Multiphysics Extension of OpenFMO Framework

1
Multi-physics ExtensionofOpenFMO Framework

• Toshiya Takami, J. Maki, J. Ooba,
• Y. Inadomi, H. Honda, R. Susukita,
• K. Inoue, T. Kobayashi, R. Nogita,
• M. Aoyagi

Research Inst. for Inf. Tech. Kyushu University,
Japan
2
Contents

• Computing Environment
• Grid to Peta Computer
• TeraGrid, EGEE, NAREGI
• ? Peta-scale Computer
• Mediator-API
• Performance prediction

• Scientific Studies on Coupled Simulations
• FMO in Water
• 3D-RISM/FMO
• Nonlinear Science

• OpenFMO for Multi-physics Simulations
• Multi-scale design of FMO with a skeleton and
  MO-API
• One-sided-communication implementation for HPC
• Open-framework for Multi-physics Simulations

3
Fragment Molecular Orbital Method (1)

• Fragment MO method, developed by Dr. Kitaura in
  AIST, Japan,is known as an approximate method of
  all electron calculation for large molecules.
• The target is divided into fragments with one or
  two residues. SCF calculation of each fragment
  is performed under the ES potential made by other
  fragments. After improvements with respect to
  pairs of fragments, the total energy is obtained.
• This algorithm has been implemented in ABINIT-MP
  (http//moldb.nihs.go.jp/abinitmp/),GAMESS
  (http//www.msg.ameslab.gov/GAMESS/),etc.

Works on FMO by Dr. Kitauras group K. Kitaura,
E. Ikeo, T. Asada, T. Nakano and M. Uebayasi,
Chem. Phys. Lett. 313, 701 (1999). K. Kitaura, S.
Sugiki, T. Nakano, Y. Komeiji and M. Uebayasi,
Chem. Phys. Lett. 336, 163 (2001). D.G. Fedorov
and K. Kitaura, J. Chem. Phys. 120, 6832 (2004).
D.G. Fedorov and K. Kitaura, J. Chem. Phys. 121,
2483 (2004).
4
Fragment Molecular Orbital Method (2)

• The flow of FMO calculation can be represented in
  this figure.
• The main part is a self-consistent loop of SCF
  calculations of fragments under the
  electro-static potential made by other fragments.
• This is executed until the total electro-static
  potential is converged.
• After the convergence, fragment-pair calculation
  is carried out over all combinations of two
  fragments in order to improve the result.

• Parallel execution
• Calculations of fragments and fragment-pairs can
  be parallelized.
• Since the SCF calculation itself can be
  parallelized, FMO is executed under a
  hierarchical parallelization scheme.

D.G..Fedorov, R.M. Olson, K. Kitaura, M.S.
Gordon, and S. Koseki, J. Comp. Chem. 25, 872
(2004).
5
RISM/SCF MO in Aqueous Solution (1)

• SCF calculations of molecules in water
• RISM/SCF Tenno-Hirata-Kato, 1993, 1994
• RISM/MCSCF Sato-Hirata-Kato, 1996
• 3D-RISM/DFT Kovalenko-Hirata, 1999
• 3D-RISM/SCF Sato-Kovalenko-Hirata, 2000

S. Ten-no, F. Hirata and S. Kato, CPL 214, 391
(1993) S. Ten-no, F. Hirata and S. Kato, JCP 100,
7443 (1994). H. Sato, F. Hirata and S. Kato, JCP
105, 1546 (1996). A. Kovalenko and F. Hirata,
JCP 110, 10095 (1999). H. Sato, A. Kovalenko and
F. Hirata, JCP 112, 9463 (2000).

• RISM (Reference Interaction Site Model)
• Statistical mechanics of molecular liquid without
  any fitting parameter
• 3D-RISM is 3D version of RISM.

from JCP 100, 7443 (1994)
F. Hirata, ed., Molecular Theory of Solvation,
(Kluwer Pub., 2003)
6
RISM/SCF MO in Aqueous Solution (2)

• We have done several test execution on small
  proteins in aqueous solution.

chignolin (138 atoms)
met-enkephalin (75 atoms)
7
RISM/SCF MO in Aqueous Solution (3)

• Our recent work 3D-RISM/SCF calculation as a
  multi-physics simulation in molecular science
• Fictitious parameter is introduced to find many
  avoided structures in orbital energies.
• Localization of one-electron orbitals is analyzed
  through eigenvalue statistics (Brody analysis).

