Title: Improving MapReduce Performance in Large Virtualized Environments


1
Improving MapReduce Performance in Large
Virtualized Environments
  • Andy Konwinski, Matei ZahariaAnthony Joseph,
    Randy Katz, Ion Stoica
  • RAD Lab, June 2008

2
RAD Lab Overview
Low level spec
Com- piler
High level spec
Instrumentation Backplane
New apps, equipment, global policies (eg SLA)
Offered load, resource utilization, etc.
Director
Training data
performance cost models
Log Mining
3
RAD Lab Overview
Low level spec
Com- piler
High level spec

Instrumentation Backplane
New apps, equipment, global policies (eg SLA)
Offered load, resource utilization, etc.
Director
Training data
performance cost models
Log Mining
4
Motivation Objectives
  • Motivation
  • MapReduce growing in popularity
  • Virtualized computing services like Amazon EC2
    provide on-demand computing power
  • But, MR assumes homogeneous environment
  • Objectives
  • Study impact of virtualization on Hadoop
  • Improve Hadoop performance on EC2

5
Methodology
  • Measured EC2 performance using low level and
    application benchmarks
  • Identified two challenges
  • EC2 effects
  • Heterogeneity
  • Designed heterogeneity-aware scheduler that
    reduces response times up to 2x

6
Outline
  • Experience running Hadoop on EC2
  • Choosing EC2 instance types
  • Disk and network cold start effects
  • The challenge of heterogeneity
  • LATE a heterogeneity-aware scheduler
  • Lessons about virtualized environments

7
Choosing EC2 Instance Types
  • 3 VM types small (0.10/h, 1 disk), large
    (0.40/h, 2 disks), xlarge (0.80/h, 4 disks)
  • Goal maximize computing power / dollar
  • Observation Small VMs have same CPU RAM per
    dollar as large, but more net disk bandwidth
    when no contention
  • Environment chosen
  • 100-900 small VM for slaves
  • 1 large VM for master

8
Disk Cold Start
  • First write to each disk location is slow
    (possibly due to allocation or security?)
  • Recommendation warm up nodes with dd

Bytes Written
Time (s)
9
Network Cold Start
  • First time two machines communicate incurs 2-5s
    delay (maybe firewall setup?)
  • Effect on Hadoop sorting 200 GB on 200 nodes
    takes 20 min first time, 4 min later
  • Also makes setup slow
  • Recommendation warm up network with a short
    MapReduce job automate setup

10
Heterogeneity in Virtualized Environments
  • Virtual machine technology isolates CPU and
    memory effectively
  • However, disk and network are shared
  • Full bandwidth when no contention
  • Fair sharing if there is contention

11
Disk IO Heterogeneity on EC2
  • Result IO bandwidth / VM varies by 2.5x
  • Same effect seen at application level

Effect of contention on I/O performance on EC2
12
Speculative Scheduling in MapReduce
  • Hadoop assumes nodes have similar performance,
    launches backup copies of slow tasks to speed
    up response times
  • This is critical for short interactive jobs,
    which are large fraction of workload
  • E.g. average job at Google is 395s
  • Problem How to select backup tasks in a
    heterogeneous environment?

13
Hadoops Scheduler
  • Hadoops scheduler uses fixed threshold create
    backup copies of all tasks with progress lt
    averageProgress 20
  • Problems
  • Too many tasks may be backed up, thrashing shared
    resources like the network
  • Wrong tasks may be backed up if slightly slow
  • Tasks never backed up if progress gt 80
  • Tasks may be restarted on slow nodes

14
Example 900 Node Run
  • 80 of reduce tasks had backups started
  • 1.3 hours to sort 100 GB

80!
15
New Scheduler LATE
  • Longest Approximate Time to End
  • Back up the task with the largest estimated
    finish time
  • Cap backup tasks to 10
  • Only launch backups on fast nodes
  • Only back up tasks that are slow enough

16
LATE Details
  • Estimating finish time
  • Thresholds
  • 25th percentiles work well for slow node/task
  • Backup task cap can be controlled to trade off
    throughput vs response time (currently 10)

17
Evaluation
  • 2 environments
  • 200 EC2 VMs, with 1-7 VMs per physical host,
    emulating mix seen in production
  • Smaller, controlled testbed (RECC RADLab
    Elastic Compute Cloud)
  • 3 job types Sort, Grep, WordCount
  • 2 metrics response time (primary), throughput
    (should not be degraded)

18
EC2 Sort with No Stragglers
  • Average 27 gain over native, 31 gain over no
    speculation

19
EC2 Sort with Stragglers
  • Average 58 gain over native, 220 gain over no
    speculation
  • 93 max gain over native

20
EC2 Sort Throughput
Jobs/second for three simultaneously submitted
Sorts
  • Average 5.1 gain over native, 18 gain over no
    speculation

21
EC2 Grep WordCount
Grep
WordCount
  • Average 36 gain over native, 57 gain over no
    speculation
  • Average 8.5 gain over native, 179 gain over no
    speculation

22
RECC Sort with No Stragglers
  • Average 162 gain over native, 104 gain over no
    speculation
  • 261 max speedup over native.

23
RECC Sort with Stragglers
  • Average 53 gain over native, 121 gain over no
    speculation
  • 100 max speedup over native.

24
RECC WordCount
  • Average 14 gain over native, 113 gain over no
    speculation

25
Summary of Results
26
Lessons for Virtualized Environments
  • Heterogeneity matters
  • CPU and memory isolation works well, disk and
    network not so much
  • Ideally, environment should minimize variance
  • Otherwise, modify app to tolerate variance
  • Document best practices and quirks
  • Provide better visibility monitoring tools

27
Conclusion
  • Analyzed EC2 with a real application
  • Identified heterogeneity as a challenge and
    addressed it in Hadoop
  • 2x better response times through LATE
  • Demonstrated X-Trace at 900 nodes

28
Future Work
  • Integrate LATE into Hadoop codebase
  • Run LATE on more realistic jobs (Hadoop grid mix
    benchmark?)
  • Scheduling among different jobs
  • Scheduling tasks on the same node

29
Questions?
?
?
?
30
Improving MapReduce Performance in Large
Virtualized Environments
  • Andy Konwinski and Matei Zaharia

31
Tips for Hadoop on EC2
  • Automate cluster setup
  • Warm up system with dds and small job
  • Choose instance type based on needs
  • Smalls usually have more IO bandwidth /
  • Large is necessary for Hadoop master
  • EC2 now added high-CPU instances too!
  • Consider turning down DFS replication for a
    significant performance gain

32
Tracing Hadoop on EC2
Hadoop Slave
Hadoop Slave
Hadoop Slave
Hadoop Master
TCP
X-Trace Backend
Trace Analysis Web UI
HTTP
HTTP
Derby DB
Filesystem
User
33
Scaling up X-Trace
  • X-Trace backend improved to use asynchronous IO
    and a hybrid filesystem RDMBS data store still
    single server
  • Found overhead of tracing to be negligible in
    Hadoop since operations are large
  • 1-2 MB / node / hour of trace data generated
    compresses by a factor of 20
