Polymorphism and Pharmaceuticals Steve Byrn

1

• Polymorphism and PharmaceuticalsSteve Byrn
• stephen.byrn_at_gte.net

2
Dimensions

• Solid State Chemical Science
• Regulatory
• Patents
• Speed to market
• Public health
• Costs

3
Solid State Technology
4
Cardinal Rules
5
Eliminate The Pipeline Problem
6
Polymorph Discovery
full
Focused
Early
Comprehensive (lifecycle)
may include salt, cocrystal, amorphous forms
7
Frequency of Multiple Forms
Based on about 150 studies 87 gt than 1
form 51 multiple polymorphs 37 hydrates 39
amorphous 31 solvatesSSCI Data
(Pat Stahly)
8
Prediction from Energy-Temperature Diagrams
9
ICH Decision Tree - Polymorphs Question 1
Note broad definition of polymorphs
10
ICH Decision Tree - Polymorph Question 2
11
ICH Decision Tree - Question 3
For solid dosage form or liquid containing
undissolved drug substanceN.B. Undertake the
following process only if technically possible
12
(No Transcript)
13
Law,et al., J. Pharm. Sci. 93 (2004) 563
14

Law,et al., J.Pharm.Sci. 93 (2004) 563
15
(Ralph Pfeiffer)
16
Four Simple ROY Derivatives
4-Me-ROY
The Original ROY
C. A. Bunnell (Eli Lilly, 1995)
X. He, U. Griesser (2001)
4-Me-5-norMe-ROY
5-norMe-ROY
H. Li (2003)
J. Hatakama (2005)
17
The Original ROY
18
4-Me-ROY

• Four Polymorphs

19
5-norMe-ROY

• Two Polymorphs

20
Four Simple ROY Derivatives
C. A. Bunnell (Eli Lilly, 1995)
X. He, U. Griesser (2001)
6 Polymorphs
4 Polymorphs
This Work
H. Li (2003)
2 Polymorphs
? Polymorphs
21
Synthesis of 4-Me-5-norMe-ROY
46.8g (18)
98.4g (53)
ca 36g (14)a
a Needs further purification
22
Polymorph Discovery

• Simple heat-cool method
• Evaporation method
• Vapor diffusion method
• Hotstage/melt methods
• Vapor deposition method
• Rapidly changing the solvent by pouring the
  solution into anti-solvent
• Even for solvent based methods there are gt
  700,000 experiments
• Need rational approach

Vapor diffusion
Vapor depostion
23
Red Form R4M5N

• Initial crystallization studies gave only a red
  form (R4M5N).
• Is this the first ROY derivative with only one
  form?

R4M5N
24
Seeding with other ROY Derivatives

• Using yellow needles of 5-Et-ROY as seed crystals
• Slow evaporation method in EtOH at room
  temperature afforded orange form (O4M5N).
• Not cocrystal
• Pure orange form

Y5ET
O4M5N
25
XRPD O4M5N and R4M5N
R4M5N
O4M5N
26
New Form of 4-Me-5-norMe-ROY O4M5N
R4M5N O4M5N Y5ET
Color Red Orange Yellow
XRPD A B -
mp (C) (Capillary) 142-143 139-140 104-105
27
X-Ray Crystallography

• Crystal structures of each form were solved.

28
The Unit Cells
O4M5N
R4M5N
29
Equilibrium Solubility in EtOH Results

• vant Hoff Plot

ln C a bT-1
r2 gt 0.99
Regression Coefficients
a b r2
R4M5N 15.002 -4222.8 0.994
O4M5N 16.684 -4788.7 0.996
30
Equilibrium Solubility in EtOH Results

• Relative Energy-Temperature Diagram

a
b
a. Calculated values from the regression line, y
16.684 - 4788.7x. b. Calculated values from the
regression line, y 15.002 - 4222.8 x.
Free Energy-Difference ?GR,O RTln(CR /CO)
63.5C
31
Relative Energy-Temperature Diagram

• Dcalc (calcd. density)
• mp
• Solubility

32
Conclusion

• Fourth derivative of simple ROY has been newly
  synthesized.
• In initial polymorph study, various
  crystallization conditions gave only a red form
  (R4M5N).
• Seeding with another ROY (Y5ET) afforded new form
  (orange form, O4M5N).
• Solubility studies showed that the new form
  (O4M5N) is the most stable form at room
  temperature
• The red and orange forms are enantiotropic
• Red form adopts the most planar conformation
  among ROY compounds.

