Lecture 21: Instruction Level Parallelism Branch Prediction

1
Lecture 21 Instruction Level Parallelism (Branch
Prediction)

• Computer Engineering 585
• Fall 2001

2
Branch Prediction Buffer
IF
ID
EX
M
WB
I-Cache
PC
3
Branch Target Buffer (BTB)
PC of instruction to fetch
Look up
Predicted PC
Number of
entries
in branch-
target
buffer
No instruction is
not predicted to be

Branch
branch. Proceed normally
predicted
taken or
untaken
Yes then instruction is branch and predicted
PC should be used as the next PC
FIGURE 4.22 A branch-target buffer.
4
Branch Prediction Steps
5
Dynamic Branch Prediction

• Performance (accuracy, cost of misprediction)
• Branch History Table is simplest
• Lower bits of PC address index table of 1-bit
  values
• Says whether or not branch taken last time
• No address check
• Problem in a loop, 1-bit BHT will cause two
  mispredictions (avg is 9 iterations before exit)
• End of loop case, when it exits instead of
  looping as before
• First time through loop on next time through
  code, when it predicts exit instead of looping

6
1-Bit Prediction Drawbacks
LOOP Inst 1 Inst 2 Inst 3
. . Inst k
Branch
Taken 9 times Not taken 1 time
1-bit prediction mispredicts twice 20
misprediction rate
7
Dynamic Branch Prediction

• Solution 2-bit scheme where change prediction
  only if get misprediction twice (Figure 4.13, p.
  264)

Taken
Not taken
Predict taken (11)
Predict taken (10)
Taken
Taken
Not taken
Not taken
Predict not taken (01)
Predict not taken (00)
Taken
Not taken
8
BHT Accuracy

• Mispredict because either
• Wrong guess for that branch.
• Got branch history of wrong branch when indexing
  the table.
• 4096 entry table programs vary from 1
  misprediction (nasa7, tomcatv) to 18 (eqntott),
  with spice at 9 and gcc at 12
• 4096 about as good as infinite table(in Alpha
  211164)

9
4096 entry 2-bit Prediction accuracy
nasa7
1
matrix300
0
1
tomcatv
5
doduc
spice
SPEC89
9
benchmarks
9
fpppp
gcc
12
5
espresso
18
eqntott
10
li
0
18
2
4
6
8
10
12
14
16
Frequency of mispredictions
FIGURE 4.14 Prediction accuracy of a 4096-entry
two-bit prediction buffer for t
he
SPEC89 benchmarks.
10
4096 entry Vs Infinite 2-bit prediction
1
nasa7
0
0
matrix300
0
1
tomcatv
0
5
doduc
5
9
spice
9
SPEC89
benchmarks
9
fpppp
9
12
gcc
11
5
espresso
5
18
eqntott
18
10
li
10
0
2
4
6
8
10
12
14
16
18
Frequency of mispredictions
4096 entries
Unlimited entries
2 bits per entry
2 bits per entry
11
Correlating Branches

• Hypothesis recent branches are correlated that
  is, behavior of recently executed branches
  affects prediction of current branch.
• Idea record m most recently executed branches as
  taken or not taken, and use that pattern to
  select the proper branch history table.
• In general, (m,n) predictor means record last m
  branches to select between 2m history tables each
  with n-bit counters.
• Old 2-bit BHT is then a (0,2) predictor

12
Correlating Branches
if (d0) d1 if (d1)
B1 and B2 are correlated? B1 Not Taken ? B2 Not
Taken
13
Correlating Branch Example
Assume d alternates between 2 and 0.
b1
b1
New b1
b2
b2
New b2
d?
prediction
action
prediction
prediction
action
prediction
2
NT
T
T
NT
T
T
0
T
NT
NT
T
NT
NT
2
NT
T
T
NT
T
T
0
T
NT
NT
T
NT
NT
1-bit predictor mispredicts every branch!
14
Correlating Branch Example
Prediction if last branch
Prediction bits
not taken
Prediction if last branch taken
NT/NT
Not taken
Not taken
NT/T
Not taken
Taken
T/NT
Not taken
Taken
T/T
Taken
Taken
Initial prediction NT/NT
b2 action
b1 prediction
New b1 prediction
d?
b1 action
b2 prediction
New b2 pred
NT/
NT
2
T
T/NT
T
NT/T
NT
/NT
0
NT
T/NT
NT
NT/T
T/
NT
NT
/T
2
T
/NT
T
T/NT
NT/
T
NT/T
T
0
T/
NT
NT
T/NT
NT
/T
NT
NT/T
15
Correlating Branches

• (2,2) predictor
• Then behavior of recent branches selects between,
  say, four predictions of next branch, updating
  just that prediction

Branch address
4
2-bit per branch predictors
XX prediction
XX
00
01
10
11
2-bit global branch history
