Location in CSD of electronic detector reconstructed events

1
Location in CSD of electronic detector
reconstructed events

• Scanning results from LNGS scanning lab
• N. DAmbrosio, N. Di Marco, L.S. Esposito, P.
  Monacelli and all the shifters that have been
  working since September

2
Event number 1064775 CSD ID 3000370 Brick
location W29/RW9/COL12, rock side SX -0.0839 ?
0.0013 SY 0.0259 ? 0.0012 PX 181.54 ? 0.27 cm
PY -288.03 ? 0.25 cm PZ-401.82 cm
with Dario and Antoine
3
Event number 1848052 CSD ID 3000456 Brick
location W28/RW8/COL8, rock side SX -0.0517 ?
0.0098 SY 0.3456 ? 0.0016 PX 238.99 ? 1.21
cm PY -302.33 ? 0.19 cm PZ -415.22 cm
with Dario and Antoine
4
Event number 2367442 CSD ID 3000521 Brick
location W29/RW9/COL8, corridor side SX
-0.0072 ? 0.0029 SY 0.6137 ? 0.0024 PX
-236.23 ? 0.24 cm PY -287.03 ? 0.20 cm PZ
-401.821
with Dario and Antoine
5
Brick position in OPERA detector
The brick position has been calculated using the
nominal geometry
6
Microscope efficiency
Double refreshed films exposed to CERN beam in
July
7
Scanning, processing and event selection

• General scanning 6?6 cm2 on both CS around the
  prediction position
• Top-bottom linking
• MinGrains ? 7 (actually set up in the microscope
  DAQ because of the higher fog density that slows
  the acquisition)
• MinSlope 0
• MergePosTol 20 mm
• MergeSlopeTol 0.050
• PosTol 30mm
• SlopeTol 0.050 rad
• SlopeTolIncreaseWithSlope 0.2
• Basetrack quality cut
• SigmaltN?0.13-1.7
• Event selection
• dtan(q)lt0.040 respect to the ED prediction
• CS connection
• dtan(q) lt 0.025 dr lt 40 mm Ntot?40

8
Event 1064775

• Scanned area 4.8 ? 4.1 cm2
• Located in emulsion on 18/11/2006 1654
• Confirmed manually

9
Event 2367442 not located

• CSD ID 3000521 (near edge, big slope)
• 6.0 x 3.1 cm2 on 29-NOV-06

10
Event 1848052 not located

• CSD ID 3000456
• 6.0 x 6.0 cm2 on 17-NOV-06 (surface lost)
• 6.0 x 6.0 cm2 on 20-NOV-06
• 6.0 x 6.0 cm2 on 27-NOV-06
• 9.2 x 9.4 cm2 on 29-NOV-06
• CSD ID 3000235 (near edge)
• 6.0 x 3.3 cm2 on 23-NOV-06

11
Event 18480523 out of 4 microtrack analysis

• BatchLink, version 2.0 modified with striplink
  option
• Quality cut for basetrack SigmaltN?0.13-1.7
• Promote microtracks to base-tracks if N?9
• Select all tracks if the Dslope ? 0.200 respect
  to ED reconstruction
• Proceed with the standard analysis
• For the connection of a basetrack and a
  microtrack
• 40 mm 150 mrad Dslope(basetrack-ED
  reconstruction)lt0.040
• No candidate was found

with Cristiano
12
Event 1848052double measured basetracks

• The two 6?6 cm2 zone in the same CS has been link
  together according to
• Dslope (basetrack-ED reconstruction) lt 0.050
• N?20 for at least one basetrack
• DSX(bt1-bt2) lt 0.020 DSY(bt1-bt2) lt 0.020
• 6 basetracks are selected on CS1, 5 are manually
  confirmed, no track found in CS2 according to
  projection
• 9 basetracks are selected on CS2, 6 are manually
  confirmed, no track found in CS1 according to
  projection

13
August run event beam
14
CS candidates reproducibility
EVENT MEASURED FOUND
4379516 9 9
937379 10 10
9516652 10 10
We re-measured the 3 August run events that we
have in LNGS In case of good tracks the system
has a good reproducibility
15
ED-CS connection
16
CS1-CS2 connection
Here the mark grid were not measured
automatically, it has been corrected in the
successive measurements
17
Link top-bottom microtracks
18
CSD exposed to cosmic rays

• 6 OPERA bricks were exposed to CR in order to
  fully simulate the OPERA scanning procedure
  (3000973,3001166,3001025,3000635,3000605,3000681)

• CS candidates were sent by mail to European
  scanning labs
• Scanned area
• 4.0 ? 4.0 cm2 in the central zone of 6 CSD
• 3.0 ? 9.2 cm2 along the short side of 5 CSD
• 193 CSD candidates / 234 cm2 ? 0.82/cm2
• Expected number 100/CS ? 0.83/cm2

19
(No Transcript)
20
Manual check

• To have a feeling of reliability of the cut used
  for the CS candidates selection the manual check
  has been performed for the tracks of CSD 3000605

This CS candidate has 39 grains
In one case a basetrack has been measured with a
wrong angle, some test are in progress
21

• We have to better use the mark position
• Some divergence in the X ray beam

22
CSD scanning driven by DB

• All scannings have been driven by DB
• Now the machinery works smoothly
• 4 scanning workstations works together
• 3 data processing computers
• 1 DB server
• 1 Batch Manager
• It needs easy operations by shifters from
  scanning workstations
• submit the job
• change plate

23
CS scanning modules

• Three programs have been written
• CSScanDriver controls, connects CSD, saves
  basetracks information in the DB
• WideAreaScanDriver scans areas in strips,
  manages strip linking, checks quality
  continuously
• BatchLink links strips optimizing performances
• the old StripLink has been replaced by custom
  version of BatchLink in order to benefit for
  future code developments

24
Input DB tables

• TB_PREDICTED_EVENTS
• EVENT
• ID_PROCESSOPERATION
• ID
• POSX
• POSY
• POSZ
• TYPE

• TB_PREDICTED_TRACKS
• ID_EVENT
• TRACK
• Z
• POSX
• POSY
• SLOPEX
• SLOPEY
• FRAME
• POSTOL1
• POSTOL2
• SLOPETOL1
• SLOPETOL2

• TB_PREDICTED_BRICKS
• ID_EVENT
• ID_EVENTBRICK
• PROBABILITY

A simple program that reads ED predictions from a
text file and inserts them into the DB
with emulsion DB group
25
Output DB tables

• TB_CS_CANDIDATES
• ID_EVENTBRICK
• ID_PROCESSOPERATION
• ID_EVENT
• TRACK
• CANDIDATE
• ID

• TB_CS_CANDIDATE_TRACKS
• ID_EVENTBRICK
• ID_CANDIDATE
• ID_ZONE
• SIDE
• ID_MICROTRACK

These tables are filled by CSScanDriver and are
used to feed the general DB with the information
to drive the scanning in the brick
with emulsion DB group
26
Conclusions and outlook

• CSD measurements driven by DB _at_ LNGS scanning lab
  works smoothly
• Its necessary to know OPERA geometry with a
  better accuracy both for brick position and track
  reconstruction
• Check mark accuracy
• Improve microtrack resolution
• Take under control emulsion distortions