33
Strategies to Find New Forms

• Guillory methods
• Seeding with related compounds
• Templated crystallization (Epitaxial growth)
• Ultrasound, Lasers
• Capillary crystallization
• Studied 18 top selling drugs
• The form on the market is most stable
• Found new forms in 13 cases
• Only 4 are solvates
• In 9 of the 13 cases, the new forms could also be
  made by other methods

(Barbara Stahly)
34
Why Capillaries?

supersaturation ratios as high as 60 have
been achieved
(Ken Morris)
35
Plots of Fraction of Most Stable Form vs
Supersaturation for two conditions (top) 50
mg/mL and (bottom) 100 mg/mL.As
supersaturation increases fraction of most stable
form decreases
Childs, Crystal Growth Design, 4, 441 (2004)
36
Fundamental Studies Using ROY
Morris, K. Hilden, J. Kelm, M. Reyes, C.
Purdue University, to be published
37
SSCI Case Study Nabumetone

• The anti-inflammatory Relafen
• One solid form reported in the literature

• About 250 traditional solvent experiments
  provided only the known Form I
• In capillaries new Form II was obtained in 18 of
  the experiments
• Appearance of Form II depended on supersaturation
  and quiescence, not solvent

Chyall, Crystal Growth Design, 2, 505 (2002)
38
Nabumetone Form II
1000 mm
39
Confidential
X-ray Powder Diffraction Software and Analysis of
Crystal Structures using XRPD
(Simon Bates)
40
Figure 1Example dendrogram from pattern matching
program based on modified HCA
41
Figure 2 Pattern matching result
42
Figure 3 Single cluster
43
XRPD Pattern Analysis - Use of Electron Density
map for Rietveld
Form A 67.4 Form C1 32.6
Rietveld analysis (MAUD) using electron density
for Quantitative analysis
44
XRPD Pattern Analysis Indexing
Monoclinic P21/n a14.724 b7.0953 c21.5057
beta103.77
45
XRD Pattern Analysis Physical Properties
Prediction
Form A Morphology
Form C1 Morphology
Density Stability Rule Form A density 1.19
g/cm3 Form C1 density 1.18 g/cm3 Experimental
Occurrence Form A 123 Form C1
32 Inter-conversion lt 95 C Form C1 gtgt Form A
Inter-conversion gt 95 C Form A gtgt Form C1 Form
C1 proved difficult to manufacture!
46
XRPD Pattern Analysis The Next Step - 2.)
Pair-Wise Distribution Functions

• Fourier Sine Transform of Reduced Structure
  Factors -gt PDF.
• Can be used on 1D or 3D diffraction data.
• Used to isolate characteristic repeats and
  packing of atoms within solid forms.
• Identify Order-Disorder relationships.
• Break Down Complex Molecular Structures into
  Building Blocks.
• Improved Pattern Matching

47
XRPD Pattern Analysis - PDF Order - Disorder
relationships
Significant Peak broadening!
Measured XRPD patterns - are materials related?
48
XRPD Pattern Analysis - PDF Order - Disorder
relationships
Local Order matches
Loss of long range order in disordered form
49
XRPD Pattern Analysis - The PDF Transform for
Indomethacin (Gamma)
17.1Å
10.3Å
Characteristic Length Scales
5.33Å
Distance in Å
50
10.3Å Cl-Cl distances
Gamma Form
17.1Å Cl-Cl distances
View of crystal structure for Gamma form using Cl
as a central atom. Cl forms a very simple lattice
acting as a frame for the organic components.
51
XRPD Pattern Analysis - The PDF Transform
Cryo-grinding of IMC gamma
0 minutes
12 minutes
30 minutes
52
XRPD Pattern Analysis - The PDF Transform
0 minutes
12 minutes
Loss of long range order
Residual memory
30 minutes
40.0Å
Distance in Å
53
Utilization of XRPD Software

• Predict Stability
• Density rule
• Tunnel area
• Select candidates for development
• Number of forms not as important as the fact that
  several forms exist with about the same energy
• Analyze amorphous forms
• Determine residual order
• Predict ease of crystallization

54
FDA Initiatives
55
FDA Critical Path
56
PAT Process Understanding
57
PAT Integrated into Drug Substance Manufacturing
58
Sensor Strategy
(Ken Morris)
59
Raman Monitoring of Polymorph During
Crystallization
(Lynne Taylor)
60
Desired Future State

• Quality by Design
• Know what you have form discovery
• Specifications based on mechanistic understanding
• Continuous quality assurance
• Make the same thing every time
• Risk based regulatory scrutiny

61
Conclusion

• Know what you have polymorph discovery
• Make the same thing every time
  characterization/analytical aspects
• Speed is paramount
• Major advances in application of XRPD
• Quality by design Risk based regulations

62
Eliminate The Pipeline Problem
63
XRPD Patterns

• Comparison between theoretical and observed
  pattern

R4M5N
O4M5N
64
Number of Experiments

• 60 solvents 60x603600
• 10 concentrations 36000
• 10 temperature changes (or 10 evaporation rates)
  360,000
• With and without stirring 720,000
