Assess A Claim

1
Assess A Claim

• Object Interaction Diagrams

2
Object sequence Diagrams - Use case

• Sequence of events that occur during one
  particular execution of a system
• This sequence can effect one or more objects
• The object sequence diagram shows the flow of
  messages between object classes
• Object classes include entity, control and
  boundary classes

3
Sequence diagrams

• An object is shown at the top of a dashed
  vertical line - the objects lifeline.
• The lifeline may start half way down the
  diagram, at creation.
• The lifeline may end during the diagram, at
  deletion. This can be done by placing an X at the
  end of the life of the object.
• Each message is represented by an arrow between
  the lifelines of two objects.
• The messages are listed from top to bottom in
  order of occurrence.

4
Components of Sequence diagrams

• Objects in use
• Sometimes the object is replaced by an anonymous
  object from the class.
• This shows that any instance of this class can
  realise the operation.
• Events or operations
• These represent messages between the objects.
• The event is normally where one object invokes a
  method on the other object.

5
Example Sequence Diagram
6
Interaction diagrams in UML

• They are models that describe how groups of
  objects collaborate in some behaviour.
• An interaction diagram captures the behaviour of
  a single use case. It shows a number of example
  objects and the messages that are passed between
  these objects within the use case.
• There are two kinds of interaction diagrams
  sequence diagrams and collaboration diagrams.

7
Elaborated Use Case

• Continue on from First cut elaboration
• Convert the methods into inter-object signals
  where appropriate.
• Represent inter-object signals as interactions in
  an Object Sequence Diagram.
• See the screens used on the following slides.

8
Screens used
9
(No Transcript)
10
(No Transcript)
11
Boundary class representation
12
Control classes

• 1 for implementing Assess A claim
• Possibly one for View a claim
• Details not given here, for the sake of
  simplicity.

13
Data Services or Entity classes
14
Used classes

• Boundary
• ClaimsForAssessment containing ClaimsForAssessment
  SB
• ViewClaim
• AssessClaimScreen
• Control
• AssessAClaim
• Entity
• Claim
• Assessor

15
Diagram
