LAM 101

1
LAM 101

• Jean M. Elwing, MD
• University of Cincinnati
• April 17, 2009

2
Overview

• What is LAM?
• How many people have LAM?
• How does it effect my lungs / lymphatics /
  kidneys?
• Why does it make you breathless?
• How are LAM and tuberous sclerosis related?
• How can your doctor treat and monitor LAM?

3
What is LAM?

• lymph lymphatics
• angio blood vessels
• leiomyo smooth muscle
• matosis a condition

4
Lymphangioleiomyomatosis
5
What is the difference?

• Lymphangioleiomyomatosis
• Lymphangiomyomatosis

• None

• There is a disease called lymphangiomatosis
  that is different

6
What is LAM?

• A build up of LAM cells in the lungs and
  lymphatics
• LAM cells dont stop growing like normal cells
• LAM cells travel in the blood and lymph

7
How many people have LAM?

• Sporadic LAM
• 2-6 per million
• 30-50,000 women
• Women 16-65 years one per 373,000
• TSC - LAM
• 1 million people who have TSC
• 50 are women
• 30-40 of adult women with TSC have LAM
• Most dont have symptoms

8
What do these stand for?

• Dx

• Diagnosis

• Bx

• Biopsy

• CXR

• Chest x-ray

• CT

• Cat Scan

• Treatment

• Tx

• Angiomyolipoma

• AML

• Pneumothorax

• PTx

• S-LAM

• Sporadic LAM

• Tuberous sclerosis-LAM

• TSC-LAM

9
How does LAM effect my lungs?

• Abnormal cells build up in the lungs
• Cells produce proteins which cause cysts
• Cysts and LAM cells cause breathlessness

10
Where do LAM cells come from?

• Nobody knows
• But
• There is genetic evidence that in some patients
  they may come from another site in the body,
  maybe angiomyolipomas, lymph nodes

11
How can smooth muscle cells do this?
12
This is a smooth muscle cell
13
Healthy tissuessmooth muscle cells line up
14
Healthy smooth muscle tissue is organized
15
Smooth muscle surrounds blood vessels, airways
and lymphatics
16
LAM smooth muscle cells are haphazardly arranged
17
Can you tell the difference?

• LAM smooth muscles cells do not follow the normal
  patterns when they surround blood vessels,
  airways and lymphatics

Smooth Muscle Cells
LAM Smooth Muscle Cells
18
How does LAM affect my lungs?

• Cysts
• Reduce oxygen uptake
• Traps air
• Increases risk for pneumothorax
• Pneumothorax
• Chylous effusion
• Airway narrowing

19
LAM on CT Chest
20
Lung Cysts and Bulla
21
A bulla is a large cyst, a bleb is a blister like
spot on the pleural surface
22
Pneumothorax

• Blebs/cysts can leak air causing pneumothorax
• Pneumothorax in LAM can be difficult to treat

23
How does LAM affect my lungs?

• Cysts
• Reduce oxygen uptake
• Traps air
• Increases risk for pneumothorax
• Pneumothorax
• Chylous effusion
• Airway narrowing

24
What is a Pneumothorax?
25
Right sided pneumothorax
26
Right sided pneumothorax on CT
27
How do I know if I have a pneumothorax?

• Persistent shortness of breath
• Persistent chest, shoulder, back or abdominal
  pain
• CXR is a very good test for a pneumothorax
• But... a pneumothorax is sometimes only visible
  on CT

28
Why cant you see all pneumothorax on CXR?
29
What are the treatments for Pneumothorax?

• Sometimes observation only
• Oxygen
• Needle aspiration
• Chest tube drainage
• Pleurodesis

30
What is pleurodesis?

• A procedure to fuse the lung to the chest wall so
  that it wont collapse again

31
How does LAM affect my lungs?

• Cysts
• Reduce oxygen uptake
• Traps air
• Increases risk for pneumothorax
• Pneumothorax
• Chylous effusion
• Airway narrowing

32
Why do chylous effusions occur?

• LAM cells can block lymph flow
• This occurs in the lung and other lymph channels

33
Where are the lymphatics?

• Removal of fluid from tissues
• Transports fatty acids and fats as chyle to the
  circulatory system.
• Immune systems

34
What is chylous effusion?
35
Chest tubes drain the pleural space
36
How does LAM affect my lungs?

• Cysts
• Reduce oxygen uptake
• Traps air
• Increases risk for pneumothorax
• Pneumothorax
• Chylous effusion
• Airway narrowing

37
Smooth muscle surrounds airways
Narrowing of the airways may be caused by the
growth of LAM cells
38
How does LAM affect my kidneys?
39
Abdominal LAM

• About 50 of people with LAM have an
  angiomyolipoma (AML)
• About 70-80 people with TSC-LAM have an AML
• Most are small and dont cause symptoms
• Contain blood vessels, LAM smooth muscle cells
  and fat

Angiomyolipoma
Angiomyolipoma
Angiomyolipoma
40
What about the kidney tumors?

• Many never cause problems

• If it causes a problem, its usually due to
  bleeding

• Bleeding can usually be controlled nonsurgically
  by embolization

41
Is LAM inherited?

• Yes
• Tuberous Sclerosis (TSC)
• 1/3 Inherited --- 2/3 new mutations
• Tuberous Sclerosis-LAM (TSC-LAM)
• Very rarely can be inherited
• Few cases reported in the medical literature
• No
• Sporadic LAM (S-LAM)
• Cannot be inherited

42
What are the genetics of LAM?
Germ cells
LAM cells
TSC-LAM
?
S-LAM
Somatic mutations
43
What is tuberous sclerosis (TSC)?

• A disease of multiple benign tumours
• skin, brain, kidneys, heart, LAM
• Diagnosis
• Clinical evaluation
• Tests CT MRI brain

44
What can I do for my LAM?

• Healthy lifestyle
• Pulmonary rehabilitation
• Flu vaccination
• Pneumonia Vaccination
• NO Smoking
• This increases the loss of lung function

45
Is there any directed treatment?

• Unclear at this point
• Further study is ongoing
• Close follow up with a pulmonary physician

46
What are PFTs and which are the important ones?
47
Spirometry

• FEV1-forced expiratory volume one-the volume of
  air that is forcibly exhaled in one second
• FVC-forced vital capacity-the volume of air that
  is forcibly exhaled over infinite time
• FEV1/FVC-the ratio of volume exhaled in one
  second, to all volume exhaled over infinite time

48
Simple spirometry
49
Spirometry

• Rate of decline in FEV1 is an index of disease
  progression
• Normal women lose about 10-25 mls of FEV1 per
  year
• Women with LAM lose about 100 mls per year (1/3rd
  of a coke can)
• Patients who smoke lose about 70 mls per year

50
Helium dilution can be used to determine the
volume of gas in the lung at rest
51
Diffusion capacity for carbon monoxide (DLCO)

• Assesses the integrity of the pulmonary capillary
  bed
• Measure the absorption of a trace amount of
  carbon monoxide into the lungs, as a means to
  measure ease of oxygen uptake

52
Diffusion capacity for carbon monoxide (DLCO)

• Most LAM patients have a reduced DLCO
• Reduction in DLCO correlates with severity of
  disease
• Isolated readings can vary, it is trends that are
  important

53
Any questions?

• Thanks to Drs. McCormack, Young and Johnson
  sharing slides for this presentation.