T. Takami, J. Maki, J. Ooba, T. Kobayashi, R.
Nogita, and M. Aoyagi, Interaction and
Localization of One-electron Orbitals in an
Organic Molecule the Fictitious Parameter
Analysis for Multi-physics Simulations, J. Phys.
Soc. Jpn. 76, 013001 (2007).
from JPSJ 76, 013001 (2007)
8
Computing Environments

• Computing Environment
• Grid to Peta Computer
• TeraGrid, EGEE, NAREGI
• ? Peta-scale Computer
• Mediator-API
• Performance prediction

• Scientific Studies on Coupled Simulations
• FMO in Water
• 3D-RISM/FMO
• Nonlinear Science

• Computing Environment
• Grid to Peta Computer
• TeraGrid, EGEE, NAREGI
• ? Peta-scale Computer
• Mediator-API
• Performance prediction

• OpenFMO for Multi-physics Simulations
• Multi-scale design of FMO with a skeleton and
  MO-API
• One-sided-communication implementation for HPC
• Open-framework for Multi-physics Simulations

9
From Grid to Peta-scale Computing

• TeraGrid
• http//www.teragrid.org/
• EGEE
• http//www.eu-egee.org/
• NAREGI
• http//www.naregi.org/

• Next-generation Supercomputer Project
• http//www.nsc.riken.jp/

10
3D-RISM/FMO by Mediator-API

• Mediator-API provides transformation/exchange of
  data between each component in coupled
  simulation.
• This is parallelized with GridMPI to achieve
  electronic-state calculations of a protein
  molecule in water.

S.Ho, S.Itoh, S.Ihara and R.D.Schlichting, Agent
middleware for heterogeneous scientific
simulations, in Proceedings of ACM/IEEE SC 1998
Conference (SC98), 1998, p. 15.
11
Performance Prediction of FMO
1,000,000 CPUs
This may be available within ten years.
10,000 nodes
100 times faster than current P4
P4
P4
P4
P4
...
P4
P4
P4
P4
...
...
P4
P4
P4
P4
multi-core CPU
multi-core CPU
multi-core CPU
multi-core CPU
P4
P4
P4
P4
We assume this type of hierarchical computer.

• If we assume the hierarchical computer (10,000
  nodes of 100 core CPUs)
• The total execution time is represented in a
  quadratic function of .
• The execution time can be estimated on the 10,000
  nodes computer with a sufficient performance in
  each node.
• All electron calculation of a molecule with
  100,000 fragments (approx. 2,000,000 atoms) can
  be executed by FMO in a day.

Total execution time of FMO
T. Takami, J. Maki, J. Ooba, Y. Inadomi, H.
Honda, T. Kobayashi, R. Nogita, and M.
Aoyagi, Open-architecture Implementation of
Fragment Molecular Orbital Method for Peta-scale
Computing, appear in Proceedings of HPCNano06
held in SC06, Tampa, FL. (2007)
arXivcs/0701075v1 cs.DC
12
OpenFMO Project

• Computing Environment
• Grid to Peta Computer
• TeraGrid, EGEE, NAREGI
• ? Peta-scale Computer
• Mediator-API
• Performance prediction

• Scientific Studies on Coupled Simulations
• FMO in Water
• 3D-RISM/FMO
• Nonlinear Science

• OpenFMO for Multi-physics Simulations
• Multi-scale design of FMO with a skeleton and
  MO-API
• One-sided-communication implementation for HPC
• Open-framework for Multi-physics Simulations

• OpenFMO for Multi-physics Simulations
• Multi-scale design of FMO with a skeleton and
  MO-API
• One-sided-communication implementation for HPC
• Open-framework for Multi-physics Simulations

13
OpenFMO Project (1)

• It is revealed that FMO calculations can exhibit
  peta-scale performance in the next-generation
  supercomputer. However, it is known that the
  present implementations have significant problems
  in
• the memory allocation
• communications between processes.
• and may not be executed in the peta machines.
• Then, we began a project named OpenFMO. The main
  objective of this project is to construct the FMO
  program which can be executed in peta-scale
  computers.

14
OpenFMO Project (2)

• This project stands for the following
  Opennesses
• Open Architecture Implementation of Skeleton and
  APIs(Dr. Maki, Dr. Inadomi, Dr. Honda)
• The layered structure of the control program
  (skeleton) and the molecular orbital API (MO-API)
  is successfully developed. It was found that the
  one-sided communication implementation using
  MPI-2 functions outperforms the usual one based
  on MPI.
• Open Interface to Multi-physics Simulations(Dr.
  Kobayashi, T.T. (myself))
• FMO can also be opened to multi-physics
  simulations. Since it is based on electro-static
  interaction between fragments, each fragment can
  be substituted by the general object which can
  provide a static charge distribution.
• Open Source License
• The source code of the skeleton program of
  OpenFMO is publicly opened according to some
  open-source license like GPL.

