Title: ICEBERG: An InternetBased, Integrated Communication System


1
ICEBERGAn Internet-Based, Integrated
Communication System
  • Helen J. Wang
  • ICEBERG Project, U C Berkeley
  • http//iceberg.cs.berkeley.edu/
  • August 1, 2000

2
Motivation
  • Lack support for
  • Integrated use of heterogeneous devices (old
    new)
  • Rapid arbitrary communication service
    customization

3
Limitations of Existing Systems
  • Telecommunications network
  • engineered with one app and device in mind
  • Existing Internet Telephony systems
  • potential of easy service creation
  • scalability, availability and fault tolerance not
    fully addressed

4
How good is a communication system?
  • Functionality communication services it can
    support, and the ease of creating them
  • Viability scalability, robustness, wide-area
    operable
  • ICEBERG a viable Internet-core communication
    system and infrastructure that supports
    heterogeneity and rapid, arbitrary communication
    service customization and creation

5
Architecture Goals
  • Any-to-any communication
  • inter-working (ICEBERG Access Point), composition
    of data transformation (Automatic Path Creation
    Service)
  • Personal mobility
  • unique ID, name mapping (Name Mapping Service)
  • Personalized communication services
  • preference storage and management (Preference
    Registry)
  • Enable user-activity driven services
  • activity tracking (Person Activity Coordinator)

6
Control ArchitectureComponents and Their
Operations
Alice_at_domain1
Bob_at_domain2
Pick up
Data Path
7
ICEBERG Architecture An Overview
Access Network Plane
ICEBERG Network Plane
Clearing House
ISP Plane
ISP1
ISP2
ISP3
8
Acronyms Lookup
  • APC Automatic Path Creation
  • CA Call Agent
  • IAP ICEBERG Access Point
  • iPOP ICEBERG Point of Presence
  • NMS Name Mapping Service
  • PAC Personal Activity Coordinator
  • PR Preference Registry

9
Leverage Cluster Computing Platforms
  • iPOP must be scalable and robust leverage
    cluster computing platforms such as Ninja, AS1
  • Our requirements
  • highly available service invocation Ninja
  • fault tolerant service session AS1
  • session state maintained on client (IAP)
  • iPOP on Ninja augmented with client heartbeat
    support from AS1
