Software Reliability Research

1
Software Reliability Research

• Pankaj Jalote
• Professor, CSE, IIT Kanpur, India

2
System Reliability

• System an entity that provides defined behavior
  at interfaces
• System is a hierarchy of subsystems, each
  subsystem being a system
• Reliability of a system - its ability to provide
  failure-free operation
• Failure the system behavior is incorrect or not
  as expected is a random phenomenon

3
Reliability Quantification

• Reliability of a system defined as failure
  probability in a time period R(t) Prob that
  system has not failed by time t
• For rel work, often distribution of R(t) is
  specified

4
Reliability Quantification..

• Reliability can also be quantified by Mean Time
  to Failure (MTTF)
• Also by failure rate (no of failures per unit
  time.)
• From R(t), MTTF or failure rate can be determined
• Under some assumptions, failure rate and MTTF are
  inversely related

5
Software Reliability

• Software (un)reliability not caused due to aging
  but due to bugs
• The more the bugs, the lesser the reliability of
  the software
• Still failures seem random, hence rel theory can
  be applied

6
Software Reliability Research

• Two main threads
• Software reliability modeling how to model and
  predict sw rel
• Improving sw reliability by removing defects
  through program checking, verification, testing,
• Will discuss some work being done here in these
  two

7
Software Reliability Modeling
8
Software Reliability

• Software systems often are one-off
• Measuring reliability in lab not practical as too
  much failure data is needed requires time
• Failures often result in fault removal, leading
  to reliability improvement
• Predicting future reliability from measured
  reliability is harder
• Hence different models needed

9
Software Reliability Growth Models

• Assume that reliability is a function of the
  defect level and as defects are removed,
  reliability improves
• Model the failure-fix process of software
  evolution
• Many models have been proposed in the last 3
  decades
• Model parameters determined from past data on
  failures and fixes

10
Reliability of Software Products

• For software products, a large population exists
  in field and faults are not removed as failures
  occur
• According to SRGMs, the reliability should remain
  the same
• I.e. the failure rate should be constant

11
Average Failure Rate of a MS Product
12
Reasons for this Phenomenon

• Users learn with time and avoid failure causing
  situation
• Users start with exploring more, then limit to
  some part of the product
• Most users use a few product features
• Configuration related failures are much more in
  the start
• These failures reduce with time

13
A New Model for Product Rel.

• For a user, there is a transient failure rate,
  which decays with a factor
• With time the transient goes, and failure rate
  reaches a steady state
• Steady state failure rate represents the
  reliability of the product

14
Failure Rate of a Unit

• Failure rate for one unit is? (i) ?0 ai ?f
• ?0 is the initial transient rate
• ?f is the final steady state rate
• a is the decay factor

15
Applying it to a Product

• Considered the failure and sale data of a real
  product for MS
• Applying the model to the data and determining
  parameters, we get
• ?0 0.04 failures/month
• ?f 0.008 failures/month
• a 0.4 (i.e. 40 decay each month)

16
Example

• Steady state failure rate is 1/6th of average
  rate in month 2, 1/3rd of average rate in month 4
• I.e. initial MTTF could be 1/6th the steady state
  MTTF
• Steady state is reached quite soon in two to
  three months

17
Software Architecture Based Rel Estimation
18
Sw Architecture

• Architecture is the components in the system and
  how they are connected
• Is decided very early in sw project
• If reliability and performance can be modeled
  from architecture, can improve the architecture
• Some work going on in arch. based perf. and rel
  modeling

19
Program Verification
20
Program Verification

• Basic goal to ensure that program is free of
  defects (bugs) as much as possible
• Good program verification leads to higher
  reliability

21
Program Verification Techniques

• Testing program is executed with test data to
  find bugs
• Static analysis program source code is analyzed
• Dynamic analysis program run on some data and
  assertions made
• Model checking
• Formal verification

22
Techniques

• Most techniques work in isolation
• Sometimes they are complimentary in their defect
  detection capability
• Combining techniques meaningfully can improve
  reliability
• We are working on techniques for combining
  testing and static analysis

23
State-based Testing Automation
24
Testing

• Testing remains main verification activity most
  reliance on it
• Consumes as much as half of the total effort in a
  sw product
• Testing test case design, execution, checking
  the results, then debugging, fixing, retesting
• Each step is expensive

25
Test Automation

• Test automation can help reduce cost and make
  testing more effective
• Most test automation approaches focus on data
  collection, re-testing
• Little effort in complete end-to-end automation
• We are working on automating OO testing using
  state based models

26
Summary

• Software reliability is a rich and wide area
• Exciting work going on across the world in
  modeling, analysis, program checking, testing,
  etc
• Lots of open issues