T. Takami, J. Maki, J. Ooba, Y. Inadomi, H.
Honda, T. Kobayashi, R. Nogita, and M.
Aoyagi, Open-architecture Implementation of
Fragment Molecular Orbital Method for Peta-scale
Computing, appear in Proceedings of HPCNano06
held in SC06, Tampa, FL. (2007)
arXivcs/0701075v1 cs.DC
15
OpenFMO Project (3)

• Subjects Achieved and Future Schedule
• In 2006
• A skeleton program based on the parallelization
  scheme of GAMESS-FMO (by Dr. Maki).
• Interfaces of MO-APIs (by Dr. Inadomi and Dr.
  Maki).
• Web pages of OpenFMO (by Dr. Maki and T.T.
  (myself))
• The first half of 2007
• The new style skeleton which can be executed on
  the peta-scale resources (by Dr. Maki and Dr.
  Inadomi, see below).
• Determin multi-physics interfaces (Dr. Kobayashi,
  and myself)
• The latter half of 2007
• Beta release of the multi-physics application

J.Maki, Y.Inadomi, T.Takami, R.Susukita, H.Honda,
J.Ooba, T.Kobayashi, R.Nogita, K.Inoue, M.Aoyagi,
One-sided Communication Implementation in FMO
Method, appear in Proceedings of HPCAsia07.
OpenFMO web-site http//www.OpenFMO.org/
16
Multi-physics Extension (1)

• Multi-physics/multi-scale applications will play
  an important role in the benchmark for peta-scale
  computers, since there is a limit in the
  scalability of a single application.
• From scientific points of view, they will be a
  significant milestone when we concern complex
  multi-scale problems.

Multi-scales in phenomenon
Stack structure of multi-simulator
17
Multi-physics Extension (2)

• Conditions
• Light-weight, reconfigurable structure is
  required in order to correspond the rapidly
  changing world of high-performance computing
• be very adaptive for the computational
  environments
• This program should be used by wide-range
  reseachers including beginners.
• reliability and stability of the program are
  required
• Open architecture must be preserved after the
  multi-physics extension.
• should be developed on a kind of standards

18
Multi-physics Extension (3)
Multi-physics Simulation
3D-RISM
FMO
Rapidly Changing Computing Environement
19
Multi-physics Extension (3)
Multi-physics Simulation
FMO
3D-RISM
Rapidly Changing Computing Environement
20
Multi-physics Extension (4)

• Component-based configuration, which is already
  done in the original OpenFMO using
  Skeleton/MO-API implementation
• Standard Communication Protocol between each
  components
• Web/Grid Services with many WSXX Standards
• RPC-based invocation / MPI parallel programing
• ...
• Standard Data Representation, or Mediator-like
  APIs for transformation of the physical data
• BMSML (BioMolecular Simulation Markup Language)
• CML (Chemical Markup Language)
• netCDF (Network Common Data Format)
• ...

Completed!!
Not yet Completed!!
21
Summary

• Several implementations and applications on (3D)
  RISM/SCF as a multi-scale/multi-physics
  simulation are reviewed, where various
  interesting phenomena can be investigated as
  scientific simulations.
• I have also mentioned that these applications and
  studies are performed on rapidly changing
  computer environments such as Grid,
  peta-computer, vector / scalar architecture,
  network topology, and so on.
• We are still struggling in the multi-physics
  extension of OpenFMO, which is originally
  introduced as an open-sourced software in order
  to avoid the dead-end in development of large
  and complex applications.

22
Acknowledgements

• Collaborated with
• Dr. J. Maki, Dr. Y. Inadomi, Dr. H. Honda,Dr. R.
  Susukita, Prof. K. Inoue, Ms. R. Nogita,Dr. T.
  Kobayashi, Prof. M. Aoyagi(PSI/NAREGI Project
  Members in Kyushu Univ.)
• Thanks to
• Dr. T. Ikegami, Dr. S. Sekiguchi (AIST, Tsukuba)
• Prof. S. Matsuoka (Tokyo Inst. Tech, Japan)
• Special Thanks to
• Director K. Murakami, Prof. T. Nanri, Dr. F-L. Gu
• Organizer of this Symposium
