Alkali-Silica Reaction:

1
Alkali-Silica ReactionThe Cancer of Concrete
Courtney Collins . Jason Ideker . Gayle
Willis . Jessica Hurst
2
Outline

• What is ASR and why is it important?
• How does ASR work?
• How can ASR damage be prevented?

3
What is ASR?
Alkali Silica Reaction (ASR)
Alkalis Reactive Silica Moisture
Concrete expansion and cracking
ASR Gel which expands
4
Concrete failure due to ASR
AASHTO Innovative Highway Technologies
AASHTO Innovative Highway Technologies
AASHTO Innovative Highway Technologies
Georgia Tech School of CEE - Courtney Collins
5
Why is it important to study ASR?

• Concrete quality
• Loss of strength, stiffness, impermeability
• Premature failure of concrete structures
• Economic/Environmental impacts
• ASR decreases concrete service life
• Reconstruction has both environmental and
  economic impacts. ex. cement production produces
  7 of the worlds CO2 emissions (a greenhouse
  gas)

6
Case Study Parker Dam, California
http//www.acres.com/aar/
Alkali-Aggregate Reactions in Hydroelectric
Plants and Dams

• Hydroelectric dam built in 1938
• 180 mm of arch deflection due to alkali silica
  gel expansion
• Cracking and gel flow in concrete

7
Case Study I-85 - Atlanta, Georgia

• Possible ASR damage on concrete retaining wall -
  picture taken 1/2002

8
How does ASR work?
What we know

• Which reactants involved and their sources
• How alkali-silica gel is created
• ASR prevention can be achieved by using low
  alkali cement, non-reactive aggregate, and
  concrete with low permeability
• Additives such as lithium compounds and
  pozzolanic material help prevent ASR damage

What we dont know

• Mechanism of gel expansion
• Lithium its mechanism of inhibition, which
  compounds work best, how much of each compound is
  needed to prevent expansion

9
Creation of alkali-silica gel
10
Creation of alkali-silica gel
Reactants alkalis, reactive silica, and water
Alkalis

• Main cations
• Sodium (Na)
• Potassium (K)
• Common sources
• Portland cement
• Deicing agents
• Seawater

11
Creation of alkali-silica gel
Reactive Silica
Silica tetrahedron
Amorphous Silica
Crystalline Silica
12
Creation of alkali-silica gel
Reactive Silica
Amorphous or disordered silica most chemically
reactive Common reactive minerals strained
quartz opal obsidian cristobalite tridymite c
helcedony cherts cryptocrystalline volcanic
rocks
13
Creation of alkali-silica gel
Water

• Found in pore spaces in concrete
• Sources
• Addition of water to concrete mixture
• Moist environment/permeable concrete

14
Creation of alkali-silica gel
1. Siliceous aggregate in solution
15
Creation of alkali-silica gel
2. Surface of aggregate is attacked by OH-
H20 Si-O-Si
Si-OHOH-Si
16
Creation of alkali-silica gel
3. Silanol groups (Si-OH) on surface are broken
down by OH- into SiO- molecules
Si-OH OH-
SiO- H20
17
Creation of alkali-silica gel
4. Released SiO- molecules attract alkali
cations in pore solution, forming an
alkali-silica gel around the aggregate.
Si-OH Na OH-
Si-O-Na H20
18
Creation of alkali-silica gel
5. Alkali-silica gel takes in water, expanding
and exerting an osmotic pressure against the
surrounding paste or aggregate.
19
Creation of alkali-silica gel
6. When the expansionary pressure exceeds
the tensile strength of the concrete, the
concrete cracks.
20
Creation of alkali-silica gel
7. When cracks reach the surface of a structure,
map cracking results. Other symptoms of
ASR damage includes the presence of gel
and staining.
21
Creation of alkali-silica gel
8. Once ASR damage has begun
Expansion and cracking of concrete
Increased permeability
More water and external alkalis penetrate concrete
Increased ASR damage
22
Images of ASR damage
23
Images of ASR damage
24
Images of ASR damage
25
How to prevent ASR damage
26
How to prevent ASR damage
Alkalis Reactive Silica Moisture
ASR Gel

• Avoid high alkali content
• use low alkali portland cement Na20eq lt 0.69
• replace cement with low alkali mineral admixtures
• Avoid reactive aggregate (amorphous silica)
• Control access to water use low water to cement
  ratio, monitor curing conditions, use admixtures
  to minimize water contact.
• Use lithium additives prior to placement of
  concrete or as a treatment in already existing
  concrete

27
ANY QUESTIONS?
