Dizzy Basics for Home Pages

1
Dizzy Basics for Home Pages Information
Technology Learning Team
2
Contents

• What is Dizzy?
• How Dizzy Works
• Dizzy File System Structure
• Terminology
• Commands
• Webliography

3
What is Dizzy?

• it is a UNIX server
• UNIX is an operating system
• servers have high-speed connections to the
  Internet
• servers run software to make Web pages available
  for browsers to access
• our server, dizzy, houses all the UA Library
  homepages so they can be accessed by the Internet

4
How Dizzy Works
5
Dizzy File System Structure

• Files
• Directories
• Pathnames
• Structure of the file system
• Navigating within file system for home pages

6
Files

• used to store the information that you usually
  work with such as an HTML document or an image
• common file extensions .htm, .gif, .jpg, .au
• you own files that you create and can set
  access permissions to control which other users
  can have access to them
• files are contained within a directory

7
Directories

• A file that holds other files and other
  directories
• you can create directories in your home directory
  to hold files and other sub-directories
• directories allow you to structure your
  information in a way that makes best sense to you

8
Pathnames

• Every file and directory in the file system can
  be identified by a complete list of names of the
  directories that are on route from root
• /usr5/webdir/library/teams/ust/homepage.htm
• is the pathname for the UST home page

9
Structure of File System

• /(root)
• ------------------------------------------------
  ------------------
• /usr10 (for staff home pages)
  /usr5
• /users lt--link--gt /webdir (WWW
  document root)
• ---- ---------------- ------------------
  ---------
•

• /mmorales /rgrunloh
  /library
• /training
  ----------------------------
• homepage.htm
  /teams
•

• ----------------------
• /ust

10
Navigating within File System for Home Pages

• Windows 3.1 Users
• Logging On/Off
• Your Personal and Home Team Directories
• Windows 95 or NT Users
• Mapping the W Drive
• Logging On/Off
• Your Personal and Home Team Directories

11
Logging On/Off(Windows 3.1 - use TELNET)

• telnet dizzy.library.arizona.edu
• the system will then ask for your login and
  password
• login calvin
• password (your password is never displayed on
  the screen as you type it in so others cant see
  it)
• each user initially logs into their home
  directory
• /usr11/users/mmorales
• to logoff, at the prompt type
• exit or logoff

12
(No Transcript)
13
Your Personal and Team Home Page Directories
(Windows 3.1 users)

• To create/edit your personal web pages you need
  to change directories (cd) from your home
  directory by typing
• cd www or cd teamname
• to see what files are in the directory type
• ls
• to change into another directory within www or
  your hometeam directory type
• cd directory name

14
(No Transcript)
15
Your Personal and Team Home Page Directories
(Windows 3.1 users)

• To go up a directory type
• cd ..
• To edit an html page type
• pico name.html
• to save changes you have made in pico type
• Ctrl-O
• to exit pico type
• Ctrl-X
• to return to your home directory type
• cd
• to FTP a file into your personal or hometeam
  directory, use the entire pathname
• /usr5/webdir/library/teams/ust

Go to Terminology Page
16
Mapping the W Drive(Windows 95/NT users)

• Go to File Manager
• in the Disk pull down menu choose
• Connect Network Drive
• in the Drive window choose W
• in the Path window type
• \\dizzy\webdir
• in the Connect As window type your dizzy login
  name
• check the Reconnect at Logon box

17
(No Transcript)
18
(No Transcript)
19
Logging On/Off(Windows 95/NT users)

• Start your computer
• enter your dizzy password when prompted
• go to File Manager
• click on the W Drive to see the list of
  directories in dizzy

20
(No Transcript)
21
Your Personal and Team Home Page Directories
(Windows 95/NT users)

• Your personal home page is in the directory
  called users
• to get to your team directory choose the library
  directory, then your team directory
• you can save files directly to dizzy

22
Terminology

• access permissionsa set of permissions
  associated with every file and directory that
  determine who can read it, write to it, or
  execute it. Only the owner of the file (or the
  super-user) can change these permissions.
• home directory the directory you are placed in
  immediately after you login to the system.
• root the directory located at the top of the
  Unix file system. It is represented by the "/"
  (forward slash) character.
• pico an editor
• file manager a tool you can use in Windows to
  organize your files and directories.
• WWW document root the only part of the Dizzy
  directory structure that the WWW server can see
• link allows other parts of the Dizzy directory
  structure to be available to Web browsers

23
Commands

• display list of files.. ls
• with file details.. ls- la
• copy file.. cp
• rename file.. mv
• delete file rm
• delete directory rmdir
• change file protection. chmod
• create directory mkdir
• change working directory cd ltdirectory namegt
• go up one directory. cd ..
• return to home directory. cd
• present working directory pwd
• get help man

24
Webliography(for more info on UNIX)

• UA Manual Pages - Information on World Wide Web
  pages
• http//dizzy.library.arizona.edu/manual/www/www.ht
  ml
• UNIXhelp for Users
• http//www.nova.edu/Inter-Links/UNIXhelp/TOP_.html

• The UNIX Reference Desk references to material
  culled from a number of different sources on
  computing in the UNIX environment.
• http//www.geek-girl.com/unix.html
• UNIX Survival a basic introduction to UNIX and
  descriptions of some essential UNIX commands.
• http//gc.bcm.tmc.edu8088/gc_help/unix.html
