
  • The sequence is a0 ? a1 GP-zones ? a2 q?
    a3 q? a4 q
  • The phase are an - fcc aluminum nth subscript
    denotes each equilibriumGP zones - mono-atomic
    layers of Cu on (001)Al q - thin discs, fully
    coherent with matrix q - disc-shaped,
    semi-coherent on (001)q bct. q - incoherent
    interface, spherical, complex body-centered
    tetragonal (bct).

38
Al-Cu driving forces
  • Each precipitate has a different free energy
    curve w.r.t composition. Exception is the GP
    zone, which may be regarded as continuous with
    the alloy (leading to the possibility of spinodal
    decomposition, discussed later).
  • PE fig. 5.27 illustrates the sequence of
    successively greater free energy decreases and
    also successively greater ?G.
  • PE fig. 5.28 illustrates the point that the
    nucleation barriers are much smaller for each
    individual nucleation step when the next
    precipitate nucleates heterogeneously on the
    previous structure.

39
Al-Cu ppt structures
GP zone structure
40
Nucleation sites, reversion
  • The nucleation sites vary depending on
    circumstances.
  • q most likely nucleates on GP zones by adding
    additional layers of Cu atoms.
  • Similarly, q nucleates on q by in-situ
    transformation.
  • However, q can also nucleate on dislocations,
    see PE fig. 5.31a.
  • The full sequence is only observable for
    annealing temperatures below the GP solvus. Any
    of the intermediate precipitates can be
    dissolved, reverted, by increasing the
    temperature above the relevant solvus, fig. 5.32.

41
Coherency loss
  • The growth of the penultimate precipitate, q,
    illustrates an important point about the loss of
    coherency that commonly occurs during growth.
  • A precipitate may start out fully coherent but
    nucleate interfacial dislocations once it reaches
    a critical size.
  • Illustration large q ppts commonly have
    dislocations, see PE fig. 5.30c.
  • Why? Again, a competition exists between
    volumetric elastic energy, and interfacial energy.

42
Coherency loss, analysis
  • The assumptions of the simple analysis (PE
    section 3.4.4) are elastic strain energy is
    significant for the fully coherent case, not for
    the non-coherent case. Also, the energy of
    non-coherent interface is significantly larger
    than that of the coherent interface.
    Thus ?Gcoherent ?Gelastic
    ?Ginterface 4µd2 4pr3/3
    4pr2gcoherent ?Gnon-coherent ?Gelastic
    ?Ginterface 0
    4pr2gnon-coherent
  • At some size, the former becomes larger than the
    latter. Provided dislocations (or other defects)
    can be nucleated, the character of the interface
    will change, and coherency will be lost.

43
Coherency loss, estimates
  • It is possible to estimate the size, and type of
    precipitate for coherency loss.
  • Given a difference in interfacial energy between
    coherent and non-coherent (which PE write as gst
    gnon-coherent - gcoherent), one can estimate a
    critical radius, rcrit. rcrit 3?g/4µd2.
  • Fig. 3.53 illustrates the requirement for
    dislocation loops to be arranged on the perimeter
    of the precipitate (similar to a low angle grain
    boundary).
  • Based on a constrained misfit, e, the minimum
    stress required to nucleate a dislocation (fig.
    3.54a) is of order 3µe and the minimum value of
    misfit to exceed the theoretical shear strength
    of a matrix is e 0.05. This implies that
    precipitates that have a small enough misfit will
    never lose coherency as they grow because they
    are unable to nucleate the required interfacial
    dislocations.

44
Impact on Properties
  • The most obvious impact of precipitation in
    metals is on mechanical strength.
  • Precipitation was measured by hardness, long
    before the structure of the precipitates was
    known.
  • Example age-hardening curves in Al-Cu alloys,
    PE fig. 5.37.

45
Summary
  • This lecture may be summarized by stating that
    both differences in elastic properties and
    interface structure exert a strong influence on
    precipitate morphology.
  • Through their effect on free energy changes as a
    function of size, they also affect which
    precipitates actually nucleate under any given
    conditions.
  • The precipitate with the smallest nucleation
    barrier (generally) appears first. Small
    nucleation barriers are associated with coherent
    interfaces (small interfacial energy) and similar
    lattices (small elastic energies from misfit).
Write a Comment
User Comments (0)
About PowerShow.com
