Connectionist Computing CS4018

1
Connectionist ComputingCS4018

• Gianluca Pollastri
• office CS A1.07
• email gianluca.pollastri_at_ucd.ie

2
Credits

• Geoffrey Hinton, University of Toronto.
• borrowed some of his slides for Neural Networks
  and Computation in Neural Networks courses.
• Ronan Reilly, NUI Maynooth.
• slides from his CS4018.
• Paolo Frasconi, University of Florence.
• slides from tutorial on Machine Learning for
  structured domains.

3
Lecture notes

• http//gruyere.ucd.ie/2007_courses/4018/
• Strictly confidential...

4
Books

• No book covers large fractions of this course.
• Parts of chapters 4, 6, (7), 13 of Tom Mitchells
  Machine Learning
• Parts of chapter V of Mackays Information
  Theory, Inference, and Learning Algorithms,
  available online at
• http//www.inference.phy.cam.ac.uk/mackay/itprnn/b
  ook.html
• Chapter 20 of Russell and Norvigs Artificial
  Intelligence A Modern Approach, also available
  at
• http//aima.cs.berkeley.edu/newchap20.pdf
• More materials later..

5
Paper 2

• Read the paper NETtalk a parallel network that
  learns to read aloud, by Sejnowski and Rosenberg
  (1986).
• The paper is linked from the course website.
• Email me (gianluca.pollastri_at_ucd.ie) a 250 word
  MAX summary by Feb the 26nd at midnight in any
  time zone of your choice.
• 5. 1 off each day late.
• You are responsible for making sure I get it, etc
  etc.

6
MLP applications matching words and sounds

• Sejnowski and Rosenberg, NETtalk, a parallel
  network that learns to read aloud, Cognitive
  Science, 14, 179-211 (1986)
• Teaching an MLP how to pronounce English by
  backprop.
• The network was given a stream of words, with the
  corresponding phonemes.
• Once the network had learned, it was possible to
  make it read.

7
MLP applications protein secondary structure
prediction

• Proteins are strings
• FEFHGYARSGVIMNDSGASTKS
• GAYITPAGETGGAIGRLGNQAD
• TYVEMNLEHKQTLDNG
• Structures too

8
deep network

• 4 hidden layers

9
Feature maps

• Hidden layers 1 and 3 implement feature maps.
• Layer 1 Input is the 16x16 image, with borders
  added for technical reasons -gt 28x28. Output is
  composed by 4 maps of 24x24 units. This is really
  implemented with 4 neurons, each taking 5x5
  inputs, each replicated in each possible position
  on the input map.
• This sounds complicated but is fairly easy
  instead of a (28x28)-gt(24x24x4) full connectivity
  only 5x5 inputs are connected to each output
  unit. Not only, but there are just 4 neurons/sets
  of weights (weight sharing).
• So, a (5x5)-gt4 full connectivity that sweeps the
  whole input. Only 104 weights including biases!

10
Averaging/subsampling layer

• Hidden layers 2 and 4 implement
  averaging/subsampling stages.
• Layer 2 24x24x4 -gt 12x12x4
• This is performed using 4 units, each one doing a
  2x2-gt1 mapping. Weights are constrained to be all
  the same.

11
layers 3, 4 and 5

• Layer 3 more feature maps. 12 8x8 maps. Each
  map is composed by a neuron (always the same)
  mapping a 5x5 area into a unit.
• Layer 4 Same as layer 2. (8x8x12) -gt (4x4x12)
• Layer 5 10 output units fully connected to layer
  4. This is where most weights are.

12
overall

• 5 layers, position invariance encoded in the
  architecture, a lot of weights shared.
• 100k connections -gt 2k independent parameters.
  every weight is shared on average by 50
  connections.
• Training complexity is still o(100k) though.

13
Training the network

• Training is by gradient descent, using
  backpropagation.
• For each copy j of a shared weight there will be
  a ?wj. They are simply added together.

14
Results

• After 30 epochs the error on the training set was
  1.1 and the squared error 0.017.
• On the test set 3.4 and 0.024
• To get 1 error 5.7 rejection (9 on just
  handwritten)
• A lot of these were actually caused by
  preprocessing. Some of those that werent, were
  ambiguous even to humans.

15
Invariances

• In Le Cuns paper we saw translation invariance
  was introduced into the network by weight
  sharing.
• Teaching neural networks invariances is a general
  problem.

16
The invariance problem

• Our perceptual systems are very good at dealing
  with invariances
• translation, rotation, scaling
• deformation, contrast, lighting, rate
• We are so good at this that its hard to
  appreciate how difficult it is.
• Its one of the main difficulties in making
  computers perceive.
• We still dont have generally accepted solutions.

17
Invariances using features

• Instead of representing an object directly,
  extract whatever-invariant features first.
• For instance, if we want roto-translational
  invariance, represent an object by the distances
  between parts instead of xyz coordinates.

18
Invariances normalisation

• For instance put a box around an object, then
  scale it to a fixed size same as preprocessing
  digits in Le Cun et al.
• Eliminates degrees of freedom.
• Not always trivial how to choose the box.

19
Invariances brute force

• We can tackle invariances by
• constraining network weights
• using features
• normalising
• But computer scientists should be lazy and
  impatient. Wouldnt it be great if we could let
  the network do all the job?
• Brute force to create invariance to
  trasformation X, for each example generate a lot
  of new other examples by applying X to it. Then
  train a large network on a fast computer.

20
Invariances brute force

• For example, translate and rotate a digit in a
  lot of different ways and train a large network
  to recognise it.
• It generally works well, if the transformations
  arent too large do approximate (easy)
  normalisation first.

21
Summary invariances

• Often as tough a problem as learning after
  invariances are tackled.
• Possible solutions
• network design
• features
• normalisation
• brute force

22
Problems with squared error

• So far, for gradient descent, we used
• Error squared
• Output function linear or sigmoid (binary wont
  work)
• There are tricky problems with squared error. For
  instance if the desired output is 1 and the
  actual output is very close to 0 there is almost
  no gradient.

23
Problems with squared error

• These are the deltas
• And these are f and f

24
Alternatives softmax and relative entropy

• Non-local non linearity.
• Outputs add up to 1 (can be interpreted as the
  probability of the output given the input).
