Come Fly With MeThe aviators new best friend

• KARENZA

2
Come Fly With MeThe aviators new best friend

• The aircrafts exact position is shown via GPS and
  positioned
• on a map updated every 15 seconds.
• Anyone you choose can follow your track live
• and will always know your exact location

3
Come Fly With MeThe aviators new best
friendThe Karenza Package

• Karenza consists of three sections
• A Live GPS Tracking viewed by 3rd Parties
• B Live GPS Tracking used by Pilots
• C Flight Planning

4
Come Fly With MeThe aviators new best friend
Home Page
5
Come Fly With MeThe aviators new best friend
1. View my Location in Detail
6
Come Fly With MeThe aviators new best friend
7
Come Fly With MeThe aviators new best friend
2. Current Location of John Levee
8
Come Fly With MeThe aviators new best friend
3. Current Location of Pilots
9
Come Fly With MeThe aviators new best friend
4. Tracks History Listing with track selected
10
Come Fly With MeThe aviators new best friend
5. View Selected Flights
11
Come Fly With MeThe aviators new best
friend Live GPS Tracking for Pilots

• Features
• GPS CONNECT Adds a green icon at the GPS
  co-ordinates.
• GPS DATA Maintains the map position centred at
  the
• GPS co-ordinates.
• Data is updated every 15 seconds.
• Destination Data Calculates heading and distance
  data.

12
Come Fly With MeThe aviators new best
friend Live GPS Tracking for Pilots

• Features
• COMPASS Draws a grey line showing the aircrafts
  current heading
• Draws a red line showing the heading to the
  destination point
• (updated every 15 seconds)

13
Come Fly With Me The aviators new
best friend
14
Come Fly With MeThe aviators new best friend
15
Come Fly With MeThe aviators new best friend
The track history of the Jindabyne to Bankstown
flight via Canberra re previous two slides
16
Come Fly With MeThe aviators new best friend
A zoomed in pilots view of tracking from
Jindabyne to Canberra to avoid restricted zones
etc.
17
Come Fly With MeThe aviators new best friend
Karenza working in a Jetstar flight from Cairns
to Sydney
18
Come Fly With MeThe aviators new best
friend Images

• Karenza uses overlays to store data
• which are positioned in front of an image.
• Three (3) image types are used.
• Map Image
• Satellite Image
• Terrain Image
• with a choice of 24 zoom levels.

19
Map Image Zoom Level 14

20
Satellite Image Zoom Level 19

21
Terrain Image Zoom Level 10

22
Satellite Image Map Image Zoom Level
0 Zoom Level 2

23
Satellite Image and, Zoom Level 23

NB The Red Marker in these 3 images hasnt
moved. Its co-ordinates are 15.298683, 19.429651
24
Flight Information Regions Terrain Image Zoom
Level 7 With the GPS icon showing the aircrafts
exact position every 15 seconds it is easy to
know the correct radio frequency

25
Flight Information Regions Map Image with Labels
Zoom Level 8 With the GPS icon showing the
aircrafts exact position every 15 seconds it is
easy to know the correct radio frequency

26
Sydney Airport Inbound Lanes for Helicopters Map
Image Zoom Level 12 With the GPS icon showing the
aircrafts exact position every 15 seconds it is
easy to keep the aircraft following along the
line of the required lane

27
Controlled Airspace C Terrain Image Zoom Level
9 With the GPS icon showing the aircrafts exact
position every 15 seconds it is easy to keep the
aircraft outside of controlled airspace

28
Controlled Airspace C Satellite Image with Labels
Zoom Level 10 With the GPS icon showing the
aircrafts exact position every 15 seconds it is
easy to keep the aircraft outside of controlled
airspace

29
Lanes and Labels selected Terrain Image Zoom
Level 10 With the GPS icon showing the aircrafts
exact position every 15 seconds it is easy to
keep the aircraft following along the line of the
required lane

30
Maximum Range Zoom Level 6 The blue circle shows
the aircrafts Maximum Range from the red marker
based on Aircraft Data
